Page 1 Cisco Aironet 1200 Series Access Point Software Configuration Guide Software Release 11.40T April, 2002 Corporate Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 526-4100 Text Part Number: OL-2159-01...
Page 2 Breakthrough, iQ Expertise, iQ FastTrack, the iQ Logo, iQ Net Readiness Scorecard, Networking Academy, ScriptShare, SMARTnet, TransPath, and Voice LAN are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn, Discover All That’s Possible, The Fastest Way to Increase Your Internet Quotient, and iQuick Study are service marks of Cisco Systems, Inc.;...
Page 3: Table Of Contents
C H A P T E R Key Features Management Options Network Configuration Examples Root Unit on a Wired LAN Repeater Unit that Extends Wireless Range Central Unit in an All-Wireless Network Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 4 Serial Number Configuration Server Protocol Default IP Address Default IP Subnet Mask Default Gateway Radio Service Set ID (SSID) Role in Radio Network Radio Network Optimization (Optimize Radio Network For) Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 5 Settings on the Boot Server Setup Page 3-47 Entering Web Server Settings and Setting Up Access Point Help 3-50 Settings on the Web Server Setup Page 3-51 Entering Name Server Settings 3-53 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 6 C H A P T E R Security Overview Levels of Security Encrypting Radio Signals with WEP Additional WEP Security Features Network Authentication Types Protecting the Access Point Configuration with User Manager Setting Up WEP Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 7 Setting the Display Options Using Station Pages Information on Station Pages Performing Pings and Link Tests Clearing and Updating Statistics 5-10 Deauthenticating and Disassociating Client Devices 5-11 Using the Network Map Window 5-11 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 8 Downloading the Current Configuration 6-11 Uploading a Configuration 6-12 Uploading from a Local Drive 6-12 Uploading from a File Server 6-13 Resetting the Configuration 6-14 Restarting the Access Point 6-15 Cisco Aironet 1200 Series Access Point Software Configuration Guide viii OL-2159-01...
Page 9 Data Received Data Transmitted Ethernet Port Page AP Radio Page 9-12 Event Log Page 9-16 Display Settings 9-16 Log Headings 9-17 Saving the Log 9-17 Event Log Summary Page 9-18 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 10 Finding an Access Point by Blinking the Top Panel Indicators 9-40 Checking Basic Settings 9-40 SSID 9-40 WEP Keys 9-40 EAP Authentication Requires Matching 802.1x Protocol Drafts 9-41 Resetting to the Default Configuration 9-43 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 11 A P P E N D I X Channels Maximum Power Levels and Antenna Gains Protocol Filter Lists A P P E N D I X N D E X Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 12 Contents Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 13: Preface
Preface The Cisco Aironet 1200 Series Access Point Software Configuration Guide describes how to configure Cisco Aironet 1200 Series Access Points using the web-based management system. This manual also briefly describes how to use the console-based management system. Audience and Scope This guide is for the network manager responsible for configuring a wireless network.
Page 14: Conventions
Commands and keywords are in boldface text. • Notes, tips, and cautions use the following conventions and symbols: Note Means reader take note. Notes contain helpful suggestions or references to materials not contained in this manual. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 15: Related Publications
Related Publications The following documents provide more information about access points and related products: Quick Start Guide: Cisco Aironet 1200 Series Access Points describes how to • attach cables, power on, and assign an IP address and default gateway for the access point.
Page 16: Obtaining Documentation
Obtaining Documentation The following sections explain how to obtain documentation from Cisco Systems. World Wide Web You can access the most current Cisco documentation on the World Wide Web at the following URL: http://www.cisco.com Translated documentation is available at the following URL: http://www.cisco.com/public/countries_languages.shtml...
Page 17: Documentation Feedback
If you are reading Cisco product documentation on Cisco.com, you can submit technical comments electronically. Click Leave Feedback at the bottom of the Cisco Documentation home page. After you complete the form, print it out and fax it to Cisco at 408 527-0730.
Page 18: Technical Assistance Center
No workaround is available. Which Cisco TAC resource you choose is based on the priority of the problem and the conditions of service contracts, when applicable. Cisco TAC Web Site...
Page 19: Cisco Tac Escalation Center
If you cannot resolve your technical issues by using the Cisco TAC Web Site, and you are a Cisco.com registered user, you can open a case online by using the TAC Case Open tool at the following URL: http://www.cisco.com/tac/caseopen If you have Internet access, it is recommended that you open P3 and P4 cases through the Cisco TAC Web Site.
Page 20 Preface Obtaining Technical Assistance Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 21: Overview
C H A P T E R Overview Cisco Aironet access points are wireless LAN transceivers that serve as the center point of a stand-alone wireless network or as the connection point between wireless and wired networks. In large installations, wireless users within radio range of an access point can roam throughout a facility while maintaining seamless, uninterrupted access to the network.
Page 22: Key Features
CLI. The examples in this manual are all taken from the browser interface. Chapter 2, “Using the Management Interfaces” provides a detailed description of each management option. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 23: Network Configuration Examples
The access point’s default configuration is as a root unit connected to a wired LAN or as the central unit in an all-wireless network. The repeater role requires a specific configuration. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 24: Root Unit On A Wired Lan
LAN. Figure 1-1 Access Points as Root Units on a Wired LAN Access Point (Root Unit) Wired LAN Access Point (Root Unit) Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 25: Repeater Unit That Extends Wireless Range
Note Non-Cisco client devices might have difficulty communicating with repeater access points. Figure 1-2 Access Point as Repeater Access Point (Root Unit) Wired LAN Access Point (Repeater) Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 26: Central Unit In An All-Wireless Network
Figure 1-3 shows an access point in an all-wireless network. Figure 1-3 Access Point as Central Unit in All-Wireless Network Access Point (Root Unit) Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 27: Chapter 2 Using The Management Interfaces
This chapter contains the following sections: Using the Web-Browser Interface, page 2-2 • Using the Command-Line Interface, page 2-5 • Using SNMP, page 2-10 • Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 28: Using The Web-Browser Interface
Using the Web-Browser Interface for the First Time Use the access point’s IP address to browse to the management system. See the Quick Start Guide: Cisco Aironet 1200 Series Access Points for instructions on assigning an IP address to the access point.
Page 29 Saves changes made on the page and return to the previous page. Cancel Discards changes to the page and return to the previous page. Restore Defaults Returns all settings on the page to their default values. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 30: Navigating Using The Map Windows
The Network Map window appears when you click Network Map in the Map window. You use the Network Map window to open a new browser window displaying information for any device on your wireless network. Figure 2-2 shows the Network Map window. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 31: Using The Command-Line Interface
You can use a command-line interface (CLI) to configure your access point through a terminal emulation program or a Telnet session instead of through your browser. This section provides instructions for Microsoft’s HyperTerminal and for Telnet; other programs are similar. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 32: Preparing To Use A Terminal Emulator
DB-9 to RJ-45 RJ-45 serial serial cable connector Note The Cisco part number for the DB-9 to RJ-45 serial cable is AIR-CONCAB1200. Browse to http://www.cisco.com/go/marketplace to order a serial cable. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 33: Setting Up The Terminal Emulator
Refreshes the page and cancel changes to settings. three times Ctrl-R Refreshes the page and cancel changes to settings. Returns to the home page without applying changes. :back Moves back one page without applying changes. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 34 You can also enter diagnostic commands in the CLI. See the “Using Command-Line Diagnostics” section on page 9-19 for information on the CLI diagnostic commands. Figure 2-4 shows a CLI page example. Figure 2-4 CLI Page Example Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 35: Selecting Pages And Settings
To start the Telnet session in Windows 2000, type open followed by the access point’s IP address. In the Host Name field, type the access point’s IP address and click Connect. Step 3 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 36: Using Snmp
The access point supports the following MIBs: Standard MIB-II (RFC1213-MIB.my) • Supported branches: system (1.3.6.1.2.1.1) – interfaces (1.3.6.1.2.1.2) – ip (1.3.6.1.2.1.4) – tcp (1.3.6.1.2.1.6) – – udp (1.3.6.1.2.1.7) snmp (1.3.6.1.2.1.11) – Cisco Aironet 1200 Series Access Point Software Configuration Guide 2-10 OL-2159-01...
Page 37 You can download the latest release of the access point MIB at the following URL: http://www.cisco.com/public/sw-center/sw-wireless.shtml IEEE802dot11-MIB.my: • Supported branch: ieee802dot11 (1.2.840.10036) – To download this MIB, browse to ftp://ftp.cisco.com/pub/mibs/v1/IEEE802dot11-MIB-V1SMI.my. Cisco Aironet 1200 Series Access Point Software Configuration Guide 2-11 OL-2159-01...
Page 38 Chapter 2 Using the Management Interfaces Using SNMP Cisco Aironet 1200 Series Access Point Software Configuration Guide 2-12 OL-2159-01...
Page 39: Configuration
Routing Setup, page 3-56 Association Table Display Setup, page 3-59 • • Event Notification Setup, page 3-65 Chapter 4, “Security Setup” for information on setting up the access point’s Note security features. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 40: Basic Settings
Express Setup page. Figure 3-1 Express Setup Page Follow this link path to reach the Express Setup page: On the Summary Status page, click Setup. On the Setup page, click Express Setup. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 41: Entering Basic Settings
The access point’s system serial number appears under the MAC address. The serial number is permanently assigned to the access point. You cannot change the serial number. The access point’s radio serial number appears on the AP Radio Identification page. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 42 255.255.255.255 indicates no gateway. Clicking the Gateway link takes you to the Routing Setup page, which contains detailed settings for configuring the access point to communicate with the IP network routing system. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 43 LAN. Figure 3-2 shows an access point operating as a root unit in a network. Figure 3-2 Root-Unit Access Points Access Point (Root Unit) Wired LAN Access Point (Root Unit) Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 44 Non-Cisco client devices might have difficulty communicating with Note repeater access points. Figure 3-3 Repeater Access Point Access Point (Root Unit) Wired LAN Access Point (Repeater) Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 45: Snmp Admin. Community
You use this setting to automatically configure the access point to be compatible with other devices on your wireless LAN. 2Mb/sec clients—Select this setting if your network contains Cisco Aironet • devices that operate at a maximum speed of 2 Mbps.
Page 46: Filter Setup
Follow this link path to reach the Ethernet Protocol Filters page: On the Summary Status page, click Setup. On the Setup page, click Filters in the Ethernet row under Network Ports. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 47: Creating A Protocol Filter
1 for the first filter set and incrementing by one for each additional set. Step 5 Click Add New. The Filter Set page appears. Figure 3-6 shows the Filter Set page. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 48 Special Cases entry field and click Add New. For example, to add Telnet to an IP port filter set, type telnet or 23. The Protocol Filter Set page appears. Figure 3-7 shows the Protocol Filter Set page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-10 OL-2159-01...
Page 49 Enter milliseconds in the Time-to-Live entry fields. If you leave these settings at Step 11 0, the protocol adopts the default time-to-live values you entered in Step Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-11 OL-2159-01...
Page 50 After defining the protocol filter set, follow the steps in the Enabling a Note Protocol Filter section to activate the filter. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-12 OL-2159-01...
Page 51: Enabling A Protocol Filter
CLI to disable the filters. Use the Address Filters page to create MAC address filters for the access point. Figure 3-8 shows the Address Filters page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-13 OL-2159-01...
Page 52: Creating A Mac Address Filter
Type a destination MAC address in the New MAC Address Filter: Dest MAC Step 2 Address field. You can type the address with colons separating the character pairs (00:40:96:12:34:56, for example) or without any intervening characters (004096123456, for example). Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-14 OL-2159-01...
Page 53 Click Advanced in the AP Radio row of the Network Ports section at the bottom of the Setup page. The AP Radio Advanced page appears. Figure 3-9 shows the AP Radio Advanced page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-15 OL-2159-01...
Page 54 MAC addresses except those listed as disallowed on the Address Filters page. Unicast packets are addressed to just one device on the network. Multicast packets are addressed to multiple devices on the network. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-16 OL-2159-01...
Page 55 If clients are not filtered immediately, click WARM RESTART SYSTEM NOW on the Manage System Configuration page to restart the access point. To reach the Manage System Configuration page, Click Cisco Services on the main Setup page and click Manage System Configuration on the Cisco Services Setup page.
Page 56: Radio Configuration
Entering Identity Information You use the AP Radio Identification page to enter basic locating and identity information for the access point radio. Figure 3-10 shows the AP Radio Identification page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-18 OL-2159-01...
Page 57: Settings On The Ap Radio Identification Page
The page also displays the access point’s MAC address, the radio serial number, the access point’s current IP address, its current IP subnet mask, its firmware version, and its boot block version. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-19 OL-2159-01...
Page 58 DHCP or BOOTP is enabled. If DHCP or BOOTP is enabled, this is the subnet mask used by the DHCP or BOOTP server. You can also enter this setting on the Express Setup page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-20 OL-2159-01...
Page 59: Entering Radio Hardware Information
You use the AP Radio Hardware page to assign settings related to the access point’s radio hardware. Figure 3-11 shows the AP Radio Hardware page. Figure 3-11 The AP Radio Hardware Page Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-21 OL-2159-01...
Page 60: Settings On The Ap Radio Hardware Page
Receive Antenna and Transmit Antenna The AP Radio Hardware page also contains a link to the AP Radio Data Encryption page, which you use to enter Wired Equivalent Privacy (WEP) settings. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-22 OL-2159-01...
Page 61 When you select yes from the world-mode pull-down menu, the access point adds channel carrier set information to its beacon. Client devices with world-mode enabled receive the carrier set information and adjust their settings automatically. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-23 OL-2159-01...
Page 62 Basic for 1 and 2 and set the rest of the data rates to Yes. Figure 3-13 shows the Data Rates set up for 1- and 2-Mbps service only. Figure 3-13 Data Rate Settings for 1- and 2-Mbps Service Only Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-24 OL-2159-01...
Page 63 Enter a setting ranging from 0 to 2339 bytes. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-25 OL-2159-01...
Page 64 DTIM every 200 Kµsecs. One Kµsec equals 1,024 microseconds. Radio Channel The factory setting for Cisco wireless LAN systems is Radio Channel 6 transmitting at 2437 MHz. To overcome an interference problem, other channel settings are available from the drop-down menu of 11 channels ranging from 2412 to 2462 MHz.
Page 65 The page lists all the channels in the access point’s regulatory domain. Click the Search check boxes beside the channels to include or exclude channels in the scan for less-congested channels. All the channels are included in the scan by default. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-27 OL-2159-01...
Page 66 When the access point used the north-pointing antenna, it would ignore client devices to the south. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-28 OL-2159-01...
Page 67: Entering Advanced Configuration Information
Use the AP Radio Advanced page to assign special configuration settings for the access point’s radio. Figure 3-15 shows the AP Radio Advanced page. Figure 3-15 AP Radio Advanced Page Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-29 OL-2159-01...
Page 68: Settings On The Ap Radio Advanced Page
Broadcast WEP Key rotation interval (sec) • Bridge Spacing • Accept Authentication Types • • Require EAP Default Unicast Address Filter • Specified Access Points • • Radio Modulation Radio Preamble • Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-30 OL-2159-01...
Page 69 MAC addresses listed as disallowed on the Address Filters page. Disallowed—The access point discards all traffic except packets sent to the • MAC addresses listed as allowed on the Address Filters page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-31 OL-2159-01...
Page 70 Use this entry field to specify the maximum number of wireless networking devices that are allowed to associate to the access point. The default setting, 0, means that the maximum possible number of associations is allowed. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-32 OL-2159-01...
Page 71 Configuration Radio Configuration Use Aironet Extensions Select yes or no to use Cisco Aironet 802.11 extensions. This setting must be set to yes (the default setting) to enable these features: • Load balancing—The access point uses Aironet extensions to direct client devices to an access point that provides the best connection to the network based on factors such as number of users, bit error rates, and signal strength.
Page 72 (IV) in encrypted packets to calculate the WEP key. WEP key hashing removes the predictability that an intruder relies on to determine the WEP key by exploiting IVs. Select Cisco from the pull-down menu and click Apply to enable WEP key hashing.
Page 73 WEP key and changes it at the interval you select. Broadcast key rotation is an excellent alternative to TKIP if your wireless LAN supports wireless client devices that are not Cisco devices or that cannot be upgraded to the latest firmware for Cisco client devices.
Page 74 With MAC addresses in these fields, the repeater access point always tries to associate with the specified access points instead of with other less-efficient access points. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-36 OL-2159-01...
Page 75: Ethernet Configuration
The pull-down menu allows you to select a long or short radio preamble: • Long—A long preamble ensures compatibility between the access point and all early models of Cisco Aironet Wireless LAN Adapters (PC4800 and PC4800A). Short—A short preamble improves throughput performance. Cisco Aironet's •...
Page 76: Entering Identity Information
On the Setup page, click Identification in the Ethernet row under Network Ports. Settings on the Ethernet Identification Page The Ethernet Identification page contains the following settings: Primary Port Settings • • Default IP Address Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-38 OL-2159-01...
Page 77 IP address. You can also enter this setting on the Express Setup and AP Radio Identification pages. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-39 OL-2159-01...
Page 78: Entering Ethernet Hardware Information
Follow this link path to reach the Ethernet Hardware page: On the Summary Status page, click Setup. On the Setup page, click Hardware in the Ethernet row under Network Ports. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-40 OL-2159-01...
Page 79: Settings On The Ethernet Hardware Page
• 100-Base-T / Full Duplex—Ethernet network connector for 100-Mbps transmission speed over twisted-pair wire and operating in full-duplex mode. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-41 OL-2159-01...
Page 80: Entering Advanced Configuration Information
Requested Status This setting is useful for troubleshooting problems on your network. Up, the default setting, enables the Ethernet port for normal operation. Down disables the access point’s Ethernet port. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-42 OL-2159-01...
Page 81 MAC addresses listed as disallowed on the Address Filters page. Disallowed—The access point discards all traffic except packets sent to the • MAC addresses listed as allowed on the Address Filters page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-43 OL-2159-01...
Page 82: Server Setup
Entering Name Server Settings, page 3-53 Entering FTP Settings, page 3-55 • See the “Enabling EAP on the Access Point” section on page 4-19 for instructions Note on setting up the authentication server. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-44 OL-2159-01...
Page 83: Entering Time Server Settings
The Time Server Setup page contains the following settings: • Simple Network Time Protocol • Default Time Server GMT Offset (hr) • • Use Daylight Savings Time Manually Set Date and Time • Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-45 OL-2159-01...
Page 84 When entering the date and time, use forward-slashes to separate the year, month, and day, and use colons to separate the hours, minutes, and seconds. For example, you would enter 2001/02/17 for February 17, 2001, and 18:25:00 for 6:25 pm. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-46 OL-2159-01...
Page 85: Entering Boot Server Settings
On the Setup page, click Boot Server under Services. Settings on the Boot Server Setup Page The Boot Server Setup page contains the following settings: Configuration Server Protocol • Use Previous Configuration Server Settings • Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-47 OL-2159-01...
Page 86 Always—The access point always loads configuration settings from an .ini file on the server. • Never—The access point never loads configuration settings from an .ini file on the server. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-48 OL-2159-01...
Page 87 This setting specifies the shortest amount of time the access point accepts for an IP address lease. The access point ignores leases shorter than this period. Enter the minimum number of minutes the access point should accept for a lease period. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-49 OL-2159-01...
Page 88: Entering Web Server Settings And Setting Up Access Point Help
Figure 3-21 Web Server Setup Page Follow this link path to reach the Web Server Setup page: On the Summary Status page, click Setup. On the Setup page, click Web Server under Services. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-50 OL-2159-01...
Page 89: Settings On The Web Server Setup Page
The online help files are provided on the access point and bridge CD in the Help directory. You can point to the help files in one of four possible locations: Internet—Cisco maintains up-to-date help for access points on the Cisco • website. While this location requires online access for every occasion of needing online help, it offers the most up-to-date information.
Page 90 This setting points to the access point management system’s HTML pages. If you create alternative HTML pages, you should change this setting to point to the alternative pages. The default setting is: mfs0:/StdUI/ Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-52 OL-2159-01...
Page 91: Entering Name Server Settings
Follow this link path to reach the Name Server Setup page: On the Summary Status page, click Setup • • On the Setup page, click Name Server under Services. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-53 OL-2159-01...
Page 92: Settings On The Name Server Setup Page
In this entry field, enter the portion of the full domain name that you would like omitted from access point displays. For example, in the domain “mycompany.com” the full name of a computer might be Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-54 OL-2159-01...
Page 93: Entering Ftp Settings
Settings on the FTP Setup Page The FTP Setup page contains the following settings: File Transfer Protocol • Default File Server • FTP Directory • FTP User Name • • FTP User Password Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-55 OL-2159-01...
Page 94: Routing Setup
IP network routing system. You use the page settings to specify the default gateway and to build a list of installed network route settings. Figure 3-24 shows the Routing Setup page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-56 OL-2159-01...
Page 95: Entering Routing Settings
New Network Route Settings • Installed Network Routes list • Default Gateway Enter the IP address of your network’s default gateway in this entry field. The entry 255.255.255.255 indicates no gateway. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-57 OL-2159-01...
Page 96 Subnet Mask—Enter the subnet mask associated with the destination network. Installed Network Routes list The list of installed routes provides the destination network IP address, the gateway, and the subnet mask for each installed route. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-58 OL-2159-01...
Page 97: Association Table Display Setup
The buttons include: • Apply—Applies your selections to the Association Table and returns you to the Association Table page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-59 OL-2159-01...
Page 98: Settings On The Association Table Filters Page
Assoc—The station is associated with an access point. Unauth—The station is unauthenticated with any access point. – Auth—The station is authenticated with an access point. – • IP Address—A device’s IP address. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-60 OL-2159-01...
Page 99 Select Alert to display the number of alert bytes to and from each station on the wireless network. Both selections add a column to the Association Table. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-61 OL-2159-01...
Page 100: Association Table Advanced Page
Association Table and the amount of time the access point continues to track each device class when a device is inactive. Figure 3-26 shows the Association Table Advanced page. Figure 3-26 Association Table Advanced Page Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-62 OL-2159-01...
Page 101: Settings On The Association Table Advanced Page
(that is, the port has been turned off, the rate setting has been changed, etc.) and appear in green in the Event Log. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-63 OL-2159-01...
Page 102 A setting of zero tells the access point to track a device indefinitely no matter how long it is inactive. A setting of 300 equals 5 minutes; 1800 equals 30 minutes; 28800 equals 8 hours. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-64 OL-2159-01...
Page 103: Event Notification Setup
Figure 3-27 The Event Display Setup Page Follow this link path to reach the Event Display Setup page: On the Summary Status page, click Setup. On the Setup page, click Display Defaults under Event Log. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-65 OL-2159-01...
Page 104: Settings On The Event Display Setup Page
“Event Handling Setup Page” section on page 3-68 for details.) Use the pull-down menus to choose one of the sixteen severity levels for each display area. Table 3-1 lists the severity levels. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-66 OL-2159-01...
Page 105 HTTP or IP. Port refers to the access point’s Ethernet or radio • network interface. External refers to a device on the network other • than the access point. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-67 OL-2159-01...
Page 106: Event Handling Setup Page
You use the Event Handling Setup page to determine how notification of the fatal, alert, warning, and information events should occur. You can choose to only count the events, display them to the console but not store them, record them after Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-68 OL-2159-01...
Page 107 Figure 3-28 shows the Event Handling Setup page. Figure 3-28 The Event Handling Setup Page Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-69 OL-2159-01...
Page 108: Settings On The Event Handling Setup Page
• display of the event. Notify—Makes a record of the event in the log, displays the event, and tells • the access point to notify someone of the occurrence. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-70 OL-2159-01...
Page 109 Clear Alert Statistics Click this button to reset the alert tallies to 0. Purge Trace Buffer Click this button to delete the packet traces from the Event Trace Buffer. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-71 OL-2159-01...
Page 110: Event Notifications Setup Page
Figure 3-29 Event Notifications Setup Page Follow this link path to reach the Event Notifications Setup page: On the Summary Status page, click Setup. On the Setup page, click Event Notifications under Event Log. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-72 OL-2159-01...
Page 111: Settings On The Event Notifications Setup Page
Type the SNMP community name. This setting also appears on the SNMP Setup page. Should Notify-Disposition Events generate Syslog Messages? Select yes to send event notifications to a Syslog server. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-73 OL-2159-01...
Page 112 This default syslog destination is only used if the syslog destination address field is blank. Syslog Facility Number Type the Syslog Facility number for the notifications. The default setting is 16, which corresponds to the Local0 facility code. Cisco Aironet 1200 Series Access Point Software Configuration Guide 3-74 OL-2159-01...
Page 113: Security Setup
Setting Up MAC-Based Authentication, page 4-28 Summary of Settings for Authentication Types, page 4-34 • • Setting Up Backup Authentication Servers, page 4-37 Setting Up Administrator Authorization, page 4-38 • Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 114: Security Overview
Figure 4-1 shows possible levels of security on Cisco Aironet wireless networking equipment, from no security on the left to highest security on the right. The highest level of security, EAP authentication, interacts with a Remote Authentication Dial-In User Service (RADIUS) server on your network to provide authentication service for wireless client devices.
Page 115: Encrypting Radio Signals With Wep
Because WEP (Wired Equivalent Privacy) is the first line of defense against intruders, Cisco recommends that you use full encryption on your wireless network.
Page 116: Network Authentication Types
WEP key and changes it at the interval you select. Broadcast key rotation is an excellent alternative to TKIP if your wireless LAN supports wireless client devices that are not Cisco devices or that cannot be upgraded to the latest firmware for Cisco client devices. See the “Enabling Broadcast...
Page 117 RADIUS server creates its own response and compares that to the response from the client. When the RADIUS server authenticates the client, the process repeats in reverse, and the client authenticates the RADIUS server. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 118 EAP capability. See “Setting Up MAC-Based Authentication” section on page 4-28 instructions on enabling MAC-based authentication. Figure 4-3 shows the authentication sequence for MAC-based authentication. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 119 1. Authentication request 2. Authentication response • Shared key—Cisco provides shared key authentication to comply with the IEEE 802.11b standard. However, because of shared key’s security flaws, we recommend that you avoid using it. Cisco Aironet 1200 Series Access Point Software Configuration Guide...
Page 120: Protecting The Access Point Configuration With User Manager
You create a list of administrators authorized to view and adjust the access point settings; unauthorized users are locked out. See the “Setting Up Administrator Authorization” section on page 4-38 for instructions on using the user manager. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 121: Setting Up Wep
Follow this link path to reach the AP Radio Data Encryption page: On the Summary Status page, click Setup. On the Setup page, click Security. On the Security Setup page, click Radio Data Encryption (WEP). Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 122 WEP key lists. However, the key does not have to be selected as the transmit key in the client devices’ WEP key lists. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-10 OL-2159-01...
Page 123 You must set a WEP key before enabling WEP. The options in the Use of Note Data Encryption by Stations is pull-down menu do not appear until you set a key. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-11 OL-2159-01...
Page 124: Using Snmp To Set Up Wep
Optional—Client devices can communicate with the access point either with • or without WEP. If you select Optional, Cisco Aironet client devices associating to the Note access point must be configured to allow association to mixed cells. See the Cisco Aironet Wireless LAN Adapters Software Configuration Guide for instructions on configuring Cisco Aironet client devices.
Page 125: Enabling Additional Wep Security Features
The MIC, implemented on both the access point and all associated client devices, adds a few bytes to each packet to make the packets tamper-proof. Note You must set up and enable WEP with full encryption before MIC takes effect. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-13 OL-2159-01...
Page 126 (the default setting). Use the AP Radio Advanced page to enable MIC. Figure 4-7 shows the AP Radio Advanced page. Figure 4-7 AP Radio Advanced Page Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-14 OL-2159-01...
Page 127: Enabling Temporal Key Integrity Protocol (Tkip)
(IV) in encrypted packets to calculate the WEP key. TKIP removes the predictability that an intruder relies on to determine the WEP key by exploiting IVs. TKIP protects both unicast and broadcast WEP keys. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-15 OL-2159-01...
Page 128 On the Summary Status page, click Setup. On the Setup page, click Advanced in the AP Radio row under Network Ports. Select Cisco from the Temporal Key Integrity Protocol pull-down menu. Step 3 Make sure yes is selected for the Use Aironet Extensions setting. Key hashing Step 4 does not work if Use Aironet Extensions is set to no.
Page 129: Enabling Broadcast Wep Key Rotation
Broadcast key rotation is an excellent alternative to TKIP if your wireless LAN supports wireless client devices that are not Cisco devices or that cannot be upgraded to the latest firmware for Cisco client devices. When you enable broadcast key rotation, only wireless client devices using LEAP Note or EAP-TLS authentication can use the access point.
Page 130: Setting Up Open Or Shared Key Authentication
Selecting the Require EAP check box also allows client devices using various types of EAP authentication, including EAP-TLS and EAP-MD5, to authenticate through the access point. To allow LEAP-enabled Cisco Aironet client devices to authenticate through the access point, you should also select Network-EAP. See “Setting Up EAP Authentication”...
Page 131: Setting Up Eap Authentication
EAP authentication. Figure 4-6 shows the AP Radio Data Encryption page. Figure 4-8 shows the Authenticator Configuration page. Figure 4-8 Authenticator Configuration Page Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-19 OL-2159-01...
Page 132 Functionality in Draft 10 is equivalent to the functionality in Draft 11, the ratified draft of the 802.1X standard. Table 4-3 lists the radio firmware versions and the drafts with which they comply. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-20 OL-2159-01...
Page 133 Enter the port number your RADIUS server uses for authentication. The default Step 4 setting, 1812, is the port setting for Cisco’s RADIUS server, the Cisco Secure Access Control Server (ACS), and for many other RADIUS servers. Check your server’s product documentation to find the correct port setting.
Page 134 Step 7 Select EAP Authentication under the server. The EAP Authentication check box designates the server as an authenticator for any EAP type, including Cisco Aironet LEAP, EAP-TLS, and EAP-MD5. Click OK. You return automatically to the Security Setup page.
Page 135 If the key in slot 1 is the only WEP key set up, select it as the transmit key. Step 14 Click OK. You return automatically to the Security Setup page. Step 15 Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-23 OL-2159-01...
Page 136: Enabling Eap In Cisco Secure Acs
Step 5 In the Key box, type the shared secret that the TACACS+ or RADIUS NAS and Cisco Secure ACS use to encrypt the data. For correct operation, the identical key (case sensitive) must be configured on the access point’s Authenticator Configuration page and in Cisco Secure ACS.
Page 137: Setting A Session-Based Wep Key Timeout
You should consider several factors when determining the best session key timeout value for your wireless network. Consult Product Bulletin 1515: Cisco Wireless LAN Security Bulletin for guidelines on selecting timeout values. Use this URL to browse to Product Bulletin 1515: http://www.cisco.com/warp/public/cc/pd/witc/ao350ap/prodlit/1515_pp.htm...
Page 138: Setting Up A Repeater Access Point As A Leap Client
LAN), you can set up the repeater access point to authenticate to your network like other wireless client devices. After you provide a network username and password for the repeater access point, it authenticates to your network using LEAP, Cisco’s wireless authentication method, and receives and uses dynamic WEP keys. See the “Setting Up a Repeater Access Point”...
Page 139 RADIUS server is not set up correctly, you must reboot the repeater access point after correcting the problem. The repeater access point does not attempt to reauthenticate until it reboots. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-27 OL-2159-01...
Page 140: Setting Up Mac-Based Authentication
Follow this link path to reach the Address Filters page: On the Summary Status page, click Setup. On the Setup page, click Address Filters under Associations. Figure 4-10 shows the Address Filters page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-28 OL-2159-01...
Page 141 The MAC address remains in the management system until you remove it. To remove the MAC address from the list, select it and click Remove. Be sure to enter your own MAC address in the list of allowed addresses. Note Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-29 OL-2159-01...
Page 142 Enter the name or IP address of the authentication server in the Server Name/IP Step 7 entry field. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-30 OL-2159-01...
Page 143 Enter the port number the server uses for authentication. The default setting, Step 8 1812, is the port setting for Cisco’s RADIUS server, the Cisco Secure Access Control Server (ACS), and for many other RADIUS servers. Check your server’s product documentation to find the correct port setting.
Page 144 Disallowed but leave Default Unicast Address Filter under Network-EAP set to Allowed. This configuration forces client devices using open authentication to authenticate using MAC addresses but does not force LEAP-enabled client Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-32 OL-2159-01...
Page 145: Enabling Mac-Based Authentication In Cisco Secure Acs
The authentication server’s list of allowed MAC addresses can reside on the authentication server or at any network location to which the server has access. Follow these steps to create a list of allowed MAC addresses in Cisco Secure ACS: Step 1 On the ACS main menu, click User Setup.
Page 146: Summary Of Settings For Authentication Types
If your server allows case-sensitive usernames and passwords, you must enter MAC addresses in the server’s database using lower-case characters. When the User Setup screen appears, enter the MAC address in the Cisco Secure Step 3 PAP Password and Confirm Password entry fields.
Page 147 Selecting Require EAP blocks non-EAP client devices from Note using the access point. • Enter a WEP key in key slot 1 and select 128-bit from the key size pull-down menu. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-35 OL-2159-01...
Page 148 Select Disallowed from the pull-down menu for Default Unicast • Address Filter for each authentication type requiring MAC-based authentication. MAC-based and LEAP Enter the settings for LEAP. • Enter the settings for MAC-based authentication. • Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-36 OL-2159-01...
Page 149: Setting Up Backup Authentication Servers
Enter the port number the server uses for authentication. The default setting, 1812, is the port setting for Cisco’s RADIUS server, the Cisco Secure Access Control Server (ACS), and for many other RADIUS servers. Check your server’s product documentation to find the correct port setting.
Page 150: Setting Up Administrator Authorization
Creating a list of users authorized to view and change the access point Note management system does not affect the ability of client devices to associate with the access point. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-38 OL-2159-01...
Page 151: Creating A List Of Authorized Management System Users
Follow the link path to the Security Setup page. Step 1 On the Security Setup page, click User Information. Figure 4-15 shows the User Step 2 Information page. Figure 4-15 User Information Page Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-39 OL-2159-01...
Page 152 Ident—The user can change the access point's identity settings (IP address • and SSID). When you assign Ident capability to a user, the user also automatically receives Write and Admin capabilities. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-40 OL-2159-01...
Page 153 Allow Read-Only Browsing without Login—Select yes to allow any user to view the access point’s basic screens. Select no to restrict access to all of the access point’s screens to only the users in the user list. Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-41 OL-2159-01...
Page 154 Select no to allow any user to view the Legal Credits page. Click OK. You return automatically to the Security Setup page. Step 9 Cisco Aironet 1200 Series Access Point Software Configuration Guide 4-42 OL-2159-01...
Page 155: Network Management
Network Management This section describes how to browse to other devices on your network, how to use Cisco Discovery Protocol with your wireless networking equipment, how to assign a specific network port to a MAC address, and how to enable wireless network accounting.
Page 156: Using The Association Table
To browse to a device’s browser-based interface, click the device’s IP address in the IP Addr. column. The home page of the device’s management system appears. Cisco Aironet access points, bridges, and workgroup bridges have browser-based interfaces, and many servers and printers have them, also.
Page 157: Setting The Display Options
Station page for a PC card client adapter. You can also use the Station page to perform pings and link tests for network devices. Figure 5-2 shows a sample Station page for a PC card client adapter. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 158 Chapter 5 Network Management Using the Association Table Figure 5-2 Station Page 209.165.201.5 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 159: Information On Station Pages
IP Address—The device’s IP address. • When you click the IP address link, the browser attempts to display the device’s home page. Cisco Aironet access points, bridges, and workgroup bridges have browser-based interfaces, and many servers and printers have them also.
Page 160 RTS (Short) Retries—Reports the number of times the RTS packet had to be • retried. Data (Long) Retries—Reports the number of times the data packet had to be • retried. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 161 Latest Signal Strength—Displays the current index of radio signal quality. • The following four fields appear only on the Station page for an access point: • Stations Associated—Displays, by number and class, all stations associated with the access point. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 162: Performing Pings And Link Tests
Network Management Using the Association Table Uptime—Displays the cumulative time the device has been operating since • the last reset. Software Version—Displays the version level of Cisco software on the • device. • Announcement Packets—Total number of Announcement packets since the device was last reset.
Page 163 Number of Pkts. and Pkt. Size fields. Click Link Test. Step 2 The link test runs using the values in the Number of Pkts. and Pkt. Size fields. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 164: Clearing And Updating Statistics
Clear Stats—Clears all packet, octet and error counts and resets the counters • to 0. Refresh—Updates the counts to their latest accumulated values, and saves the • Alert selections. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-10 OL-2159-01...
Page 165: Deauthenticating And Disassociating Client Devices
Table, the Network Map window does not list wired devices on your LAN. Figure 5-5 shows the Network Map window. Note Your Internet browser must have Java enabled to use the map windows. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-11 OL-2159-01...
Page 166 Click show clients to display all the wireless client devices on your network. The client names appear under the access point or bridge with which they are associated. If clients are displayed, click hide clients to display only non-client devices. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-12 OL-2159-01...
Page 167: Using Cisco Discovery Protocol
Using Cisco Discovery Protocol Using Cisco Discovery Protocol Cisco Discovery Protocol (CDP) is a device-discovery protocol that runs on all Cisco network equipment. Each device sends identifying messages to a multicast address, and each device monitors the messages sent by other devices.
Page 168: Settings On The Cdp Setup Page
CDP packets through its radio port and monitors the radio for CDP packets from other devices. MIB for CDP A MIB file is available for use with CDP. The filename is CISCO-CDP-MIB.my, and you can download the MIB at the following URL: http://www.cisco.com/public/mibs...
Page 169 Follow this link path to reach the Port Assignments page: On the Summary Status page, click Setup. On the Setup page, click Port Assignments in the Association section near the top of the page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-15 OL-2159-01...
Page 170: Settings On The Port Assignments Page
RADIUS server on your network. Cisco Secure ACS writes accounting records to a log file or to a database daily. Consult the Cisco Secure ACS 2.6 for Windows 2000/NT Servers User Guide for instructions on viewing and downloading the log or database: http://www.cisco.com/univercd/cc/td/doc/product/access/acs_soft/csacs4nt/csnt2...
Page 171: Settings On The Accounting Setup Page
The delay reduces accounting activity for client devices that disassociate from the access point and then quickly reassociate. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-17 OL-2159-01...
Page 172 • Port—The communication port setting used by the access point and the server. The default setting, 1813, is the correct setting for Cisco Aironet access points and Cisco secure ACS. Timeout (sec.)—Enter the number of seconds the access point should wait •...
Page 173: Accounting Attributes
The method with which the client device is authenticated to the network. This value is always 1, which represents RADIUS authentication. The access point sends this attribute to the server with all three status types. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-19 OL-2159-01...
Page 174 Acct-Terminate-Cause How the client device’s session was terminated. This attribute lists the same cause for every disassociated client device: Loss of service. The access point sends this attribute only with the ACCT_STOP status type. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-20 OL-2159-01...
Page 175 RADIUS_IPADR The IP address of the access point sending the accounting information. The access point sends this attribute to the server with all three status types. Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-21 OL-2159-01...
Page 176 Chapter 5 Network Management Enabling Wireless Network Accounting Cisco Aironet 1200 Series Access Point Software Configuration Guide 5-22 OL-2159-01...
Page 177: Chapter 6 Managing Firmware And Configurations
You use the Cisco Services Setup page as a starting point for all these activities.
Page 178: Updating Firmware
Updating Firmware Updating Firmware You use the Cisco Services Setup page to update the access point’s firmware. You can perform the update by browsing to a local drive or by using FTP to update the firmware from a file server.
Page 179: Full Update Of The Firmware Components
Full Update of the Firmware Components To update all the firmware components at the same time, click Through Browser on the Fully Update Firmware line on the Cisco Services Setup page. The Update All Firmware Through Browser page appears. Figure 6-2 shows the Update All Firmware Through Browser page.
Page 180: Selective Update Of The Firmware Components
Updating Firmware Selective Update of the Firmware Components To update firmware components individually, click Through Browser on the Selectively Update Firmware line on the Cisco Services Setup page. The Update Firmware Through Browser page appears. Figure 6-3 shows the Update Firmware Through Browser page.
Page 181: Updating From A File Server
Full Update of the Firmware Components To update all the firmware components at the same time, click From File Server on the Fully Update Firmware line on the Cisco Services Setup page. The Update All Firmware From File Server page appears.
Page 182 New File for All Firmware entry field. Step 4 Click Browser Update Now to load and install the new firmware. When the update is complete, the access point automatically reboots. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 183: Selective Update Of The Firmware Components
Updating Firmware Selective Update of the Firmware Components To update firmware components individually, click From File Server on the Selectively Update Firmware line on the Cisco Services Setup page. The Update Firmware From File Server page appears. Figure 6-6 shows the Update Firmware From File Server page.
Page 184: Distributing Firmware
Follow this link path in the browser interface to reach the Distribute Firmware page: On the Summary Status page, click Setup. On the Setup page, click Cisco Services Setup. On the Cisco Services page, click Distribute Firmware to other Cisco Devices. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 185: Distributing A Configuration
If they have User Manager enabled, contain in their User Lists a user with the • same user name, password, and capabilities as the user performing the distribution (the person logged in on the distributing access point) Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 186: Downloading, Uploading, And Resetting The Configuration
On the Summary Status page, click Setup. On the Setup page, click Cisco Services Setup. On the Cisco Services page, click Distribute Configuration to other Cisco Devices. Follow these steps to distribute the access point’s configuration to other access...
Page 187: Downloading The Current Configuration
Click Download System Configuration Except IP Identity to save an .ini • file containing the current configuration except for the access point’s IP address. Cisco Aironet 1200 Series Access Point Software Configuration Guide 6-11 OL-2159-01...
Page 188: Uploading A Configuration
When the filename appears in the Additional System Configuration File entry Step 3 field, click Browser Update Now. The configuration file is loaded and applied in the access point. Cisco Aironet 1200 Series Access Point Software Configuration Guide 6-12 OL-2159-01...
Page 189: Uploading From A File Server
In the FTP User Name entry field, enter the user name assigned to the FTP server. If you selected TFTP, you can leave this field blank. Cisco Aironet 1200 Series Access Point Software Configuration Guide 6-13 OL-2159-01...
Page 190: Resetting The Configuration
– The access point’s IP address, subnet mask, default gateway, and boot protocol – The users in the User Manager list – The SNMP Administrator Community name Cisco Aironet 1200 Series Access Point Software Configuration Guide 6-14 OL-2159-01...
Page 191: Restarting The Access Point
Click “Cold” Restart System Now to perform a cold restart of the access • point. A cold restart is the equivalent of removing and then reapplying power for the access point. Cisco Aironet 1200 Series Access Point Software Configuration Guide 6-15 OL-2159-01...
Page 192 Chapter 6 Managing Firmware and Configurations Downloading, Uploading, and Resetting the Configuration Cisco Aironet 1200 Series Access Point Software Configuration Guide 6-16 OL-2159-01...
Page 193: Chapter 7 Management System Setup
This chapter explains how to set up your access point to use SNMP, Telnet, or the console port to manage the access point. This chapter contains the following sections: SNMP Setup, page 7-2 • Console and Telnet Setup, page 7-5 • Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 194: Snmp Setup
The SNMP Setup page contains the following settings: Simple Network Management Protocol (SNMP)—Select Enabled to use • SNMP with the access point. System Description—The system's device type and current version of • firmware. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 195: Using The Database Query Page
On the Summary Status page, click Setup. On the Setup page, click SNMP in the Services section of the page. On the SNMP Setup page, click Browse Management Information Base (MIB). Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 196: Settings On The Database Query Page
Step 3 Click Set. The new value is set on the access point. Step 4 If the object is read-only, the value is not changed when you click Set. Note Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 197: Console And Telnet Setup
• Parity—An error-detecting process based on the addition of a parity bit to make the total number of bits Odd or Even. The default setting, None, uses no parity bit. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 198 16 characters to 50 characters. Adjust the value to get the optimum display for your terminal emulator. Enable Telnet—The default setting is Yes. Select No to prevent Telnet access • to the management system. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 199: Chapter 8 Special Configurations
Ethernet port does not forward traffic. Figure 8-1 shows an access point acting as a repeater. Non-Cisco client devices might have difficulty communicating with repeater Note access points. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 200 Omni-directional antennas, like the ones that ship with your access point, are best suited for repeater access points. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 201 Follow these steps to set up a repeater access point: Step 1 Use the Quick Start Guide: Cisco Aironet Access Points and the information in this manual to set up an access point as a root unit on the wired LAN.
Page 202 If the repeater will use the DHCP server, skip to Step On the Express Setup page, enter a fixed IP address for the repeater access point Step 12 in the Default IP address field. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 203 1/8 of a second when it is associated with the root access point but has no client devices associated with it. The repeater access point should also appear as associated with the root access point in the root access point’s Association Table. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 204: Using Hot Standby Mode
On the Setup page, click Cisco Services under Services. • • On the Cisco Services Setup page, click Hot Standby Management. Note Wireless client devices associated to the standby access point lose their connections during the hot standby setup process.
Page 205: Using Hot Standby Mode
Click the browser’s refresh button to verify that the Current State line on the Hot Step 10 Standby Setup page states that Hot Standby is initialized. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 206 The standby access point does not revert to standby mode automatically. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 207: Chapter 9 Diagnostics And Troubleshooting
This chapter describes the diagnostic pages in the management system and provides troubleshooting procedures for basic problems with the access point. For the most up-to-date, detailed troubleshooting information, refer to the Cisco TAC website at http://www.cisco.com/tac. Select Wireless LAN under Top Issues.
Page 208: Radio Diagnostics Page
Follow this link path to reach the Radio Diagnostics page: On the Summary Status page, click Diagnostics in the Network Ports row. On the Cisco Network Diagnostics page, click Radio Diagnostics Tests. Cisco Aironet 1200 Series Access Point Software Configuration Guide...
Page 209: Antenna Alignment Test
Wireless networking devices with the same SSID as the access point send probe responses to the access point, and the access point measures the quality of the signal between the devices. Figure 9-2 shows an example Antenna Alignment Test window. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 210 The left side of the Strength column displays the percentage of signal strength between the access point and the other device, and the right side of the column displays signal strength in dBm. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 211: Carrier Test
Carrier Test window. The access point drops all associations with wireless networking devices during Note the carrier test. Figure 9-3 shows an example Carrier Test window. Figure 9-3 Carrier Test Window Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 212: Network Ports Page
The Network Ports page contains a table listing information for the access point’s Ethernet and radio ports. Figure 9-4 shows a Network Ports page example. Figure 9-4 Network Ports Page Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 213: Identifying Information And Status
The Network Diagnostics link at the top of the Network Ports page leads to the Cisco Network Diagnostics page, where you can select diagnostic tests. The Network Ports table is divided into three sections: identifying information and status, data received, and data transmitted. Each row in the table is described below.
Page 214: Data Received
Discards—The number of packets discarded by the access point due to errors or network congestion. Forwarded pkts.—The number of packets transmitted by the port that was • acceptable or passable through the filters. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 215: Ethernet Port Page
Ethernet Port Page 172.16.24.0 Like the Network Ports page, the Ethernet Port page lists statistics in a table divided into sections. Each row in the table is explained in the following sections. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 216 Filtered Packets—Packets that were stopped or screened by the filters set up • on the port. Packet CRC Errors—Cyclic redundancy check (CRC) errors that were • detected in a received packet. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-10 OL-2159-01...
Page 217 • problems. Could also indicate a failing NIC card. Underrun Packets—Packets failed to be sent because the access point was • unable to keep up with the Ethernet controller. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-11 OL-2159-01...
Page 218: Ap Radio Page
Like the Network Ports and Ethernet Port pages, the AP Radio Port page lists statistics in a table divided into sections. Each row in the table is explained below. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-12 OL-2159-01...
Page 219 Hardware Information” section on page 3-21 for details on the AP Radio Hardware page. • Status of “awc0”—awc0 (Aironet Wireless Communications) is part of Cisco Aironet's naming convention for this radio. This field displays one of three possible operating states: Up—The port is operating properly.
Page 220 Hardware page, where you can set the maximum RTS value. Total Retries—The total number of retries that occurred through the radio • port. • Canceled Assoc. Lost—Packets dropped because a client device lost association with the access point. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-14 OL-2159-01...
Page 221 Detailed Stats.—Twenty additional statistical fields covering packet • fragments, collisions, and other errors. Individual Rates—Data transmission statistics for each data rate (1, 2, 5, and • 11 Mbps). Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-15 OL-2159-01...
Page 222: Event Log Page
Next—Displays earlier events in the log. Prev—Displays more recent events in the log. • • Apply New—Changes the display by applying the settings in the Index and Number of Events fields. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-16 OL-2159-01...
Page 223: Log Headings
In Netscape Communicator, the log file is displayed on the screen, and you select Save As from Communicator’s File pull-down menu to save the log. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-17 OL-2159-01...
Page 224: Event Log Summary Page
Event Log Summary page example. Figure 9-8 Event Log Summary Page Click the Severity heading on the Event Log page to reach the Event Log Summary page. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-18 OL-2159-01...
Page 225: Using Command-Line Diagnostics
IP statistics :vxdiag_memshow free and allocated memory on the access point :vxdiag_muxshow networking protocols installed on the access point :vxdiag_routeshow current routing information :vxdiag_tcpstatshow TCP statistics :vxdiag_udpstatshow UDP statistics Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-19 OL-2159-01...
Page 226: Entering Diagnostic Commands
Enter the command (for example, :vxdiag_memshow) and press Enter. The Step 5 command’s diagnostic information appears. Diagnostic Command Results This section describes the information displayed on the CLI for the diagnostic commands listed in Table 9-1. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-20 OL-2159-01...
Page 227: Eap_Diag1_On
6b 69 64 3d 45 41 50 33 2c 6e 61 73 69 64 3d 45 *kid=EAP3,nasid=E* 00c15750: 41 50 33 2c 70 6f 72 74 69 64 3d 30 *AP3,portid=0..* Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-21 OL-2159-01...
Page 228: Vxdiag_Arpshow
• • Flags—see Table 9-2 for a list of flags Table 9-2 Flag Definitions Flag Value Definition Route is usable. Destination is a gateway. Host of specific routing entry. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-22 OL-2159-01...
Page 229 – Follow the steps in the “Entering Diagnostic Commands” section on page 9-20 open the CLI and enter the :vxdiag_arpshow command. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-23 OL-2159-01...
Page 230: Vxdiag_Checkstack
Margin—the difference between the stack size and the highest number of • bytes which have been in use Follow the steps in the “Entering Diagnostic Commands” section on page 9-20 open the CLI and enter the :vxdiag_checkstack command. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-24 OL-2159-01...
Page 231: Vxdiag_Hostshow
Aliases—List of additional names, other than the hostname, that refer to the Inet address Follow the steps in the “Entering Diagnostic Commands” section on page 9-20 open the CLI and enter the :vxdiag_hostshow command. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-25 OL-2159-01...
Page 232: Vxdiag_I
PC—program counter; a memory address of the task • SP—stack pointer; another memory address of the task ERRNO—error number; the latest error reported by any function called by • the task Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-26 OL-2159-01...
Page 233: Vxdiag_Ipstatshow
Badhlen—number of packets received with IP header length less than the packet data size • Badlen—number of packets received with IP length less than the IP header length • Infragments—number of packets received that were fragmented Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-27 OL-2159-01...
Page 234: Vxdiag_Memshow
• bytes—the memory for each status described in bytes blocks—the memory for each status described in contiguous blocks; indicates • the level of fragmentation in the access point’s memory Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-28 OL-2159-01...
Page 235: Vxdiag_Muxshow
Type: 34605 Recv 0x6986c Shutdown 0x6a728 Device: rptr Unit: 2 Follow the steps in the “Entering Diagnostic Commands” section on page 9-20 open the CLI and enter the :vxdiag_muxshow command. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-29 OL-2159-01...
Page 236: Vxdiag_Routeshow
– Follow the steps in the “Entering Diagnostic Commands” section on page 9-20 open the CLI and enter the :vxdiag_routeshow command. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-30 OL-2159-01...
Page 237: Vxdiag_Tcpstatshow
0 connection dropped by keepalive 63 pcb cache lookups failed Follow the steps in the “Entering Diagnostic Commands” section on page 9-20 open the CLI and enter the :vxdiag_tcpstatshow command. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-31 OL-2159-01...
Page 238: Vxdiag_Udpstatshow
You can save packet traces in a log file that you view or save, or you can view packets on the access point command-line interface without storing the traces in a log file. Use the instructions in this section to reserve access point memory for Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-32 OL-2159-01...
Page 239: Tracing Packets For Specific Devices
Browse to the access point’s Association Table. You can reach the Association Table by clicking Current Associations on the Summary Status page or by clicking the gray Associations button at the top of most management system pages. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-33 OL-2159-01...
Page 240: Tracing Packets For Ethernet And Radio Ports
Network Ports page. Browse to the Network Ports page by clicking Current Associations on the Summary Status page or by clicking the gray Network button at the top of most management system pages. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-34 OL-2159-01...
Page 241: Viewing Packet Trace Data
If you store traced packets in a log file, you can view or save the file. If you do not store traced packets, you can view the packets in real time on the access point CLI. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-35 OL-2159-01...
Page 242: Packets Stored In A Log File
04:49:06 + 0.019231 Station Alert: 00:01:64:43:ef:41Aironet:40:6f:e600:05:31:d3:c0:09IP IPv4 UDP ID=0x14f3 totalLen=96 10.84.139.164 -> ne-wins.cisco.com 04:49:06 + 0.192308 Station Alert: 00:05:31:d3:c0:0900:01:64:43:ef:41IP IPv4 UDP ID=0xb2b4 totalLen=90 ne-wins.cisco.com -> 10.84.139.164 ===End of AP_North Detailed Trace Log=== Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-36 OL-2159-01...
Page 243: Packets Displayed On The Cli
If your access point is not communicating, check the three indicators on the top panel. The indicators report the unit’s status. Figure 9-9 shows the indicators on top of the access point. Table 9-3 lists the meanings of the indicator signals. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-37 OL-2159-01...
Page 244 The radio indicator blinks green to indicate radio traffic activity. The light is • normally off, but it blinks green whenever a packet is received or transmitted over the access point’s radio. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-38 OL-2159-01...
Page 245 Blinking – General warning. amber Failure Steady Steady Steady Firmware failure; disconnect power from the unit and reapply power. Firmware – Steady – Unit is loading new upgrade firmware. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-39 OL-2159-01...
Page 246: Finding An Access Point By Blinking The Top Panel Indicators
WEP Key 3 on the access point to exactly the same value. The access point does not need to use Key 3 as its transmit key, however. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-40 OL-2159-01...
Page 247: Eap Authentication Requires Matching 802.1X Protocol Drafts
Table 9-4 802.1x Protocol Drafts and Compliant Client Firmware Draft Firmware Version Draft 7 Draft 8 PC/PCI cards 4.13 — — PC/PCI cards 4.16 — — Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-41 OL-2159-01...
Page 248 Step 2 Use the 802.1x Protocol Version (for EAP authentication) pull-down menu to select the draft of the 802.1x protocol the access point’s radio should use. Menu options include: Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-42 OL-2159-01...
Page 249: Resetting To The Default Configuration
COM port on a computer. Open a terminal-emulation program on your computer. Step 2 These instructions describe HyperTeminal; other programs are similar. Note Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-43 OL-2159-01...
Page 250 After the access point reboots and the Express Setup screen appears, reconfigure Step 10 the access point by using the terminal emulator or an Internet browser. Cisco Aironet 1200 Series Access Point Software Configuration Guide 9-44 OL-2159-01...
Page 251: Appendix
This appendix covers these topics: • Channels, page A-2 • Maximum Power Levels and Antenna Gains, page A-3 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 252: Channels
2450 to 2483.5 MHz can be used in Mexico at up to 4W EIRP. Users are responsible for ensuring that the channel set configuration is in compliance with the regulatory standards of Mexico. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 253: Maximum Power Levels And Antenna Gains
Table A-2 Maximum Power Levels Per Antenna Gain Regulatory Domain Antenna Gain (dBi) Maximum Power Level (mW) North America and ANZ (4 watts EIRP maximum) 13.5 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 254 Maximum Power Levels Per Antenna Gain (continued) Regulatory Domain Antenna Gain (dBi) Maximum Power Level (mW) ETSI (100 mW EIRP maximum) 13.5 Israel (100 mW EIRP maximum) 13.5 China (10 mW EIRP maximum) 13.5 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 255 Maximum Power Levels and Antenna Gains Table A-2 Maximum Power Levels Per Antenna Gain (continued) Regulatory Domain Antenna Gain (dBi) Maximum Power Level (mW) Japan (10 mW/MHz EIRP maximum) 13.5 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 256 Appendix A Channels, Power Levels, and Antenna Gains Maximum Power Levels and Antenna Gains Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 257: Appendix
Special Cases field on the Filter Set page to select the protocol. Table B-3 also lists the protocols’ ISO numeric designators. You can use these designators to select a protocol also. Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 258 Novell IPX (old) — 0x8137 Novell IPX (new) 0x8138 EAPOL (old) — 0x8180 EAPOL (new) — 0x888E Telxon TXP 0x8729 Aironet DDP 0x872D Enet Config Test — 0x9000 NetBUI — 0xF0F0 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 259 Internet Group Management Protocol IGMP Transmission Control Protocol Exterior Gateway Protocol — CHAOS — User Datagram Protocol XNS-IDP ISO-TP4 ISO-CNLP CNLP Banyan VINES VINES Encapsulation Header encap_hdr Spectralink Voice Protocol Spectralink — Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 260 Simple Mail Transport Protocol SMTP mail time timserver Resource Location Protocol IEN 116 Name Server name whois nicname Domain Name Server domain — BOOTP Server — BOOTP Client — TFTP — Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 261 Sun RPC sunrpc tap ident authentication auth sftp — uucp-path — Network News Transfer Network News Protocol readnews nntp USENET News Transfer Network News Protocol readnews nntp Network Time Protocol Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 262 Border Gateway Protocol Prospero — Internet Relay Chap SNMP Unix Multiplexer smux AppleTalk Routing at-rtmp AppleTalk name binding at-nbp AppleTalk echo at-echo AppleTalk Zone Information at-zis NISO Z39.50 database z3950 — Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 263 Kerberos kadmin kerberos-adm network dictionary webster SUP server supfilesrv swat for SAMBA swat SUP debugging supfiledbg 1127 ingreslock — 1524 Prospero non-priveleged prospero-np 1525 RADIUS — 1812 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 264 Protocol Filter Lists Table B-3 Protocols on the IP Port Protocol Filters Page (continued) Protocol Additional Identifier ISO Designator Concurrent Versions System 2401 Cisco IAPP — 2887 Radio Free Ethernet 5002 Cisco Aironet 1200 Series Access Point Software Configuration Guide OL-2159-01...
Page 265: I N D E X
Association Table page role in radio network Station page SNMP admin. community authentication server SSID Authentication Server Setup page 4-20 system name backup servers 4-37 baud rate Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-1 OL-2159-01...
Page 266 Cisco Secure ACS DHCP enabling EAP 4-24 class identifier 3-50 setting session-based WEP key timeout lease duration 4-25 3-49 minimum lease duration 3-49 auto-apply multiple-offer timeout 3-49 common functions diagnostic pages Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-2 OL-2159-01...
Page 267 See WEP flow control ensure compatibility with fragment threshold 3-25 Ethernet configuration France, regulatory domain advanced settings frequencies 3-42 hardware settings 3-40 3-55 identity settings 3-38 speed 3-41 Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-3 OL-2159-01...
Page 268 Japan MAC address filters 3-13 power levels and antenna gain MAC-based authentication 4-28 regulatory domain setting up in Cisco Secure ACS 4-33 map windows maximum number of associations 3-32 Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-4 OL-2159-01...
Page 269 North America and ANZ regulatory domain radio carrier test radio cell role 3-32 OK button radio configuration optimize radio network for advanced settings 3-29 hardware settings 3-21 identity settings 3-18 Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-5 OL-2159-01...
Page 270 WEP 4-12 root unit Speed setting 3-41 routing setup 3-56 SSID 3-5, 3-21 RTS retries and threshold 3-26 standby mode Station pages Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-6 OL-2159-01...
Page 271 4-10 transmit antenna 3-28 optional 4-12 transmit power 3-25 overview session key timeout 4-25 setting with SNMP 4-12 transmit key 4-10 unicast packets, filtering with EAP 3-36 updating firmware Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-7 OL-2159-01...
Page 272 Index Windows XP, using EAP with 4-20 World mode 3-23 Cisco Aironet 1200 Series Access Point Software Configuration Guide IN-8 OL-2159-01...

Cisco Aironet 1200 Series Software Configuration Manual

Preface

Overview

Chapter 2 Using the Management Interfaces

Configuration

Basic Settings

Filter Setup

Radio Configuration

Ethernet Configuration

Server Setup

Routing Setup

Association Table Display Setup

Event Notification Setup

Chapter 4 Security Setup

Security Overview

Setting up WEP

Enabling Additional WEP Security Features

Setting up Open or Shared Key Authentication

Setting up EAP Authentication

Setting up MAC-Based Authentication

Summary of Settings for Authentication Types

Setting up Backup Authentication Servers

Setting up Administrator Authorization

Chapter 5 Network Management

Chapter 6 Managing Firmware and Configurations

Chapter 7 Management System Setup

Chapter 8 Special Configurations

Chapter 9 Diagnostics and Troubleshooting

Appendix

Channels, Power Levels, and Antenna Gains

Appendix

Protocol Filter Lists

I N D E X

Quick Links

Related Manuals for Cisco Aironet 1200 Series

Summary of Contents for Cisco Aironet 1200 Series
