Menu Access. The default option is Not Used. A new option is assigned by pressing the A> or <B key
until the required option is displayed or by entering the option number directly and then pressing the
ent to accept the selection.
9 = MAX (Access Control Function) Keypad
The menu option assigned to the MAX card (proximity card) can be limited to operate on a single
keypad. On selecting this option the display shows * *, indicating that a keypad has not been specified.
To specify a keypad, press the # key. The address of the first keypad on the system is displayed. Use the
A> or <B key to select the required keypad and press the ent key to accept the selection.
NOTE: The address of the keypad that is currently being used is indicated by a black square flashing over
the first digit of the keypad address.
Assigning Dual Functions to MAX (proximity card) Numbers
If a card has a # assigned to the number, then any card-held function will only work in conjunction with
the PIN from the same user, provided that the PIN has a # assigned also. The Dual Focus function will
work in either order, but if the card is presented first, it will simply enable the PIN to gain access to the
normal menu (see option 42 = Codes for programming).
If a user's card number is assigned a *, then the card becomes Dual access. This means that it will not
open the door on its own; it needs another PIN or card as well (see option 42 = Codes for programming).
10 = APB (Antipassback) Forgive
This function, if selected, clears all antipassback restrictions for the selected user.
11 = Template
Every user on the system must be allocated an access template. Multiple users can be assigned the same
template. An access template is a list of groups and time schedules that will govern card access
through doors. This method means that if there are multiple doors leading into one group or area, then a
user will be given access to all those doors in one move. This reduces programming time and complexity.
The templates are created in option 45.7 which are in turn made up from the weekly schedules created
in option 65.1.
42.2 = PIN Warning
This option determines the number of days notification before the PIN Change expiration date (refer to
option 51.42 = PARAMETERS.PIN Change) that the user is prompted to assign new code on entry of the
expiring PIN. The default period is 28 days, with a programmable range of 1 – 28. If the user does not assign
a new code by the end of the PIN Warning period, then the code is erased on the next unsetting (disarming)
of the system.
NOTE: The PIN Warning ends on the last day of the month, the PIN expires on the first day of the following
month.
42.3 = Card Users
This option determines the proximity cards on the system for various users. There are seven options:
1 = Add Batch
This option starts enrollment and displays the user/card for each presentation. When batch enrolling (auto assigning of
cards to users), the panel increments the user number, starting from Batch Start. It does this for every new card
presented at the DCM assigned in Batch DCM.
2 = Test Batch
This option checks the card number stored at the panel for the current card presented at the Batch
DCM. It can also be used to go directly to the user programming details that are assigned to the
presented card.
3 = Delete Batch
This option removes MAX (proximity) card numbers from enrollment. A warning is given before deletion.
4 = Batch Start
This option determines the user number where enrollment starts.
GX-Series Control Panel Installation and Setup Guide
6-27
