- Page 1 Vigor2700G e/e A D S L 2/2+ F irew a l l R ou t er Q u ic k S t a rt G u id e Version: 1.0 Date: 2005/11/07...
-
Page 2: Table Of Contents
1.1.2 Rear View for Vigor2700Ge ..................2 1.1.3 Front View for Vigor2700e ..................3 1.1.4 Rear View for Vigor2700e..................3 1.2 Package Content ........................4 2. Installing Your Vigor2700Ge/e Series Router ............. 5 2.1 Hardware Installation......................5 3. Configuring Web Pages ..................7 3.1 Basic Configuration ........................7 3.2 Wireless LAN Settings (for Vigor2700Ge only).............. -
Page 3: Introduction
Vigor2700Ge/e provides exceptional bandwidth for Internet access. The available bandwidth depends on the Internet Service Provider. To secure your network, the Vigor2700Ge/e provides an advanced firewall with advanced features, such as NAT with multi VPN pass-through, Stateful Packet Inspection (SPI) to... -
Page 4: Panel Explanation
ADSL2+ ADSL2/2+ Router Link WLAN Data Status Explanation ACT (Activity) Blinking The router is powered on and running properly. The router is powered on. Wirelss access point is turned off. WLAN Wireless access point is ready. Wireless traffic goes through. Blinking ADSL is show time. -
Page 5: Front View For Vigor2700E
ADSL2+ ADSL2/2+ Router Link Data Status Explanation ACT (Activity) Blinking The router is powered on and running properly. The router is powered on. ADSL2+ Link ADSL is show time. Blinking The device starts handshaking. ADSL2+ Data Blinking DSL data is transmitting. LAN (1, 2, 3, 4) Green A normal connection is through its... -
Page 6: Package Content
Quick Start Guide RJ-45 Cable (Ethernet) The type of the cable depends on the country that the router will be installed: RJ-11 to RJ-11 Cable RJ-11 to RJ-45 Cable RJ-45 to RJ-45 Cable (Annex A) (Annex B) (Annex B) The type of the power adapter depends on the country that the router will be installed: UK-type power adapte EU-type power adapt USA/Taiwan-type power adapter... -
Page 7: Installing Your Vigor2700Ge/E Series Router
This section will guide you to install the router through hardware connection and configure the router’s settings through web browser. Before starting to configure the router, you have to connect your devices correctly. Connect the DSL interface to the external ADSL splitter with an ADSL line cable. Connect one port of 4-port switch to your computer with a RJ-45 cable. - Page 8 This page is left blank.
-
Page 9: Configuring Web
The Quick Start Wizard is designed for you to easily set up your router for Internet access. You can directly access the Quick Start Wizard via Web Configurator. Make sure your PC connects to the router correctly. Notice: You may either simply set up your computer to get IP dynamically from the router or set up the IP address of the computer to be the same subnet as the default IP address of Vigor router 192.168.1.1. - Page 10 Enter the login password on the field of New Password and retype it on the field of Retype New Password. Then click Next to continue. On the next page as shown below, please select the appropriate Internet access type according to the information from your ISP or click Auto detect button to detect the related DSL parameters automatically.
- Page 11 PPPoE or PPPoA: if you click PPPoE or PPPoA as the protocol, please manually enter the Username/Password provided by your ISP. Check Always On means Internet access is always on regardless of Internet usage. Then click Next. Besides, the protocol set here can be reviewed in the section of DSL Modem Settings – Encapsulation on the web page of Internet Access –...
- Page 12 1483 Routed IP: if you click 1483 Routed IP, you will get the following page. Please type in all the information originally provided by your ISP. Then click Next for next step. Besides, the protocol set here can be reviewed in the section of DSL Modem Settings –...
-
Page 13: Wireless Lan Settings (For Vigor2700Ge Only)
For the user of Vigor2700e, please skip this section. For operating Vigor2700Ge Series well, it is necessary for you to set the wireless LAN settings for using wireless function. Please read the following section carefully for configuring the settings for this router. -
Page 14: General Settings
On the Wireless LAN group, select General Settings. The following page will be shown. Check the box Enable Wireless LAN to enable the wireless function. Select an appropriate wireless mode. The router can connect to IEEE802.11b and IEEE802.11g Mixed (11b+11g) stations simultaneously. -
Page 15: Security Settings
On the Wireless LAN group, select Security Settings. Select an appropriate encryption mode to improve the security and privacy of your wireless data packets. Turn off the encryption mechanism. For the security of Disable your router, please select any one of the encryption mode here. - Page 16 field of Pre-Shared Key (PSK). WPA encrypts each frame transmitted from the radio using the Pre-Shared Key (PSK) which entered from this panel. As to WEP encryption, select 64-bit or 128-bit as the encryption mode. For 64bits WEP key, type in 5 ASCII characters or 10 hexadecimal digitals leading by 0x, for example, ABCDE or 0x4142434445.
-
Page 17: Trouble Shooting
This section will guide you to solve abnormal situations if you cannot access into the Internet after installing the router and finishing the web configuration. Please follow sections below to check your basic installation status stage by stage. Checking if the hardware status is OK or not. Checking if the network connection settings on your computer are OK or not. - Page 18 The example is based on Windows XP. As to the examples for other operation systems, please refer to the similar steps or find support notes in www.draytek.com. Go to Control Panel and then double-click on Network Connections. Right-click on Local Area Connection and click on Properties.
- Page 19 Select Obtain an IP address automatically and Obtain DNS server address automatically. Double click on the current used MacOs on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4.
-
Page 20: Pinging The Router From Your Computer
The default gateway IP address of the router is 192.168.1.1. For some reason, you might need to use “ping” command to check the link status of the router. The most important thing is that the computer will receive a reply from 192.168.1.1. If not, please check the IP address of your computer. -
Page 22: Checking If The Isp Settings Are Ok Or Not
Click Internet Access group and then check whether the ISP settings are set correctly. Check if the Enable option is selected. Check if Username and Password are entered with correct values that you got from your ISP. -
Page 23: Backing To Factory Default Setting If Necessary
Check if the Enable option for Broadband Access is selected. Check if all parameters of DSL Modem Settings are entered with correct value that provided by your ISP. Especially, check if the encapsulation is selected properly or not (it should be the same with the setting on Quick Start Wizard). Check if IP Address, Subnet Mask and Gateway are set correctly (must identify with the values from your ISP) if you choose Specify an IP address. -
Page 24: Contacting Your Dealer
After restore the factory default setting, you can configure the settings for the router again to fit your personal request. If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com. -
Page 25: Specifications
ANSI T1.413 Issue2 ) URL blocking Java Applet, Cookies, Active X blocking ADSL G.dmt.bis ( G.992.1 ) Key word blocking ADSL2 G.dmt.bis ( G.992.3 ) Specific file type blocking: compressed, ADSL2+ ( G.992.5 ) executable, multimedia Reach extend ADSL ( READSL ) Time schedule control Up to 24Mbps downstream and 1Mbps upstream... - Page 26 Model comparison High Speed Wireless AP ADSL2/2+ Router Vigor2700Ge Vigor2700e...
