STEP 4 REMOVE OVEN DOOR(S)

• Open the door fully.
• Push hinge latches up to lock hinges in open
position.
Normal Position
• Grasp each side of the door and pull the door straight
out and away from the oven.
• Lay the oven door on packaging to prevent
scratching.
Locked
Hinge
Latch
CAUTION
Do not lift the oven or oven door with handle.
PRUDENCE
Ne pas lever le four ou la porte du four par la poignée.
Installation Instructions
Hinge Latch
STEP 5 ROUTE CABLE THROUGH
CUTOUT
CAUTION
Oven(s) are very heavy. 2 people are required to lift
oven(s) into the opening. Ovens have side handles.
Grasp side handle with one hand and put other hand
into the oven opening. Carefully, lift the oven to the
cabinet opening.
PRUDENCE
Le four est lourd. Il faut deux personnes pour soulever
et mettre le four dans l'ouverture. Le four est équipé
de poignées latérales. Prendre la poignée latérale
d'une main et mettre l'autre main dans l'ouverture du
four. Soulever le four avec précaution et le mettre
dans l'ouverture de l'armoire de cuisine.
With oven in front of cabinet opening:
• Insert power cable into cabinet opening.
• Lift the oven into the opening while continuing to feed
the cable in the direction of the installed junction box.
Be sure the cable does not get pinched between the
back of the oven and cabinet wall.
11
Styrofoam
Shipping Base
