Mode
WPA
WEP
Vigor2800 Series User's Guide
There are several modes provided for you to choose.
Disable - Turn off the encryption mechanism.
WEP Only - Accepts only WEP clients and the encryption
key should be entered in WEP Key.
WEP/802.1x Only - Accept WEP clients with 802.1x
authentication. Since the key will be auto-negotiated
during authentication, the field of key setting below will be
not available for input.
-
WEP or WPA/PSK
legal key accordingly. Only Mixed (WPA+WPA2) is
applicable if you select WPA/PSK.
WEP/802.1x or WPA/802.1x - Accept WEP or WPA
clients with 802.1x authentication. Only
Mixed(WPA+WPA2) is applicable if you select WPA/PSK.
Since the key will be auto-negotiated during authentication,
the field of key setting below will be not available for input.
WPA/PSK Only - Accepts WPA clients and the
encryption key should be entered in PSK. Remember to
select WPA type to define either Mixed or WPA2 only in
the field below.
WPA/802.1x Only - Accept WPA clients with 802.1x
authentication. Remember to select WPA type to define
either Mixed or WPA2 only in the field below. Since the
key will be auto-negotiated during authentication, the field
of key setting below will be not available for input.
The WPA encrypts each frame transmitted from the radio
using the key, which either PSK entered manually in this
field below or automatically negotiated via 802.1x
authentication.
Type - Select from Mixed (WPA+WPA2) or WPA2 only.
Pre-Shared Key (PSK) - Either 8~63 ASCII characters,
such as 012345678..(or 64 Hexadecimal digits leading by
0x, such as "0x321253abcde...").
64-Bit - For 64 bits WEP key, either 5 ASCII characters,
such as 12345 (or 10 hexadecimal digitals leading by 0x,
such as 0x4142434445.)
128-Bit - For 128 bits WEP key, either 13 ASCII
characters, such as ABCDEFGHIJKLM (or 26
hexadecimal digits leading by 0x, such as
0x4142434445464748494A4B4C4D).
All wireless devices must support the same WEP
encryption bit size and have the same key. Four keys can
be entered here, but only one key can be selected at a time.
Accepts WEP and WPA clients with
