- Page 1 X-Treme™ Electric Scooters XMB-400 Electric Mobility Scooter Owner’s Manual (Photo may vary from actual) PLEASE READ ENTIRE MANUAL COMPLETELY BEFORE RIDING...
-
Page 2: Important - Battery Maintenance & Charging Instructions
IMPORTANT! BATTERY MAINTENANCE and CHARGING INSTRUCTIONS You MUST charge completely prior to initial use. (Follow charging instructions in your Product Handbook) Charge immediately after each use. Charge before storage. You must charge every 30 days if not in use. Charge the unit for 10-12 hours or until the light on the charger turns green. DO NOT allow this unit to deep discharge the battery. -
Page 3: Important - Warning & Safety
IMPORTANT PLEASE READ THIS BEFORE USING THIS PRODUCT WARNING This product does not conform to Federal Motor Vehicle Standards and is not intended for operation on public streets, roads or highways. Serious injury can result from the unsafe operations of this product. Operator can minimize these risks by using certain safety equipment such as: safety helmet, goggles, gloves, elbow and kneepads and appropriate footwear. -
Page 4: Quick Reference Safety Guide
QUICK REFERENCE SAFETY GUIDE SAFETY GUIDE The recommended minimum age for riding this scooter is 16 years old. To avoid damage to the motor and footplate, do not overload the scooter. Never ride with more than one person. ... -
Page 5: Technical Support Information
DO NOT RETURN TO STORE! Do not use this vehicle for the first time until you have inflated the tires to the correct PSI and completely charged the battery. Failure to follow these instructions may damage your vehicle and void your warranty. For technical support CALL OR GO ONLINE 1-253-777-0690... -
Page 6: Table Of Contents
TABLE OF CONTENTS Important – Battery Maintenance & Charging Instructions…………………………………… 2 Important – Warning & Safety………………………………………………………………….. 3 Quick Reference Safety Guide…………………………………………………………………. 4 Technical Support Information………………………………………………………………….. 5 Table of Contents………………………………………………………………………………… 6-7 Riding Safety…………………………………………………………………………………….. 8-10 Safety Basics: Do’s & Don’ts………………………………………………………….. 8-9 Operating Reminders and Suggestions………………………………………………. 9 Wet Weather Riding……………………………………………………………………. - Page 7 Frequently Asked Questions (FAQ)…………………………………………………… 23-24 Care & Maintenance…………………………………………………………………………….. 25-27 Moisture………………………………………………………………………………….. 25 Temperature…………………………………………………………………………….. 25 General Guidelines……………………………………………………………………… 25-26 Sleep Timer……………………………………………………………………………… 26 Daily Checklist………………………………………………………………………….. 26 Weekly Checklist………………………………………………………………………… 26 Storage…………………………………………………………………………………… 26 Cleaning…………………………………………………………………………………. 26-27 Safety…………………………………………………………………………………………….. 28-31 Pre-Ride Checklist………………………………………………………………………. 28 Weight Limitations………………………………………………………………………. 28 Incline Information……………………………………………………………………….. 28 Braking Information………………………………………………………………………...
-
Page 8: Riding Safety
Always wear shoes that will stay on your feet and will stay on the floorboard. o Wear bright, visible clothing that is not so loose that it can catch on moving parts of the XMB-400 or objects at the side of the road or trail. -
Page 9: Operating Reminders And Suggestions
Operating Reminders and Suggestions o Review all instructions carefully before riding the XMB-400. o Follow all rules and regulations in your area for operating a motorized scooter. Obey the same road laws as all other road vehicles, including yielding the right-of-way to pedestrians, and stopping at red lights and stop signs. -
Page 10: Night Riding
Ride at night only if necessary. Slow down and use familiar roads with street lighting, if possible. Other Reminders The XMB-400 works best on level ground. Use caution while going down an incline, such as a hill or a ramp. Hill climbing and repeated acceleration/braking will exhaust the battery much more rapidly. -
Page 11: Introduction
Your understanding of these instructions is essential for the safe operation of your new scooter. X-Treme™ Scooters is not liable for damage to property or personal injury arising out of the failure of any person and/or user to follow the instructions and recommendations set forth in this manual or any other demands contained on the scooter itself. -
Page 12: Specifications & Structure
SSPECIFICATIONS & STRUCTURE Your XMB-400 Mobility Scooter mainly consists of four sections: a front section, a rear section, a seat and a battery. A tiller console, handle bar and a footplate are located in the front section. A driving motor, a brake system and the control electronics are located on the rear section. The seat unit contains a seatback and armrests etc. -
Page 13: Charging And Control System
TILLER CONSOLE (Fig. 2) A. Key Switch B. Speed Adjustment Knob C. Battery Condition Indicator D. Horn Button E. Headlight Button F. Throttle Control Lever G. Tiller Figure 2 CHARGING AND CONTROL Figure 3 SYSTEM (Fig. 3) H. 3-Pin Charger Power Receptacle Load Protector SEAT UNIT J. -
Page 14: Specifications
SPECIFICATIONS Drive Wheel 7.3 x 2.76" Solid Rubber Wheel Front Wheel 7.1 x 1.96" Solid Rubber Wheel Anti-Tip Wheel 2.2 x 0.94" Solid Plastic Wheel Forward Speed: 3.7 MPH Speed Reverse Speed: 2.2 MPH Distance per Charge 10.5 Miles Intelligent Regenerative Electromagnetic Braking System Brake Distance Between Ground... -
Page 15: Assembly
5. 24 Volt Battery Charger 6. User Manual GETTING STARTED Open the packing box of your new XMB-400 Mobility Scooter and take off all the protective lining. Remove the scooter from the carton. ADJUSTING THE TILLER 1. Loosen the lock-nut (See Fig. 4). -
Page 16: Assembling The Battery Unit
ASSEMBLING THE BATTERY UNIT Figure 6 Place the battery in the trough. Align the electrode terminal on the battery with that in the trough (See Fig. 6). ASSEMBLING THE SEAT UNIT 1. Place the seat onto the seat support (See Fig. 7). 2. -
Page 17: Disassembly
Figure 9 Seat Unit For convenience to transport and store, your Battery Unit XMB-400 Mobility Scooter is designed to be Rear Section disassembled and assembled easily without any special tools. You can easily disassemble the scooter into four pieces: the front section, the rear section, the seat unit and the batteries (See Fig. -
Page 18: Comfortable Adjusting
WARNING! Remove the key from the key switch before adjustments. Never attempt to make adjustments while the scooter is in motion. Before operating your XMB-400 Mobility Scooter, you may find you need to make some adjustments to increase your comfort while riding, such as seat height, armrest width and tiller angle. -
Page 19: Operation
OPERATION TILLER CONSOLE The tiller consoled houses all the controls needed to drive your XMB-400 Mobility Scooter, including the key switch, the speed adjustment knob, throttle control lever, battery condition indicator, horn button and headlight button. With all the controls on the console you can control various motions of your XMB-400. -
Page 20: Horn Button
2. If the hand is pointing to yellow range that indicates half capacity of the batteries remains and they will need to be charged. 3. If the hand is pointing to red range that indicates the batteries are near the end of capacity and need to be charged immediately. -
Page 21: Manual Free-Wheel Mode Lever
WARNING! When your scooter is in powered mode, the manual free-wheel mode lever must be in downward position, i.e. in power mode, to guarantee the braking system is working normally. Failure to do so may cause the brake system to malfunction and cause personal injury. -
Page 22: Battery & Charging
BATTERY & CHARGING Your XMB-400 Mobility Scooter uses two long-lasting, 12-volt, deep cycle batteries. These batteries are sealed and maintenance free. Since they are sealed, there is no need to check the electrolyte (fluid) level. Deep-cycle batteries are designed to handle a longer and deeper discharge. -
Page 23: Frequently Asked Questions (Faq)
12VDC (direct current). This scooter’s batteries use direct current to run the XMB-400. When the battery voltage is low, the charger sends more current to the batteries so that the charger has a higher temperature, this is normal. When the batteries are fully charged, the current sent to them from the charger is nearly zero. - Page 24 We recommend deep-cycle batteries that are seal and maintenance free. Both SLA (Sealed Lead Acid) and Gel-Cell are deep-cycle batteries that are similar in performance. Your XMB-400 will arrive with 12V12Ah SLA batteries. Why do my new batteries seem weak? Deep-cycle batteries employ a much different chemical technology than that used in car batteries, nickel-cadmium, or in other common battery types.
-
Page 25: Care & Maintenance
CARE & MAINTENANCE For a safe and extended useful life, your XMB-400 Mobility Scooter, like any other motorized vehicle, requires routine maintenance checks. Preventative maintenance is very important. You can perform some of these regular checks yourself. If you follow the maintenance checks in this section as scheduled, you can help ensure that your scooter gives you years of trouble-free operation. -
Page 26: Sleep Timer
Check the anti-tip wheel. Make sure it is not seriously worn. If so, you should change. Check the drive wheels for wear. If significant wear, contact an authorized dealer or X-Treme Scooters for replacement. Keep your scooter clean and free of foreign material, such as hair, food, drink, dust and mud etc. - Page 27 Never use any chemicals to clean the seat, as they may cause the seat to become slippery or dry out and crack. Clean with a damp cloth or neutral soapy water and dry the seat thoroughly.
-
Page 28: Safety
SAFETY PRE-RIDE SAFETY CHECK We recommend you perform a safety check before each use to make sure your scooter operates smoothly. See CARE & MAINTENACE. Check all electrical connections. Make sure they are tight and not corroded. Check all connections to the battery box. Make sure they are secured properly. ... -
Page 29: Braking Information
BRAKING INFORMATION Your XMB-400 Mobility Scooter comes equipped with two powerful brake systems: Electrical Brake System: This system can gradually slow and stop your scooter when you loosen your pressure on the throttle control lever to let it return to the original position when driving. -
Page 30: Up Or Down Stairs And Escalators
UP OR DOWN STAIRS AND ESCALATORS Your scooter is not designed to travel up or down stairs or escalators. Always use an elevator. WARNING! Never use your scooter to negotiate steps or escalators. You may cause personal injury to yourself and others and damage your scooter. IN OR OUT ELEVATORS Modern elevators have a door edge safety mechanism that when you push it reopens the elevator door. -
Page 31: Getting Onto Or Off Your Scooter
GETTING ONTO OR OFF YOUR SCOOTER Getting onto or off your scooter requires a good sense of balance. Please use the following safety tips and the help of your attendant to avoid personal injury. 1. Ensure that the power is turned OFF. See OPERATION. 2. -
Page 32: Electromagnetic Interference
ELECTROMAGNETIC INTERFERENCE EMI/RFI WARNINGS Radio wave, a form of electromagnetic energy, can cause unintended motion of electric mobility scooters. When electromagnetic energy adversely affects the operation of an electrical device, that adverse effect is called Electromagnetic Interference (EMI) or Radio Frequency Interference (RFI). -
Page 33: How To Prevent Emi
affected by a strong radio source than is an electric mobility vehicle with a low resistance level is less likely to be affected by a strong radio source than is an electric mobility vehicle with a low resistance level. HOW TO PREVENT EMI Here are some precautions you can take to prevent EMI: ... - Page 34 DO NOT RETURN TO STORE! IF YOU NEED HELP CALL TOLL FREE OR GO ONLINE 1-253-777-0690 www.x-tremescooters.com/support/ For General Information or Parts Visit www.x-tremescooters.com /3/13 Revised 9...
