- Page 1 MODEL H5626/7 INSTRUCTION MANUAL Model H5626 Model H5627 COPYRIGHT © SEPTEMBER, 2003 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. PRINTED IN TAIWAN...
-
Page 2: Safety Instructions For Pneumatic Tools
For Your Own Safety Read Instruction Manual Before Operating This Equipment The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages. The progres- sion of symbols is described below. - Page 3 USERS TO USE THIS TOOL WHILE UNSUPERVISED. 23. IF YOU ARE UNSURE OF THE INTENDED OPERATION, STOP USING THE TOOL. Seek formal training or research books or maga- zines that specialize in pneumatic tools. RECOMMENDED Consult DAMAGED PARTS. ALLOW UNTRAINED H5626/H5627 Upholstery Stapler...
- Page 4 HOLDING THE TOOL. DO NOT USE A CHECK VALVE OR ANY OTHER FITTING that allows air to remain in the tool. H5626/H5627 Upholstery Stapler Operating this stapler can propel objects into the air, causing immedi- ate eye damage. To protect yourself,...
- Page 5 Commentary We are proud to offer the Grizzly Model H5626/H5627 Upholstery Stapler. This model is part of a growing Grizzly family of fine power tools. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoy- able operation and proof of Grizzly’s com-...
-
Page 6: Compressed Air System
Compressed Air System The Model H5626/H5627 is designed to be operated at 60-100 psi. Do not exceed the maximum operating pressure for your model. Before you use your new stapler, install the ⁄ " quick connect fitting that comes with the stapler. -
Page 7: Operation
Figure 3. Make sure that the point- ed ends of the staples point in the same direction as the stapler nose piece. Figure 3. Loading staples into stapler. Push the magazine cover forward until the magazine latch locks in place. H5626/H5627 Upholstery Stapler... - Page 8 Before pressing the trigger, make sure your free hand is positioned out of the way of a potential path of a sta- H5626/H5627 Upholstery Stapler ple in case of deflection. (Deflection is caused when the staple changes its path, resulting in the staple puncturing the surface of the workpiece as shown in Figure 4.)
-
Page 9: Speed Adjustment
Disconnect the stapler from the air supply! Open the magazine cover and pull the magazine all the way back. Remove stick of staples. Remove jammed staple with needle nose pliers. Always disconnect air from stapler whenever clearing a jammed staple! H5626/H5627 Upholstery Stapler... - Page 10 Vapors in the tool may ignite, causing the tool to explode. Ignoring this warning may lead to serious personal injury or even death! H5626/H5627 Upholstery Stapler Always disconnect air from stapler whenever servicing! During mainte- nance, a stapler connected to air...
- Page 11 Remove all staples from the maga- zine cartridge. Remove the 4 cap screws from the stapler exhaust cap on the Model H5626, or unscrew the exhaust cap on the Model H5627. Remove the exhaust cap as shown in Figure 6.
-
Page 12: Maintenance Notes
MAINTENANCE NOTES H5626/H5627 Upholstery Stapler... - Page 13 H5626 PART BREAKDOWN H5626/H5627 Upholstery Stapler...
- Page 14 24 PH5626024 SEAL 25 PH5626025 TRIGGER VALVE HD 26 PH5626026 TRIGGER VALVE STEM 27 PH5626027 O-RING 28 PH5626028 O-RING 29 PH5626029 TRIGGER VALVE GUIDE H5626/H5627 Upholstery Stapler PART # DESCRIPTION 30 PH5626030 TRIGGER 31 PH5626031 O-RING 32 PH5626032 TUBE 33 PH5626033 O-RING 34 PSB17M CAP SCR M4-.7 X 10...
- Page 15 H5627 PART BREAKDOWN H5626/H5627 Upholstery Stapler...
- Page 16 28 PH5627028 O-RING 29 PH5627029 BODY 30 PH5627030 DRIVER GUIDE 31 PH5627031 EXHAUST DIFFUSER 32 PH5627032 COVER 33 PH5627033 1/4" NPT CONNECT H5626/H5627 Upholstery Stapler PART # DESCRIPTION 34 PSB23M CAP SCR M4-.7 X 12 35 PSB53M CAP SCR M5-.8 X 18...
-
Page 17: Troubleshooting
1. Use correct staples. 2. Use undamaged staples 3. Tighten magazine and nose screws. 4. Replace worn or dam- aged parts. 1. Clear stapler magazine or discharge area. 2. Replace piston shaft. 3. Check/increase air pres- sure. H5626/H5627 Upholstery Stapler... -
Page 18: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of main- tenance. -
Page 19: Warranty Card
14. Do you think your purchase represents good value? 15. Would you recommend Grizzly to a friend? 16. Would you allow us to use your name as a refer- ence for Grizzly customers in your area? Note: We never use names more than three times. 17.Comments:________________________________... - Page 20 Send a Grizzly Catalog to a friend: Name________________________________ Street________________________________ City______________State______Zip_______ FOLD ALONG DOTTED LINE GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
