18 GAUGE STAPLER KIT
MODEL G6042/3
INSTRUCTION MANUAL
Model G6042
Model G6043
COPYRIGHT © OCTOBER, 2001 BY GRIZZLY INDUSTRIAL, INC.
1821 VALENCIA ST., BELLINGHAM, WA 98227
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN TAIWAN

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G6042

Summary of Contents for Grizzly G6042

  • Page 1 Model G6043 COPYRIGHT © OCTOBER, 2001 BY GRIZZLY INDUSTRIAL, INC. 1821 VALENCIA ST., BELLINGHAM, WA 98227 WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. PRINTED IN TAIWAN...

  • Page 2: Safety Instructions For Power Tools

    For Your Own Safety Read Instruction Manual Before Operating This Equipment The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages. The progres- sion of symbols is described below.
  • Page 3 ALLOW UNTRAINED USERS TO RUN THIS TOOL WHILE UNSUPERVISED. INTENDED OPERATION, STOP USING THE TOOL. Seek formal training or research books or maga- zines that specialize in power tools. G6042/G6043 18 Gauge Stapler Kit...
  • Page 4 DO NOT USE A CHECK VALVE OR ANY OTHER FITTING that allows air to remain in the tool. G6042/G6043 18 Gauge Stapler Kit Operating this stapler can propel objects into the air, causing immedi- ate eye damage. To protect yourself,...
  • Page 5 Commentary We are proud to offer the Grizzly Model G6042/G6043 18 Gauge Stapler. This model is part of a growing Grizzly family of fine power tools. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoy- able operation and proof of Grizzly’s com-...

  • Page 6: Compressed Air System

    Compressed Air System The Model G6042/G6043 is designed to be operated at 60-100 psi. Do not exceed the maximum operating pressure for your model. Before you use your new stapler, install the ⁄ " quick connect fitting that comes with the stapler.

  • Page 7: Operation

    Figure 2. Make sure that the point- ed ends of the staples point in the same direction as the stapler nose piece. Figure 2. Loading staples into stapler. Push the magazine cover forward until the magazine latch locks in place. G6042/G6043 18 Gauge Stapler Kit...
  • Page 8 Figure 3.) G6042/G6043 18 Gauge Stapler Kit Figure 3. Example of staple deflection. Besides damaging your workpiece, deflection can cause injury if your free hand is securing the workpiece in the location that the staple deflects.

  • Page 9: Clearing Jammed Staples

    The jammed staple should now be visible; remove it from the discharge area with needle nose pliers. Replace the staples. Push the maga- zine closed and snap the quick release latch back into operating posi- tion. G6042/G6043 18 Gauge Stapler Kit...
  • Page 10 As mentioned before, the best option is to install a filter/lubricator/regulator unit such as the Grizzly Model H2333 in your air line. Figure 4. Lubricating stapler via air inlet. G6042/G6043 18 Gauge Stapler Kit...
  • Page 11 Replacing Pistons/O-Rings If you use your stapler day in and day out, Grizzly offers repair pistons as cheap insurance against wasted down time and lost profits in the event that a piston or pis- ton shaft becomes worn out. To replace a...

  • Page 12: Maintenance Notes

    MAINTENANCE NOTES G6042/G6043 18 Gauge Stapler Kit...
  • Page 13 G6042 PART BREAKDOWN G6042/G6043 18 Gauge Stapler Kit...
  • Page 14 O-RING P6042038 TRGR VALVE GUIDE P6042039 SPRING 40A P6042040A TRIGGER P6041041 CAP SCREW * These items are not shown in the illustration. G6042/G6043 18 Gauge Stapler Kit PART # DESCRIPTION P6042042 NOSE COVER P6042043 CAP SCREW P6042044 CAP SCREW P6042045...
  • Page 15 G6043 PART BREAKDOWN G6042/G6043 18 Gauge Stapler Kit...
  • Page 16 TRGR VALVE STEM P6043036 O-RING P6043037 O-RING P6043038 TRGR VALVE GUIDE P6043039 SPRING * These items are not shown in the illustration. G6042/G6043 18 Gauge Stapler Kit PART # DESCRIPTION 40A P6043040A TRIGGER P6045041 CAP SCREW P6043042 NOSE COVER P6043043 CAP SCREW...

  • Page 17: Troubleshooting

    1. Use correct staples. 2. Use undamaged staples 3. Tighten magazine and nose screws. 4. Replace worn or dam- aged parts. 1. Clear stapler magazine or discharge area. 2. Replace piston shaft. 3. Check/increase air pres- sure. G6042/3 18 Gauge Stapler Kit...

  • Page 18: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of main- tenance.

  • Page 19: Warranty Card

    14. Do you think your purchase represents good value? 15. Would you recommend Grizzly to a friend? 16. Would you allow us to use your name as a refer- ence for Grizzly customers in your area? Note: We never use names more than three times. 17.Comments:________________________________...
  • Page 20 Send a Grizzly Catalog to a friend: Name________________________________ Street________________________________ City______________State______Zip_______ FOLD ALONG DOTTED LINE GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
