For Vigor2830Vn - Draytek Vigor2830 Series Quick Start Manual

1 . 1 . 3 F o r V i g o
1 . 1 . 3 F o r V i g o
LED
ACT (Activity)
USB
CSM
WLAN
DSL
WAN2
Line
Phone 1/2
LED on Connector
Left LED
GigaLAN
(Green)
1/2/3/4
Right LED
(Green)
Left LED
WAN2
(Green)
(Giga)
Right LED
(Green)
Vigor2830 Series Quick Start Guide
r 2 8 3 0 V n
r 2 8 3 0 V n
Status
Blinking
Off
On
Blinking
On
On
Blinking
On
Blinking
On
Blinking
On
Off
On
Off
Blinking
On
Off
Blinking
On
Off
On
Off
Blinking
On
Off
Explanation
The router is powered on and running normally.
The router is powered off.
USB device is connected and ready for use.
The data is transmitting.
The profile(s) of CSM (Content Security Management)
for IM/P2P, URL/Web Content Filter application can be
enabled from Firewall >>General Setup. (Such profile
must be established under CSM menu).
Wireless access point is ready.
It will blink slowly while wireless traffic goes through.
ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and will return to
normal condition after two minutes. (You need to setup
WPS within 2 minutes.)
The router is ready to access Internet through DSL link.
Slowly: The DSL connection is ready.
Quickly: The connection is training.
The WAN2 connection is ready.
It will blink while transmitting data.
A PSTN phone call comes (in and out). However, when
the phone call is disconnected, the LED will be off.
There is no PSTN phone call.
The phone connected to this port is off-hook.
The phone connected to this port is on-hook.
A phone call comes.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps when left LED
is on.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps when left LED
is on.
6
