Setting Up the Converter (7)
C4004U556AA
C4004U557AA
TERM
C4004U558AA
4004-7715-01
1. Remove the converter from its box.
2. Remove the screw at the bottom of the con-
verter, and then remove the upper cover.
3. Set the TERM switch (S2) to ON as shown in
the illustration.
NOTE
• Set the button on the converter to "Nor-
mal".
• In order to reduce the risk of damage to
the circuit board due to static electricity,
do not touch the circuit board pattern.
• Do not change the setting of any
switches other than those specified.
CF2001P
Setting Up the Selector (3)
C4004U601AA
C4004U602AA
Aluminum tape
C4004U603AA
– 13 –
NEXT
NEXT
1. Remove the selector from its box.
2. Remove the two screws from the selector,
and then remove the upper cover.
3. Affix aluminum tape to the converter as
shown in the illustration.
