C4004U062AA
C4004U063AA
C4004U064AA
C4004U065AB
4004-7715-01
6. Fully pull the toner hopper shutter out toward
you. Pulling out the toner hopper shutter
allows the toner to begin filling the toner hop-
per. Check that all of the toner has emptied
out of the toner bottle and into the hopper,
which may take a while.
NOTE
Do not tap on the toner bottle while refilling
the hopper; otherwise, the toner may spurt
out.
7. Push the toner hopper shutter closed until it
snaps into place and closes the bottle.
8. Tilt the toner bottle slightly backward, and
then pull the opening of the bottle up and
toward you to remove it.
CF2001P
C4004U066AA
C4004U067AA
– 9 –
NEXT
NEXT
9. Carefully close the yellow toner hopper lid.
10. Fill the magenta, cyan, and black toner in the
same way (as described in steps 2 through
9).
NOTE
Be sure to fill the toner hoppers with the cor-
rect color of toner.
11. After all four toner hoppers are filled, grasp
the toner supply door as shown, and then
carefully swing the door down to close it.
