RIDGID KJ-3000 User Manual

Jetter
Motor/Pump Assembly
27
NOTE: Order parts by Catalog Number Only.
DO NOT order by Reference Number.
Ref. Catalog
No. No. Description
1 66092 Gasoline Engine, 13 Hp Manual Start
66097 Gasoline Engine, 13 Hp Electric Start
2 49562 Decal, Warning
3 60102 Decal, Fuel Warning
4 66102 Decal, Model No.. KJ-3000
" x " x 1"
5 66107 Key, 1 / 1 /
4 4
6 66112 Spacer, Gearbox Mount
7 60080 Lock Washer (8)
" - 16 x 1
8 75350 Hex Screw, 3 /
8
9 66117 Pressure Gauge, KJ-3000
10 48107 Street EL, 45 Degree
11 66122 Pump Complete, 3000 PSI
12 65412 Thermal Relief Valve
Printed in U.S.A.
2
1
22
23
24
25
26
18
28
29
30
31
32
33
Ref. Catalog
No. No.
13 66132
14 48187
15 60230
16 85867
17 66137
18 63907
19 46375
20 66142
" (4)
1 / 21 65202
4
22 66147
23 48117
24 66157
25 66162
Ridge Tool Company/Elyria, Ohio, U.S.A.
3
7
5
6
21
13
7
35
34
16
17
19
20
Description
Hex Hd. Cap Scr., Metric M8-10 (4)
Rubber Foot (4)
Nut (4)
Pulse Actuator Assembly
Panel
Pulse Actuator Handle
Soc. Hd. Cap Screw, #6 - 32 x 5
Decal, Instruction
Unloader Valve
Chemical Injector
Quick Connect – Female
Reducer Adapter
Street EL, 90 Degree
6/05
KJ-3000
4
9
8
10
11
12
15
36
7
7
13
14
Ref. Catalog
No. No. Description
26 66867 Coupling, 1 /
2
27 48147 Street EL, 90 Degree,
28 66167 Inlet Filter
29 49587 Hose Adapter w/Washer
30 48287 Filter Washer
31 49582 Water Shut-Off
"
/ 32 48202 Hose Coupler Nipple
8
33 48197 Hose Coupler
34 85877 Adjusting Screw w/Seals
35 85882 Seals for Adjusting Screw
36 65392 O-Ring
37 95787 Pressure Gauge Blushing
— 65127 Wash Wand Nozzle (Not Shown)
37
" NPT
" NPT
1 /
2
278-099-581.10
