Summary of Contents for Baumatic BW1000W
- Page 1 BW 1000W BW 1200W BWD 1300W...
- Page 2 This appliance complies with the provisions of the 89/336/EC Directive regarding electromagnetic compatibility and the 73/23/EC directive Low Voltage regarding electrical safety and the 93/68/EC Directive for CE marking.
- Page 3 INDEX 1-SPECIFICATION 2- INSTALLATION 3- HANDLING 4- MAINTENANCE 5- CAUTIONS AND ADVICE 6- SAFETY FEATURES 7- CONTROLS 8- WASH PROGRAMME TABLE...
-
Page 4: Specification
1 - SPECIFICATION Wash/Dry 1.1 - Technical data - Dimensions...........Height........85 cm Width........60 cm Depth........55 cm - Washing/Drying capacity.......Cotton.....5,5 kg/2,75 kg Synthetics....2,75 kg/1,5 kg Wool......1 kg - Power supply voltage (m.f.)..........230 V ~ 50 Hz - Maximum power consumption-washing/Drying....2.200 W/ 1.450 W - Models................ -
Page 5: Installation
2- INSTALLATION 2.1 - Removing transit bolts After removing the external packing the drum must be released before the machine is used. This is done in the following manner: 1 . ) U n s c r ew a n d r e m ove t h e f o u r screws A-B-C-D. - Page 6 2.3 - Levelling For the appliance to work under optimum conditions, it needs to be levelled perfectly, i.e.horizontal and stable. Once the machine has been positioned in ist place, work the adjustable feet "I" at the front of the washing machine, until it is horizontal and the four feet are resting f irmly on the floor.
- Page 7 3- HANDLING 3.1 - Loading door-Opening Once the washing programme has f inished, push the programme button (or ON/OFF push-button) and wait 2 minutes before trying to open the door. CASE A: 1. Press the hidden lever with the index and middle f ingers 1 2.
- Page 8 3.3 - Selecting the clothes load Before putting the clothes into the machine, you should: Separate the clothes into three lots (cotton, synthetics and wool). Within each group, separate the coloureds from the whites. Once the clothes have been sorted, put them into the drum of the machine, separately according to colour and group, loose piece by piece, as per the following proportions: Cotton maximum 5,5 kg.
-
Page 9: Maintenance
4- MAINTENANCE 4.1 - Cleaning the drain-pump outlet filter. It is advisable to periodically clean this f ilter (every 25 wash cycles) in order to maintain the correct operation of the drain pump and consequently, the washing and rinsing eff iciency. In order to clean the filter carry out the following: -Open the access door. -
Page 10: Cautions And Advice
5- CAUTIONS AND ADVICE In order to get maximum satisfaction and performance from this appliance, it is important to follow the instructions indicated below: This washing machine is exclusively for domestic use. Select the clothes load correctly (section 3.3) and choose the appropriate programme (section 8). - Page 11 In the event of any doubts or anomalies which arise, ring the TECHNICAL ASSISTANCE SERVICE, but first, make the following checks: a) The machine is not working. Check that: - The door is properly closed. - The fuses are not brown and the automatic cutout has not been triped. - The programmer control button P (or the push-button X) is not in the STOP position.
-
Page 12: Safety Features
6- SAFETY FEATURES 6.1 - The door A n e l e c t r o - m e c h a n i c a l s a f e t y d e v i c e p r e v e n t s t h e d o o r f r o m opening whilst the appliance is operating,thus preventing access to the inside of the machine and the consequent danger of injuries to the hands from coming into contact with high temperatures or from the movement of the drum. - Page 13 7 - CONTROLS BW 1000W BW 1200W BWD 1300W...
- Page 14 7 - CONTROLS P- Programme selector This control button is used to select the programme which is adequate according to the nature and deg ree of dir tiness of the clothes to be washed.To set the programme,operate the ON/OFF button (position out) and turn the control in a clockwise direction until the indicating mark coincides with the chosen programme.
- Page 15 A- Rinse and hold push-button When activated "button IN", it makes the wash cycle of the synthetic and wool programs stop during the last rinse with the drum full of water. This operation is advisable to prevent creasing in certain fabric which need to be drip dried. To end the cycle, press the button again "button OUT".
-
Page 16: Practical Advice
PRACTICAL ADVICE a) Correctly select the load of clothes and correct programme (section 3.3 and 8). b) The temperature indicated in the programme table is the maximum which can be c) One can choose the desired temperature with the temperature selector, but always lower than that indicated in the programme table (section 8). - Page 17 8- WASH PROGRAMME TABLE WOOL COTTON FABRIC SYNTHETICS ºC.SELECTOR PRE-WASH WASH BLEACH SOFTENER LOAD kg ON/OFF NO SPIN EXTRA RINSE HALF LOAD RINSE & HOLD 550/1000- 1300rpm CONSUMPTION WASHING min.
-
Page 18: Conditions Of Guarantee
In addition, your appliance is covered by a 5 year parts warranty, Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are f itted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years fron the original purchase date. - Page 19 For mainland UK and Northen Ireland, please contact one the above numbers for further information or any other query you may have. For ROI (Republic of Ireland), please contact one of the numbers below: TEL: 01-4030501 FAX: 01-4030503 Thank you for buying Baumatic.
