Baumatic AS19SS-A Instruction Manual

60 cm multifunction oven
Hide thumbs Also See for AS19SS-A:
Table of Contents

Advertisement

Quick Links

Instruction manual
AS19SS-A Studio Solari
60 cm Multifunction oven

Advertisement

Table of Contents
loading

Related Manuals for Baumatic AS19SS-A

Summary of Contents for Baumatic AS19SS-A

  • Page 1 Instruction manual AS19SS-A Studio Solari 60 cm Multifunction oven...
  • Page 2 ELECTRIC SINGLE OVENS USER AND INSTALLATION INSTRUCTIONS...

  • Page 3: Model Number

    For future reference please record the following information which be found on the Rating Plate and the date of purchase which can be found in the invoice: Model Number ……………………. Serial Number ……………………. Date of Purchase …………………….

  • Page 4: Table Of Contents

    CONTENTS General Information pages 3-4 Warning and Safety Instructions pages 5-6 Instructions for Use pages 7-19 pages 20-23 Instructions for Installation Maintenance pages 24-25 Technical Data page 26 pages 27-28 Conditions of Guarantee European directive on Waste Electrical and Electronic Equipment (WEEE) page 29...

  • Page 5: General Information Pages

    Installation Instructions. The use for any other purpose or in any other environment without the express agreement of Baumatic Ltd, would invalidate any warranty or liability claim. Your new appliance is guaranteed against electrical or mechanical defects subject to certain exclusions noted in Baumatic Ltd Conditions of Guarantee.
  • Page 6 CE Marking – 93/68 Low Voltage – 73/23 EMC – 89/336 Safety Standards – EN 60 335-1, EN 60 335 – 2 – 6. As Baumatic have a policy of continued product improvement, the right is reserved to adjust and make any modifications deemed necessary without notification.

  • Page 7: Warning And Safety Instructions Pages

    Baumatic advise that this appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safely.
  • Page 8 For electrical installations, NICEIC registration is recommended. Baumatic Ltd declines any responsibility for injury or damage to persons or property as a result of improper use or installation of this appliance.

  • Page 9: Instructions For Use Pages

    INSTRUCTIONS FOR USE These User Instructions should be retained for future reference and for use by a person who is perhaps unfamiliar with the appliance. The following models are covered by these instructions: AS19SS-A UK AS19SK.X-A...
  • Page 11 FUNCTION BUTTONS Decreases temperature Increases temperature ON/OFF and CHILDREN CARE Minute minder Cooking time End time Minus setting + Plus setting Program setting Program setting OPERATION The timer flashes on the display when switched on for the first time and the oven cannot be operated;...
  • Page 12 END OF COOKING SEMIAUTOMATIC OPERATION For fixed-time cooking Switch on the oven; press button and set the end of cooking time, within the next 23h59m, 23h59m, with buttons - and +. Wait until the 2 dots on the timer display stop flashing and the timer shows the current hour;...

  • Page 13: Cooking Functions

    Cooking functions: OVEN LIGHT The internal oven light goes on. If no cooking mode is selected after 1 minute, PREHEATING Step 1 - The grill and sole resistance, the radial fan and the oven light turn on. A circular moving symbol is shown on the temperature display. Preheating up to 210°C.
  • Page 14 Cooking functions: PIZZA FUNCTION This kind of cooking is ideal for pizza and vegetable dishes. With this function, lower heating element, circular heating element and fan motor work at the same time. FAN OVEN MODE This provides even heating with the fan and allows different dishes to be cooked at the same time on different levels.
  • Page 15 OTHER FUNCTIONS OVEN OFF MODE W hen no function is selected, the temperature and program displays are off and the timer displays the time. "CHILDREN CARE" - CONTROLS LOCK FUNCTION Hold down button for at least 3 seconds: the oven will be set on "children care" "...

  • Page 16: Helpful Hints

    WARNING • Ensure that the oven door is kept closed when using the GRILL. • Do not use aluminium foil to cover the grill pan or heat. • Do not wrap items in aluminium foil and place under the grill – the high reflectivity of the foil can damage the grill element.

  • Page 17: Cleaning The Appliance

    CLEANING THE APPLIANCE Always allow the appliance to cool down before cleaning to avoid a burn injury. Do not use caustic or abrasive agents, coarse wire wool or hard tools as these can damage the surface finishes. Normally, wiping with a soft cloth dampened with hot detergent is sufficient, but for stubborn marks the following is recommended: VITREOUS ENAMEL PARTS Use only a cleaner that is recommended for this type of material –...
  • Page 18 REMOVING THE OVEN DOOR INNER GLASS PANEL (fig. 1-2) Do not use any abrasive medium that could cause damage. Remember that if the surface of the glass panel becomes scratched, this could lead to a dangerous failure. To remove the oven door inner glass panel, use a coin to perform a levering action in the two grooves (A) until the two pins (B) are released from their housing (fig.
  • Page 19 REMOVING THE OVEN DOOR INNER GLASS PANEL (fig. 1-2) Fig. 1 Fig. 2...
  • Page 20 REMOVING AND REFITTING THE OVEN DOOR (1-6) The door can be hooked on both sides Block position Release position...
  • Page 21 Warning: once completed Release the operation, check the door position is correctly hooked. Block position...

  • Page 22: Instructions For Installation Pages

    IEE Wiring Regulations Electricity at Work Regulations PRE-COMMISSIONING THE APPLIANCE When unpacked, check that the following parts are included with the appliance: • Baumatic Instruction and Installation Book. • 2 oven shelves; • 1 set comprising Grill Pan, Trivet and handle. •...
  • Page 23 INSTALLATION 85-90 85-90 550 min. 592-593 85-90 550 min.
  • Page 24 12,9 Front panel (side view) Fixing screw Oven door (upper view) Fixing screw (1 on each corner)

  • Page 25: Electrical Connection

    ELECTRICAL CONNECTION Before connecting the appliance, make sure the supply voltage marked on the Rating Plate corresponds with the mains supply voltage. WARNING – THIS APPLIANCE MUST BE EARTHED This appliance should be wired into a 16A double pole switched fused spur outlet having 3mm contact separation and placed in an easily accessible position adjacent to the appliance.

  • Page 26: Maintenance Pages

    Before carrying out any maintenance, disconnect the appliance from the electricity supply. During the guarantee period, in case of need all service interventions should be referred back to the Baumatic Ltd Service department. Please note that intervention or repair by any unauthorised personnel will invalidate such guarantee.

  • Page 27: Replacing The Oven Light

    If the liners are allowed to become black and shiny, they must be replaced by new items. Remove all internal accessories to facilitate replacement of the liners. Replacement liners may be purchased directly from the Baumatic Spares Department (details on page 28). Please quote product-type references B600 and/or your appliance’s...

  • Page 28: Technical Data

    TECHNICAL DATA DIMENSIONS Height: 591mm Width: 597mm Depth: 525mm COOLING FAN A tangential cooling fan is fitted on the following models: AS19SS-A UK, AS19SK.X-A ELECTRICAL DETAILS Rated Voltage: 230V a.c. 50Hz Supply Connection: 16A (double pole switched fused outlet with 3mm contact gap) MAX RATED INPUTS: AS19 SS-A UK, AS19SK.X-A...

  • Page 29: Conditions Of Guarantee Pages

    Baumatic appliance. * In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fitted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date.
  • Page 30 Headquarters Baumatic Ltd. Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX, United Kingdom Sales Telephone +44 118 933 6900 Sales Fax +44 118 931 0035 Service Telephone +44 118 933 6911 Service Fax +44 118 986 9124 Spares Telephone...
  • Page 31 This appliance is marked according to the European directive 2002/96/EC on Waste electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
  • Page 32 Baumatic ® w w w . b a u m a t i c . c o m...
