Chapter 10 Managing Modules
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
d.
Note

Using the reload module Command

The following steps describe how to configure the SSI image boot variable for Fibre Channel switching
and Intelligent Storage Services on the SSM on switches running Cisco MDS SAN-OS release 2.0(2b)
through Release 2.1(1a) on the SSM. You can also use these steps to configure the SSI image boot
variable for Fibre Channel switching on the ASM on switches running Cisco MDS SAN-OS Release
2.0(2b) through Release 2.1(1a).
Log into the switch through the console port, an SSH session, or a Telnet session.
Step 1
Verify that the ASM is physically installed in the switch. If the module is not physically installed, insert
Step 2
it into the desired slot. Issue a show module command to verify the status of the module.
switch# show module
Mod
---
4
5
6
...
Note the slot number for later reference.
Verify the Cisco MDS SAN-OS release running on the switch and the location and name of the SSI boot
Step 3
image on the switch following the procedure described in the
page
OL-6973-03, Cisco MDS SAN-OS Release 2.x
switch# delete bootflash:m9500-sf1ek9-kickstart-mz.2.1.1.bin
The show module command output shows that the standby supervisor is in slot 6. Use the attach
command to access the supervisor module.
switch# attach module 6
...
switch(standby)# delete bootflash:m9500-sf1ek9-kickstart-mz.2.1.1.bin
switch(standby)# exit
switch#
Copy the boot image file from the FTP server to the bootflash: or slot0: device in the active
supervisor module. The following example shows how to copy to bootflash:
As of Cisco MDS SAN-OS Release 2.1(2), you can copy to modflash: on the SSM but only
Note
for installations using the reload module command. You can check the available space using
the dir modflash://slot-1/ command.
switch# copy ftp://10.1.7.2/m9000-ek9-ssi-mz.2.1.2.bin
bootflash:m9000-ek9-ssi-mz.2.1.2.bin
The system will automatically synchronize the SSI image to the standby supervisor if automatic
copying is enabled.
switch# config t
switch(config)# boot auto-copy
Ports Module-Type
----- -------------------------------- ------------------ ------------
32 Storage Services Module
0 Supervisor/Fabric-1
0 Supervisor/Fabric-1
10-22.
Installing the SSI Boot Image on the SSM
Model Status
DS-X9032-SSM ok
DS-X9530-SF1-K9 active *
DS-X9530-SF1-K9 ha-standby
"Verifying the SSI Boot Image" section on
Cisco MDS 9000 Family Configuration Guide
10-25
