Summary of Contents for D-Link DCS-3410

  • Page 2: Table Of Contents

    Motion Detection ... 3 Time and Date ... 33 Recording ... 34 Snapshot ... 35 Digital Output ... 36 D-Link DCS-3410 User Manual Table of Contents RS-485 ... 37 Maintenance ... 38 Device Management ... 38 Backup and Restore ... 39 Firmware Upgrade ...

  • Page 3: Product Overview

    Section 1 - Product Overview Product Overview Package Contents • D-Link DCS-3410 PoE Day & Night Network Camera • CAT5 Ethernet Cable • Power Adapter • Manual and Software on CD • Quick Install Guide • Camera Stand Note: Using a power supply with a different voltage than the one included with the package will cause damage and void the warranty for this product.

  • Page 4: Introduction

    Snapshot enables you to save a snapshot image directly from a Web browser to a local hard drive without installing any software. With 0.3 lux light sensitivity, the DCS-3410 is capable of capturing video in rooms with minimal lighting.

  • Page 5: Features

    • Low Light Recording and 4x Digital Zoom: The DCS-3410’s 0.3 lux light sensitivity allows you to capture video in rooms with minimal lighting, making it ideal for use at night time. The camera also features 4x digital zoom for closer viewing.

  • Page 6: Hardware Overview

    Microphone Connector The DCS-3410 PoE Day & Night Network Camera has an internal microphone built-in. However, you have the option of using an external microphone by plugging it into the microphone connector. Ethernet Cable Connector (PoE) The Network Camera’s back panel features...

  • Page 7: Hardware Overview

    D-Link DCS-3410 User Manual Hardware Overview I/O Connector The DCS-3410 provides a terminal block with three pairs of connectors situated on the back panel. Two pairs are for input and the other is for output. The I/O connectors provide the physical interface to send and receive digital signals to and from a variety of external devices.

  • Page 8: Hardware Installation

    Network Camera. Connect Using Power-Over-Ethernet Once you connect an Ethernet cable to your PoE switch or adapter, the Power LED on the DCS-3410 will turn green to indicate a proper connection. D-Link DCS-3410 User Manual...
  • Page 9 Attach the camera stand to the Network Camera and station it for your application. There are holes located in the base of the camera stand allowing the Network Camera to be mounted to the ceiling, or any wall securely. Socket for camera stand D-Link DCS-3410 User Manual...

  • Page 10: Software Installation

    Section  - Installation Software Installation Turn on the computer and Insert the D-Link DCS-3410 Driver CD in the CD-ROM drive. The step-by-step instructions that follow are shown in Windows XP. The steps and screens are similar for the other Windows operating systems.
  • Page 11 Click Next to continue. Click Next Click Yes to accept the License Agreement. Click Yes D-Link DCS-3410 User Manual...
  • Page 12 Section  - Installation To start the installation click Next. Note: The installation may take several minutes to complete. Click Next D-Link DCS-3410 User Manual...
  • Page 13 Section  - Installation Click Finish to complete the installation. Click Finish D-Link DCS-3410 User Manual...

  • Page 14: Configuration

    Section 3 - Configuration Configuration This section will show you how to configure your new D-Link Network Camera using the Setup Wizard. Setup Wizard Configuration Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu.
  • Page 15 IP Address (which may or may not be correct depending on what you have your DCS-3410 connected to). If you have a DHCP server on your network, there will be a valid IP Address displayed here. Click the Wizard button to continue.
  • Page 16 Select DHCP if you want to obtain a new IP address every time the camera boots up. Click Next Select static IP to use the same IP address at each boot up. Click Next D-Link DCS-3410 User Manual...
  • Page 17 Click the button labeled Link to access the web configuration page. The Setup Wizard will automatically open your web browser to the IP address of the DCS-3410, in this example it is: http://19.198.0.10. Your DCS-3410 may have a different IP Address.

  • Page 18: Web-Based Configuration Utility

    Section 3 - Configuration Web-based Configuration Utility This section will show you how to configure your new D-Link Network Camera using the Web-based Configuration Utility. To access the configuration utility, open a web-browser such as Internet Explorer and enter the IP address for your Network Camera (http://19.168.0.10)

  • Page 19: Live Video

    Video Profile 1 Video Profile 2 Video Profile 3 Video Profile 4 Full screen mode Taking a Snapshot Recording a Video Clip Set a Storage Folder Listen/Stop Listening Talk/Stop Talking Start/Stop Digital Output D-Link DCS-3410 User Manual Live Video Camera...

  • Page 20: Setup

    Manual Motion Detection Setup and skip to page 7. Internet Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera and connect the camera to the internet. Click Next to continue.
  • Page 21 Select Static IP if your Internet Service Provider has provided you with connection settings, or you wish to set a static address within your home network. Enter the accurate information for your static IP setting. Click Next to continue. Click Next D-Link DCS-3410 User Manual...
  • Page 22 If you have a Dynamic DNS account and would like the camera to update your IP address automatically, Select Enable and enter your host information. Click Next to continue. Click Next Enter a name for your camera and click Next to continue. Click Next D-Link DCS-3410 User Manual...
  • Page 23 If you have selected Static IP, you will see a summary of your camera’s settings. Please note down all this information as you will need it for accessing your camera within the network. Click Apply to save your settings. Click Apply D-Link DCS-3410 User Manual...

  • Page 24: Motion Detection Setup Wizard

    This wizard will guide you through a step-by-step process to configure your new D-Link Camera motion detection functions. Click Next to continue. Click Next This section will allow you to enable or disable motion detection as well as control the sensitivity or your camera’s ability to detect movement.
  • Page 25 This step allows you to specify how you will receive the events notification of your camera, either via using email or FTP. You will need to enter all the relevant information for your email account or FTP settings. Then, click Next to continue. Click Next D-Link DCS-3410 User Manual...
  • Page 26 Section 3 - Configuration You have completed the Motion Detection Wizard. Click Apply to activate your settings. Click Apply D-Link DCS-3410 User Manual...

  • Page 27: Network Setup

    Enable UPnP port Enable this setting to allow the camera to add port forwarding entries into the router automatically. forwarding: Enable PPPoE: Enable this setting if you network is using PPPoE service. D-Link DCS-3410 User Manual Network Setup...
  • Page 28 The password to your account. You may obtain this information from your ISP. HTTP Port: The default value is 80. RTSP port: The port number that you use for RTSP streaming to mobile devices, such as mobile phones or PDAs. The default port number is 554. D-Link DCS-3410 User Manual...

  • Page 29: Dynamic Dns

    User name: Enter your user name or e-mail used to connect to the DDNS Password: Enter your password used to connect to the DDNS server. Status: Indicate the connection status, automatically determined by the system. D-Link DCS-3410 User Manual Dynamic DNS...

  • Page 30: Image Setup

    An adjustable setting to compensate for backlit scenes. Saturation: This setting controls the strength of color from black and white to bold colors. Contrast: The measurement for color intensity/strength. Hue: This setting controls the color tone. D-Link DCS-3410 User Manual Image Setup...

  • Page 31: Audio And Video

    Higher bit rate will increase the video quality. It is the URL name used to connect to the camera when RTSP URL: viewing from a mobile device or PDA. D-Link DCS-3410 User Manual Audio and Video...

  • Page 32: Motion Detection

    Select this option to draw out the motion detection area area: by dragging your mouse in the window (indicated by the red-colored box). Erase motion Select this option to erase your motion detection area area: by dragging your mouse in the window. D-Link DCS-3410 User Manual Motion Detection...

  • Page 33: Time And Date

    Set the date and This option allows you to set the time and date time manually: manually. Copy Your This will synchronize the time information from your Computer’s Time Settings: D-Link DCS-3410 User Manual Time and Date...

  • Page 34: Recording

    A preset amount of time before motion recording is triggered. Postrecord: A preset amount of time after motion recording is triggered. Select this option to manually configure the starting and ending time for the recording. Continuous: D-Link DCS-3410 User Manual Recording...

  • Page 35: Snapshot

    The prefix that will be added to the filename of each file. Port: The port of the FTP server. The default port is 5. Passive mode: Some FTP servers allow clients to use passive mode when connecting to an FTP, which uses random ports for transfers. D-Link DCS-3410 User Manual Snapshot...

  • Page 36: Digital Output

    This enables the D/O to send a signal when there is a signal: triggered event. Trigger Event: You can choose from one or up to three events, such as Motion Detection, D/I Signal 1, and D/I Signal  for the sources of the triggered events. D-Link DCS-3410 User Manual Digital Output...

  • Page 37: Rs-485

    For example, if the data is 011, for even parity, the parity bit is 0 to keep the number of logic-high bits even. If the parity is odd, the parity bit is 1, resulting in 3 logic-high bits. D-Link DCS-3410 User Manual RS-485...

  • Page 38: Maintenance

    Camera Name: Create a unique name for your camera, in which you can access the camera by using this name in your web- browser. For example: http://DCS-3410 (By default). Enable OSD: Select this option to enable the On-Screen Display feature for your camera.

  • Page 39: Backup And Restore

    Load Configuration. Restore To Factory You may reset your camera and restore the factory Default: settings to your camera by clicking Restore Factory Defaults. Reboot Device: This will restart your camera. D-Link DCS-3410 User Manual Backup and Restore...

  • Page 40: Firmware Upgrade

    Your current firmware version and date will be displayed on your screen. You may go to the D-Link Support Page to check for the latest firmware version available. To upgrade the firmware on your DCS-3410, please download and save the latest firmware version from the D-Link Support Page to your local hard drive.

  • Page 41: Status

    Section 3 - Configuration Status Device Info This page displays all the details information about your device and network connection. D-Link DCS-3410 User Manual...

  • Page 42: Logs

    Section 3 - Configuration Logs This page displays the log information of your camera. You may also download the information by clicking Download. D-Link DCS-3410 User Manual...

  • Page 43: Help

    Section 3 - Configuration Help D-Link DCS-3410 User Manual...

  • Page 44: D-Viewcam Installation

    D-ViewCam software is included for the administrator to manage up to 3 D-Link IP cameras remotely. You may now use the software to configure all the advanced settings for your cameras. D-ViewCam is a comprehensive management tool for IP surveillance.
  • Page 45 Click Next to continue. Click Next Click Browse if you would like to choose a specific folder for the installation, otherwise click Next to continue. Click Next D-Link DCS-3410 User Manual...
  • Page 46 Click Next to start the installation. Note: The D-ViewCam installation process may take several minutes to complete. Click Next Click Finish to complete the installation. Click Finish D-Link DCS-3410 User Manual...

  • Page 47: Add A Camera

    Add a Camera This section will show you how to start and add a camera to the D-ViewCam system. To start D-ViewCam, select Start > All Programs > D-Link > D-Link D-ViewCam. Enter Admin as the default user name and leave the password blank.
  • Page 48 Section 4 - D-ViewCam Installation Welcome to the Add Camera Wizard. Use this wizard to add your cameras to the D-ViewCam system. Note: Use the left or right arrow to navigate the wizard. Click / Next to continue. Click Next D-Link DCS-3410 User Manual...
  • Page 49 LAN with same subnet. The system will place all the cameras under the default map called My Map. Click Next to continue. If you choose Add Manually, you will need to enter the IP address of the camera(s). Click Next to continue. D-Link DCS-3410 User Manual...
  • Page 50 • Non-Office Hours Only: Continuously monitoring during non-office hours (06:00 PM to 08.00 AM) and ONLY recording when motion is detected. Note: Excluding 24/7 Continuous Recording, other schedule recording types can ONLY do recording when motion is detected. Please refer to page 32 for more information. Click Next to continue. D-Link DCS-3410 User Manual...
  • Page 51 Click Next to continue. The Add Camera wizard is now complete. Click Close to access the D-ViewCam’s main screen. Your D-ViewCam Installation is Complete! Note: Please refer to the D-ViewCam user manual for information about using D-ViewCam. D-Link DCS-3410 User Manual...

  • Page 52: Troubleshooting

    7. Can the Network Camera be setup as a PC-cam on a computer? No, the DCS-3410 Network Camera is used only on an wireless 80.11g, Ethernet or Fast Ethernet network. 8. Can the DCS-3410 be connected to the network if it consists of only private IP addresses? Yes, the Network Camera can be connected to a LAN with private IP addresses.
  • Page 53 10. Why am I unable to access the DCS-3410 from a Web browser? If a router or firewall is used on the network, the correct ports for the DCS-3410 may not be configured on the router or firewall. To correct the problem, you need to determine if the DCS-3410 is behind a router or firewall and if the router or firewall is properly configured for the ports the DCS-3410 is using.
  • Page 54 The configuration on the Network Camera image display is incorrect. Through the Advanced > Image Setting section of the Web management you need to adjust the image related parameters such as brightness, contrast, hue and power line frequency for fluorescent light. D-Link DCS-3410 User Manual...

  • Page 55: Networking Basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 56: Statically Assign An Ip Address

    000 - From the desktop, right-click My Network Places > Properties. ® Step 2 Right-click on the Local Area Connection which represents your D-Link network adapter and select Properties. Step 3 Highlight Internet Protocol (TCP/IP) and click Properties. Step 4 Click Use the following IP address and enter an IP address that is on the same subnet as your network or the LAN IP address on your router.

  • Page 57: Technical Specifications

    • Support Full-Duplex operations • MDI/MDIX auto-negotiation • 80.3x Flow Control support for Full-Duplex mode • Supported IEEE 80.3af standard (PoE) D-Link DCS-3410 User Manual Technical Specifications 4dB +/- 3dB, Omni-directional I/O Connector  Inputs (Photo relay, Active High: Dropout: 0 VDC) 1 Output (photo relay, Close circuit current: AC 70mA or DC 100mA;...
  • Page 58 • Up to 30 frames at 704 x 480 (NTSC) / 704x576(PAL) • Up to 30 frames at 35 x 40 (NTSC) / 35x88 (PAL) • Up to 30 frames at 176 x 10 (NTSC) / 176x144(PAL) D-Link DCS-3410 User Manual Low Lux 0.3 lux @ F1.6...
  • Page 59 Environmental conditions will adversely affect wireless signal range. Range varies depending on country’s regulation. The DCS-3410 doesn’t include 5.5-5.35GHz & 5.47~5.75GHz. D-Link DCS-3410 User Manual...

  • Page 60: Contacting Technical Support

    • Hardware Revision (located on the label on the bottom of the Network Camera (e.g. rev A1)) • Serial Number (s/n number located on the label on the bottom of the Network Camera). You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues.

  • Page 61: Warranty

    Warranty Period or ninety (90) days, whichever is longer, and is subject to the same limitations and exclusions. If a material defect is incapable of correction, or if D-Link determines that it is not practical to repair or replace the defective Hardware, the actual price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware.
  • Page 62 Software Warranty Period, the magnetic media on which D-Link delivers the Software will be free of physical defects. The customer’s sole and exclusive remedy and the entire liability of D-Link and its suppliers under this Limited Warranty will be, at D-Link’s option, to replace the non-conforming Software (or defective media) with software that substantially conforms to D-Link’s functional specifications for the Software or to refund...
  • Page 63 • The customer is responsible for all in-bound shipping charges to D-Link. No Cash on Delivery (“COD”) is allowed. Products sent COD will either be rejected by D-Link or become the property of D-Link. Products shall be fully insured by the customer and shipped to D- Link Systems, Inc., 17595 Mt.

  • Page 64: Limitation Of Liability

    FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT.
  • Page 65 The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. D-Link DCS-3410 User Manual...
  • Page 66 Appendix D - Warranty For detailed warranty information applicable to products purchased outside the United States, please contact the corresponding local D-Link office. Industry Canada Notice: This device complies with RSS-10 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and () this device must accept any interference received, including interference that may cause undesired operation.

  • Page 67: Registration

    Appendix E - Registration Registration Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. Version 1.0 May 1, 008 D-Link DCS-3410 User Manual...
