- Page 1 Home Xerxes Ceiling Fan User Manual Read and save these instructions before use Model #51905...
-
Page 2: Package Contents
PACKAGE CONTENTS Mounting Bracket Canopy Mounting Bracket Screw (x 4) Canopy Cover Downrod Downrod Pin Downrod Clip Yoke Cover Set Screw (x 2) Yoke Motor Assembly Blade Arm (x 8) Motor Screw (x 24) Fitter Plate Fitter Plate Screw (x 3) Blade (x 8) Light Kit Lens Cover... -
Page 3: Safety Information
THANK YOU Honeywell Ceiling Fans feature a collection of fans in various sizes and specifications to ensure your choice of indoor or outdoor fan delivers optimum performance for your room’s size. You can trust the quality of Honeywell Ceiling Fans to deliver maximum airflow and stylish lighting options. -
Page 4: Care And Maintenance
SAFETY INFORMATION CAUTION: CAN ICES-003 (B) / NMB-003 (B) CAN ICES-005 (B) / NMB-005 (B) This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device (if applicable). -
Page 5: Initial Installation
PREPARATION Before beginning the assembly of this product, ensure all parts are present. Compare all parts with the package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated assembly time: 2 hours Tools required (not included): Flat-head and Phillips Screwdriver, Safety Glasses, Step Ladder, Wire Cutters and Wire Strippers. - Page 6 STANDARD OR ANGLE MOUNT INSTRUCTIONS 1. Remove the downrod clip and downrod pin from the downrod. Then partially loosen the set screws in the yoke at the top of the motor assembly (Figure 3.1). 2. Insert the downrod through the canopy and yoke cover. Feed the wires and braided cable from the fan through the downrod (Figure 3.2).
-
Page 7: Final Installation
SECONDARY HANGING SYSTEM INSTRUCTIONS For installation in the United States: Building codes in the U.S.A. do not require installation of a Secondary Hanging System. If desired, the braided cable can be cut and removed using wire cutters (sold separately). Skip to FINAL INSTALLATION. For installation in Canada: In compliance with building codes in Canada, installation of the Secondary Hanging System is required. - Page 8 FINAL INSTALLATION 4. Partially insert three blade screws through the blade arm and the blade. Secure each blade screw with a blade screw cap, starting with the one in the middle. Repeat this step for the remaining blades and blade arms (Figure 5.4). 5.
- Page 9 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS 1. Batteries were preinstalled in the battery compartment of the remote in remote pack. Pull the plastic film in the direction of the arrow to remove which will activate the batteres (Figure 6.1). 2. To operate the fan using the remote, press and release the following buttons (Figure 6.2): LED Indicator - Indicates the six speeds of the fan.
-
Page 10: Troubleshooting
TROUBLESHOOTING If you experience any faults, please check the Troubleshooting section below. If a problem cannot be remedied or you are experiencing difficulty in installation, please contact Customer Service: 1-877-361-3883, Monday - Friday, 8am - 5pm, Central. WARNING: Shut off the power supply before you begin any maintenance task. PROBLEM CORRECTIVE ACTION 1. -
Page 11: Limited Lifetime Warranty
Blade (x 8) 4A086530001 Remote Pack 4A000026470 HW Hardware Bag 4A000026410 The Honeywell Trademark is used under license from Honeywell International Inc. Honeywell International Inc. makes no representations or warranties with respect to this product. This product is manufactured for Hong Kong China Electric Appliance, LTD.
