- Page 1 Home Graceshire Ceiling Fan User Manual Read and save these instructions before use Model #51859, 51860...
-
Page 2: Package Contents
PACKAGE CONTENTS Mounting Bracket Mounting Bracket Screw (x4) Motor Assembly Blade (x5) Fitter Plate Fitter Plate Screw (x3) Light Pan Light Pan Screw (x3) Light Kit Bowl Assembly Remote Pack Blade Balancing Kit HARDWARE CONTENTS Wire Connector (x3) Blade Screw (x15) Blade Washer (x15) Secondary Support Screw Secondary Spring... -
Page 3: Safety Information
THANK YOU Honeywell Ceiling Fans feature a collection of fans in various sizes and specifications to ensure your choice of indoor or outdoor fan delivers optimum performance for your room’s size. You can trust the quality of Honeywell Ceiling Fans to deliver maximum airflow and stylish lighting options. -
Page 4: Care And Maintenance
SAFETY INFORMATION CAUTION: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device (if applicable). CAN ICES-003 (B) / NMB-003 (B) CAN ICES-005 (B) / NMB-005 (B) This device complies with Part 15 of the FCC Rules. -
Page 5: Initial Installation
PREPARATION Before beginning the assembly of this product, ensure all parts are present. Compare all parts with the package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated assembly time: 2 hours Tools required (not included): Phillips and Flat-head Screwdrivers, Safety Glasses, Step Ladder, Wire Cutter, and Wire Stripper. -
Page 6: Final Installation
SECONDARY HANGING SYSTEM INSTRUCTIONS For installation in the United States: Building codes in the U.S.A. do not require installation of a Secondary Hanging System. If desired, the braided cable can be cut and removed using wire cutters (sold separately). Skip to FINAL INSTALLATION. For installation in Canada: In compliance with building codes in Canada, installation of the Secondary Hanging System is required. - Page 7 FINAL INSTALLATION 4. Remove one of the three fitter plate screws preassembled to the fitter plate and loosen the other two but do not remove. Feed the single-pin connector through the center hole in the light pan. Align the keyhole slots in the light pan with the loosened screws in the fitter plate.
- Page 8 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS 1. Remove the battery door from the back of the remote using a flat-head screwdriver (not included). Insert the two CR2032 batteries into the remote; ensure the positive pole of the batteries face up (as pictured) and then replace the battery door. Press the FAN POWER button to ensure the LED indicator illuminates and the fan turns on (Figure 5.1).
-
Page 9: Troubleshooting
TROUBLESHOOTING If you experience any faults, please check the Troubleshooting section below. If a problem cannot be remedied or you are experiencing difficulty in installation, please contact Customer Service: 1-877-361-3883, Monday-Friday, 8am - 5pm, Central Time. WARNING: Shut off the power supply before you begin any maintenance task. PROBLEM CORRECTIVE ACTION 1. -
Page 10: Limited Lifetime Warranty
4L000016870 4L000016870 Remote Pack 4A000023600 4A000023600 Hardware Bag The Honeywell Trademark is used under license from Honeywell International Inc. Honeywell International Inc. makes no representations or warranties with respect to this product. This product is manufactured for Hong Kong China Electric Appliance, LTD.
