- Page 1 Network Appliance Platform Hardware Platforms for Industrial SD-WAN ISD-O370 User Manual Version: 1.6 Date of Release:2023-06-20 Arrow.com. Downloaded from...
- Page 2 - assumed to be qualified in the servicing of computer equipment, such as professional system integrators, or service personnel and technicians. The latest version of this document can be found on Lanner’s official website, available either through the product page or through the Lanner Download Center page with a login account and password.
- Page 3 ISD-O370 User Manual Taiwan Corporate Headquarters China Lanner Electronics Inc. Beijing L&S Lancom Platform Tech. Co., Ltd. 7F, No.173, Sec.2, Datong Rd. Guodong LOFT 9 Layer No. 9 Huinan Road, Xizhi District, New Taipei City 22184, Huilongguan Town, Changping District, Beijing...
- Page 4 ISD-O370 User Manual Intel® and Intel® Atom® are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp. All other product names or trademarks are properties of their respective owners.
- Page 5 ISD-O370 User Manual Follow these guidelines to ensure general safety: Keep the chassis area clear and dust-free during and after installation. Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and roll up your sleeves.
- Page 6 ISD-O370 User Manual Risque d’explosion si la pile est remplacée par une autre d’un mauvais type. Jetez les piles usagées conformément aux instructions. L’installation doit être effectuée par un électricien formé ou une personne formée à l’électricité connaissant toutes les spécifications d’installation et d’appareil du produit.
- Page 7 ISD-O370 User Manual The device can only be used in a fixed location such as a lab or a machine room. L’appareil ne peut être utilisé que dans un lieu fixe, tel qu’un laboratoire ou une salle de machines. The PoE networks without routing to the outside plant that installation instructions clearly state, therefore, these circuits are not considered external circuit.
- Page 8 ISD-O370 User Manual Arrow.com. Downloaded from...
- Page 9 IoT and SD-WAN in the most demanding conditions. ISD-O370 is IP67 rated ingress protection and MIL-STD-810G standard compliant resistant to shock and vibration. ISD-O370 is equipped with M12 connectors designed to ensure a correct sealing to achieve IP67 rating.
- Page 10 Note: Recommend preinstallation by Lanner MV31-W 5G KIT ISD-O370C FG (5G w/ Internal Cables & Antenna kit) PSF9697-001 Note: Recommend preinstallation by Lanner WNFB-265AXI WI-FI-6 KIT ISD-O370 FG (Wi-Fi 6 w/ Internal Cables & Antenna kit) PSF9698-001 Note: Recommend preinstallation by Lanner Arrow.com.
- Page 11 ISD-O370 User Manual Form Factor Desktop Processor Options Intel® Atom® C3000 (Denverton) CPU Socket Onboard Platform Chipset Security Acceleration Intel® QuickAssist Technology BIOS AMI SPI Flash BIOS Technology DDR4 2133 MT/s ECC SODIMM System Memory Max. Capacity Up to 64GB, Default ECC RAM 16GB...
- Page 12 ISD-O370 User Manual ISD-O370C/D/E/F/G/H/I/J Description 1x M12 K-coded 5-pin Male Connector with Isolation for Power Source, (1.5KV DC) DC Input Signals Signals V-in 5(PE) Chassis_GND PoE+ Port 1/ 1x M12 X-coded 8-pin Female Connector GbE PoE+ Port LAN Port 6...
- Page 13 ISD-O370 User Manual ISD-O370K/L Description 1x M12 K-coded 5-pin Male Connector with Isolation for Power Source, (1.5KV DC) DC Input Signals Signals V-in 5(PE) Chassis_GND LAN Port 4 GbE LAN Ethernet Port with SR-IOV, M12 X-coded 8-pin Female Connector LAN Port 3...
- Page 14 ISD-O370 User Manual Description 5G Antennas 4x SMA connector for 5G module Wi-Fi Antennas 2x SMA connector for Wi-Fi module Arrow.com. Downloaded from...
- Page 15 ISD-O370 User Manual The block diagram indicates how data flows among components on the motherboard. Please refer to the following figure for your motherboard’s layout design. Arrow.com. Downloaded from...
- Page 16 ISD-O370 User Manual The block diagram indicates how data flows among components on the motherboard. Please refer to the following figure for your motherboard’s layout design. Arrow.com. Downloaded from...
- Page 17 ISD-O370 User Manual The system can be mounted on a flat surfaced wall. Please take the following into considerations when mounting the system onto the wall. Please note anchoring wall plugs and screws are not included in the package content, and the recommended screw sizes are as below.
- Page 18 ISD-O370 User Manual 4. Drive four (4) hex head lag screws into the anchoring wall plugs to secure the system. Size: 1/4” x 1 1/2” Hex Head Screw Arrow.com. Downloaded from...
- Page 19 ISD-O370 User Manual The system has AMI BIOS built-in, with a SETUP utility that allows users to configure required settings or to activate certain system features. Pressing the <Tab> or <Del> key immediately allows you to enter the Setup utility.
- Page 20 ISD-O370 User Manual Setup main page contains BIOS information and project version information. Feature Description BIOS Vendor: American Megatrends Core Version: AMI Kernel version, CRB code base, X64 BIOS Compliancy: UEFI version, PI version Information Project Version: BIOS release version...
- Page 21 ISD-O370 User Manual Select the Advanced menu item from the BIOS setup screen to enter the “Advanced” setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description Enabled USB Power Enables or disables USB port power.
- Page 22 ISD-O370 User Manual Feature Options Description Security Enables or disables BIOS support for security device. By Enabled Device disabling this function, OS will not show Security Device. Disabled Support TCG EFI protocol and INT1A interface will not be available. SHA-1 PCR Enabled Enables or disables SHA-1 PCR Bank.
- Page 23 ISD-O370 User Manual Platform Enabled Enables or disables Platform Hierarchy. Hierarchy Disabled Storage Enabled Enables or disables Storage Hierarchy. Hierarchy Disabled Endorsement Enabled Enables or disables Endorsement Hierarchy. Hierarchy Disabled Select the TCG2 Spec Version, TPM2.0 UEFI TCG_1_2 TCG_1_2: Supports the Compatible mode for Win8/Win10...
- Page 24 ISD-O370 User Manual Arrow.com. Downloaded from...
- Page 25 ISD-O370 User Manual Feature Options Description Enabled Serial Port Enables or disables Serial Port 1. Disabled Device IO=3F8h; IRQ = 4 Settings RS232 COM1 MODE RS485 Select COM mode as RS232/485/422. RS422 Arrow.com. Downloaded from...
- Page 26 ISD-O370 User Manual Feature Options Description Serial Port Enabled Enable or Disable Serial Port 2. Disabled Device Settings IO=2F8h; IRQ = 3 Arrow.com. Downloaded from...
- Page 27 ISD-O370 User Manual Arrow.com. Downloaded from...
- Page 28 ISD-O370 User Manual Feature Options Description COM0 Enabled Console Enables or disables Console Redirection Disabled Redirection Arrow.com. Downloaded from...
- Page 29 ISD-O370 User Manual Feature Options Description VT100: ASCII char set VT100 VT100+:Extends VT100 to support color, VT100+ function keys, etc. Terminal Type VT-UTF8 VT-UTF8:Uses UTF8 encoding to map Unicode ANSI chars onto 1 or more bytes ANSI: Extended ASCII char set...
- Page 30 ISD-O370 User Manual Key Support Enabled ANSI/VT100 terminals Disabled With this mode enabled, only text will be sent. Recorder Mode Enabled This is to capture Terminal data. VT100 LINUX XTERM86 Putty KeyPad Selects FunctionKey and KeyPad on Putty. ESCN VT400 Arrow.com.
- Page 31 ISD-O370 User Manual Feature Options Description Redirection COM COM0 Select a COM port to display redirection of Port Legacy OS and Legacy OPROM Messages. 80x24 On Legacy OS, the Number of Rows and Resolution 80x25 Columns supported redirection. When Bootloader is selected, Legacy Console...
- Page 32 ISD-O370 User Manual Feature Options Description Enable or Disables 64bit capable Devices to be Above 4G Disabled Decoded in Above 4G Address Space (Only if Decoding Enabled System supports 64 bit PCI decoding). If the system has SR-IOV capable PCIe Devices,...
- Page 33 ISD-O370 User Manual Feature Options Description Disabled CSM Support Enables or disables CSM Support Enabled Do Not Launch Controls the execution of UEFI and Legacy PXE Network UEFI OpROM Legacy Do Not Launch Controls the execution of UEFI and Legacy...
- Page 34 ISD-O370 User Manual Feature Options Description Enables Legacy USB support. Enabled Auto option disables legacy support if no USB devices are Legacy USB Disabled connected; Support Auto Disabled option will keep USB devices available only for EFI applications. Enabled This is a workaround for OSes without XHCI hand-off support.
- Page 35 ISD-O370 User Manual Select the IntelRCSetup menu item from the BIOS setup screen to enter the Platform Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description Relax Security Disable Relaxes the security configuration to be able to use BIOS...
- Page 36 ISD-O370 User Manual Feature Options Description Fast String Disable When enables, enable fast strings for REP MOVS/STOS. Enable Execute Disable Bit Disable When disabled, forces the XD feature flag to always return 0. Enable Disable Enables the Vanderpool Technology, takes effect after reboot.
- Page 37 ISD-O370 User Manual Feature Options Description Enables/Disables fast boot which skips memory training Disabled Fast Boot and attempts to boot using fast known good Enabled configuration. VT-d Disable Option to enable /Disable VT-d. Enable VT-d Interrupt Disable Option to enable /Disable VT-d Interrupt remapping.
- Page 38 ISD-O370 User Manual Arrow.com. Downloaded from...
- Page 39 ISD-O370 User Manual Feature Options Description Enable controller Enabled Enables/Disables SATA Controller if supported by current Disabled CPU sku Arrow.com. Downloaded from...
- Page 40 ISD-O370 User Manual Feature Options Description Enable/disable port Enabled Enables/Disables SATA Controller port. Disabled Arrow.com. Downloaded from...
- Page 41 ISD-O370 User Manual Feature Options Description IQAT Enabled Hides IQAT device from and OS.. Disabled Set IQAT FUSECTL Enabled Enable/Disable the setting of IQAT FUSECTL Register Disabled Set 64B MRR/MPL Enabled Enable the setting of 64B MRR/MPL in IQAT DevCtl...
- Page 42 ISD-O370 User Manual Select the Security menu item from the BIOS setup screen to enter the Security Setup screen. Users can select any of the items in the left frame of the screen. Feature Description If ONLY the Administrator's password is set, it only limits access to Administrator Password Setup and is only asked for when entering Setup.
- Page 43 ISD-O370 User Manual Feature Options Description Secure Boot is activated when Platform Key(PK) is Disabled Secure Boot Enable enrolled, System mode is User/Deployed, and CSM Enabled function is disabled. Customizable Secure Boot mode: In Custom mode, Standard Secure Boot Mode...
- Page 44 ISD-O370 User Manual Feature Options Description Factory Key Disabled Provision factory default keys on next re-boot only when Provision Enabled System in Setup Mode. Restore Factory Force System to User Mode. Configure NVRAM to contain None keys OEM-defined factory default Secure Boot keys.
- Page 45 ISD-O370 User Manual Select the Boot menu item from the BIOS setup screen to enter the Boot Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description Setup Prompt The number of seconds to wait for setup activation key.
- Page 46 ISD-O370 User Manual Select the Save and Exit menu item from the BIOS setup screen to enter the “Save and Exit” Setup screen. Users can select any of the items in the left frame of the screen. ■ Save Changes and Reset When Users have completed the system configuration changes, select this option to save the changes and exit from BIOS Setup in order for the new system configuration parameters to take effect.
- Page 47 ISD-O370 User Manual ■ Discard Changes and Exit Select this option to quit Setup without saving any modifications to the system configuration. The following window will appear after the “Discard Changes and Exit” option is selected. Select “Yes” to Discard changes and Exit Setup.
- Page 48 Adverse external conditions such as power surges and dips, thunderstorm activity, acts of God, acts of terrorism, damage caused by vermin or any other act or circumstances beyond Lanner’s control. 1. To obtain an RMA number, simply fill out and fax the “RMA Request Form“ to your supplier.
- Page 49 When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed. Arrow.com. Downloaded from...
