5.1 Periodic Replacement Parts

5.1.1 Periodic Replacement Parts

5.2 Consumable Parts

5.2.1 Consumable Parts
Service WASTE INK BOX UNIT (L)
WASTE INK ABSORBER UNIT
PLATEN FAN DUCT UNIT
PLATEN SUCTION FAN UNIT
WASTE INK BOX UNIT
CARRIAGE UNIT
MOUNT, MULTI SENSOR
REFERENCE
SCALE, LINEAR
TUBE UNIT
MULTI SENSOR UNIT
PURGE UNIT
WASTE INK RECEPTACLE UNIT
HEAD MANAGEMENT SENSOR
UNIT
MOTOR, DC BRUSHLESS
FEED MOTOR ASS'Y
ROLLER, PICK-UP
MIST FAN UNIT
CUTTER
User See "Product Overview> Features> Consumables"
- Maintenance Kit
MAINTENANCE KIT A
MAINTENANCE KIT D
After supplies have been replaced, execute [INITIALIZE] > [PARTS COUNTER] > [PARTS xx] in service mode to initialize (clear) the parts counter information.
Level
User
Service Personnel
Consumables
Name Part number
QM3-4814
QL2-2822
QM3-4816
QM3-4827
QM3-4828
QM3-4835
QL2-2840
QC3-1889
QM3-4834
QM3-5240
QM3-4847
QM3-4912
QM3-4844
QK1-5211
QM3-5246
QC3-0208
QM3-4846
QM3-4873
Kit name
Periodic Replacement Part
None
None
Life
Q'ty PARTS xx
sheets/A0
1 25000 A1
3 25000 A2/A3/A4
1 25000 A5
1
1
1 25000 D1/D2/D3
1 25000 D1/D2/D3/D5
1 25000 D2
1 25000 D4
1 25000 D5
1 25000 H1/H2
1 25000 H2
1 25000 K1
1 25000 M1
1 50000 P1
1 25000 S1
2 50000 V1
1 100000 Y1
Parts number Life
QY6-1328 25000
QY6-1329 25000
Service Mode
COUNTER x States (Error Code)
A OK/W1/E146-4001
D OK/W1/W2
D OK/W1/E144-4047
D OK/W1/W2
H OK/W1/E141-4046
H OK/W1/E144-404F
K OK/W1/E194-404A
M OK/W1/W2
P OK/W1/W2
S OK/W1/W2
V OK/W1/E146-4001
Y OK/W1/W2
Counter name
A
D
