1.2 Features
1.2.1 Features
- Media pass in widths up to 44 inches (1117.6 mm).
- Large ink tanks reduce the need for frequent ink replacement.
- Uninterrupted printing from subtanks.
- BK and MBK inks are loaded concurrently to eliminate the need for their replacement.
- Durability will be added by maintenance kit.
- Large LCD panel displays more information and makes operations easier.
- High resolutions of 2400 x 1200 dpi maximum, coupled with the exceptionally light-fast, water-proof and ozone-proof five-color inks of Y, M, C, BK and MBK,
deliver high-quality photographic picture quality.
- USB2.0 Hi-speed interface and 10Base-T/100Base-TX in standard support of a TCP/IP network.
- Barcodes printed on roll media makes measuring the remaining roll length more manageable.
- Borderless four-side printing support (roll media) reduces laborious cutting work, easing the job of creating posters to a significant degree.
- High-speed printing with a 1-inch head for each color (1,280 nozzles), under bidirectional print control.
- The hard disk is installed for better print job management and for driving on night time.
- The product allows two roll medias to be loaded simultaneously, making it possible to mix different sizes or types of paper in a single print job or use two roll
medias of the same paper size to fulfill bulk print needs.
- Ready for CAD drawings output on the HP-GL/2 and HP-RTL.
- The product comes with a wheeled output stacker to print lengthy materials or load bulk print jobs.
Functional enhancements new to this model include:
The processing ability of the printed data will enhance by increase of hard disk drive and memory capacity.
1.2.2 Printhead
The printhead that mounts on the carriage is an integrated six-color disposable printhead.
It has 2,560 nozzles for each color, comprising two rows of 1,280 nozzles each arranged in a staggerd pattern.
If print quality does not improve despite carrying out the specified cleaning, the printhead must be replaced with a new one.
1.2.3 Ink Tank
The ink tanks are disposable.
An ink tank should be replaced when an ink tank replacement prompt message appears.
To install ink tanks, open the ink tank cover of the printer. Ink tanks are furnished with a notch for preventing incorrect installation, which will allow the tanks to
be installed at the position marked in the right color and nowhere else.
The ink tanks are also available in two capacities: 330 ml and 700 ml.
The ink tanks are available in the four dye ink colors of black, cyan, magenta and yellow and the pigment ink color of mat black.
F-1-3
F-1-4
Chapter 1
0025-9206
0013-2742
0020-5419
1-3
