- Page 1 SABAL PALM 52” CEILING FAN MODEL #50204 Español p. 21 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-361-3883, Monday - Thursday, 8 am - 6 pm, EST and Friday, 8 am - 5 pm, EST.
-
Page 2: Table Of Contents
WELCOME TABLE OF CONTENTS PREPARATION Care and Maintenance ......2 Before beginning the assembly of this product, ensure that all parts are present. -
Page 3: Package Contents
PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: 1. Canopy 2. Mounting Bracket 3. Canopy Cover 4. Blade (5) 5. Downrod 6. Blade Arm (5) 7. Bulb (3) 8. Yoke Cover 9. Motor Housing 10. -
Page 4: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product. • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. • Make sure that all electrical connections comply with local codes, ordinances, the National Electrical Code, and ANSI/NFPA 70-199. -
Page 5: Mounting Options
MOUNTING OPTIONS DANGER Fig. 1 Turn off the circuit breakers and the wall switch to the fan supply line leads. Failure to disconnect the power supply prior to installation may result in serious injury or death. 1. Your fan has 3 mounting options: •... -
Page 6: Mounting Bracket Installation
MOUNTING BRACKET INSTALLATION 4. Loosen all four mounting bracket screws. Fig. 4 Completely remove the two mounting bracket screws and washers from the round holes of Mounting Mounting canopy. Set aside for later use. Detach mounting Bracket Bracket Screws bracket from canopy (Fig. 4). Washer Mounting Bracket Washer... -
Page 7: Standard Or Angle Mounting Instructions
STANDARD OR ANGLE MOUNTING INSTRUCTIONS 6. Partially loosen the set screws in the yoke at the Fig. 6 top of the motor housing (Fig. 6). Set Screws Fig. 7 7. Remove the downrod pin and downrod clip from the downrod (Fig. 7). Downrod Clip Downrod Pin... - Page 8 STANDARD OR ANGLE MOUNTING INSTRUCTIONS 9. Slide the downrod into the yoke of the motor Fig. 9 Downrod housing, align the holes, and re-install the downrod pin and downrod clip. Then re-tighten the set Downrod screws (Fig. 9). Downrod Downrod Pin Clip Set Screw Downrod Clip...
- Page 9 STANDARD OR ANGLE MOUNTING INSTRUCTIONS 12. Install the downrod ball into the mounting bracket Fig. 12 opening. Align the slot in the ball with the tab in the mounting bracket. The downrod should not rotate if installed correctly (Fig. 12). Slot Mounting Bracket...
-
Page 10: Closemount Instructions
CLOSEMOUNT INSTRUCTIONS 13. Remove the canopy cover from the bottom of the Fig. 13 canopy (Fig. 13) Helpful Hint: The downrod, hanging ball, and canopy cover are not used in this type of installation. Canopy Cover Canopy Closemount Fig. 14 14. -
Page 11: Wiring
WIRING Fig. 16 CAUTION Be sure outlet box is properly grounded or that a ground (green or bare) wire is present. Black (live) WARNING White (neutral) If house wires are different colors than referred to in the following step, stop immediately. A professional Bare/Green (ground) electrician is recommended to determine wiring. -
Page 12: Canopy Installation
CANOPY INSTALLATION 18. Lift the canopy up so the partially installed mounting Fig. 18 bracket screws are situated in the L-slots on each side of the canopy. Rotate the canopy clockwise and install the remaining mounting bracket screws and washers from Step 4 (Fig. 18). Mounting Mounting Bracket... -
Page 13: Blade Installation
BLADE INSTALLATION 19. Remove the ten motor screws from underside of Fig. 19 motor and save for blade arm attachment. Discard the plastic motor blocks but keep the motor screws (Fig. 19). Motor Motor Screw Block Motor Screw Motor Block 20. -
Page 14: Light Kit Installation
LIGHT KIT INSTALLATION To install the fan without a light kit, skip to Step 28. Fig. 22 22. Remove screws and washers from switch housing. Then connect the single pin connectors from the switch housing to the single pin connectors from the light kit -- black to black and white to white. -
Page 15: Finial Cap
LIGHT KIT INSTALLATION 25. Remove the pre-installed rubber washer, nut, finial Fig. 25 cap, and finial from the light kit (Fig. 25). Rubber Washer Finial Cap Finial 26. Feed pull chain through the center hole in the glass Fig. 26 globe, rubber washer and nut. - Page 16 INSTALLATION WITHOUT LIGHT KIT 28. (Optional) To install the fan without a light kit: Fig. 28 Hex Nut Unscrew the hex nut located inside the switch Light housing cap from the threaded rod in the center Pull Chain of the cap to remove the light kit from the switch housing cap (Fig.
-
Page 17: Operating Installation
OPERATING INSTRUCTIONS 30. Use the fan reverse switch, located on the side Fig. 30 of the light kit, to optimize your fan for seasonal performance (Fig. 30). Using a ceiling fan will allow you to raise your thermostat in the summer and lower your thermostat in the winter without sacrificing comfort. -
Page 18: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call the customer service department at 1-877-361-3883, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday. MODEL 50204 PIECE DESCRIPTION PART # Blade Arm 50204-A Blade 50204-B Glass Shade 50204-C Loose parts bags containing (not... -
Page 19: Troubleshooting
TROUBLESHOOTING At least twice each year, lower the canopy to check the downrod assembly, and tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. You may occasionally apply a light coat of furniture polish to wood blades for added protection. -
Page 20: Limited Lifetime Warranty
1-877-361-3883, Monday - Thursday, 8 am - 6 pm, EST and Friday, 8 am - 5 pm, EST.. Please have a copy of the receipt as proof of purchase. The Honeywell Trademark is used under license from Honeywell International Hong Kong China Electric Appliance Manufacture Co., Ltd.
