- Page 1 BIRNHAM 52” CEILING FAN MODEL #50191,50192 Español p. 20 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-361-3883, Monday - Thursday, 8 am - 6 pm, EST and Friday, 8 am - 5 pm, EST.
-
Page 2: Table Of Contents
WELCOME TABLE OF CONTENTS PREPARATION Care and Maintenance ......2 Before beginning the assembly of this product, ensure that all parts are present. -
Page 3: Package Contents
PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: 1. Motor Housing 2. Light Kit Fitter 3. Blade Arm (5) 4. Canopy 5. Mounting Bracket 6. Canopy Cover 7. Optional Cap 8. Downrod Assembly 9. -
Page 4: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product. • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. • Make sure that all electrical connections comply with local codes, ordinances, the National Electrical Code, and ANSI/NFPA 70-199. -
Page 5: Mounting Options
MOUNTING OPTIONS DANGER Fig. 1 Turn off the circuit breakers and the wall switch to the fan supply line leads. Failure to disconnect the power supply prior to installation may result in serious injury or death. 1. Your fan has 3 mounting options: •... -
Page 6: Mounting Bracket Installation
MOUNTING BRACKET INSTALLATION 4. Loosen all four mounting bracket screws. Remove Fig. 4 the two canopy screws and washers from the round holes of canopy. Set aside for later use. Detach Mounting mounting bracket from canopy (Fig. 4). Mounting Bracket Bracket Screws Washer... -
Page 7: Standard Or Angle Mounting Instructions
STANDARD OR ANGLE MOUNTING INSTRUCTIONS 6. Partially loosen the two set screws in the yoke at Fig. 6 the top of the motor housing (Fig. 6). Set Screws 7. Remove the downrod pin and downrod clip from Fig. 7 the downrod (Fig. 7). Downrod Clip Downrod Pin... - Page 8 STANDARD OR ANGLE MOUNTING INSTRUCTIONS 9. Slide the downrod into the yoke of the motor Fig. 9 housing, align the holes, and re-install the downrod Downrod pin and downrod clip. Then re-tighten the two set screws (Fig. 9). Downrod Downrod Clip Downrod Pin Set Screw...
- Page 9 STANDARD OR ANGLE MOUNTING INSTRUCTIONS 12. Install the downrod ball into the mounting bracket Fig. 12 opening. Rotate the fan and/or downrod until the slot in the downrod ball engages the tab in the mounting bracket. The rod should not rotate if installed correctly (Fig.
-
Page 10: Closemount Instructions
CLOSEMOUNT INSTRUCTIONS 13. Remove the canopy cover from the bottom of the Fig. 13 canopy (Fig. 13). Helpful Hint: Closemount-style mounting is more suitable for ceilings lower than 8 ft. (2,44 m) high. The downrod and canopy cover are not used in this type of installation. -
Page 11: Wiring
WIRING CAUTION Fig. 16 Be sure outlet box is properly grounded or that a ground (green or bare) wire is present. Black (live) WARNING White (neutral) If house wires are different colors than referred to in the following step, stop immediately. A professional Bare/Green (ground) electrician is recommended to determine wiring. -
Page 12: Canopy Installation
CANOPY INSTALLATION 18. Lift the canopy up so the partially installed canopy Fig. 18 screws are situated in the L-slots on each side of the canopy. Rotate the canopy clockwise and install the remaining canopy screws and washers from Step 4 (Fig.18). Mounting Mounting Bracket... -
Page 13: Blade Installation
BLADE INSTALLATION 19. Remove the ten motor screws from underside of Fig. 19 motor and save for blade arm attachment. Discard the five plastic motor blocks but keep the screws (Fig. 19). Motor Block Motor Screw Motor Screw Motor Block 20. -
Page 14: Light Kit Installation
LIGHT KIT INSTALLATION 22. (Optional) To install the fan without a light kit: Fig. 22 Remove the screws and washers from the upper switch housing. Align holes in optional cap with holes in upper switch housing. Re-insert screws and washers that were previously removed. Use a Phillips screwdriver (not included) to secure all screws (Fig. -
Page 15: Glass Shade
LIGHT KIT INSTALLATION 25. Remove the socket ring from the socket. Lift glass Fig. 25 shade onto the light kit fitter and secure with socket ring (Fig. 25). Repeat for each socket. Socket Glass Shade Socket Ring 26. Install the bulbs (Fig. 26). Fig. -
Page 16: Operating Installation
OPERATING INSTRUCTIONS 28. Use the fan reverse switch, located on the side Fig. 28 of the light kit, to optimize your fan for seasonal performance (Fig. 28). Using a ceiling fan will allow you to raise your thermostat in the summer and lower your thermostat in the winter without sacrificing comfort. -
Page 17: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call the customer service department at 1-877-361-3883, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday. Model 50191 Model 50192 PIECE DESCRIPTION PART# PART# Blade Arm 50191-A 50192-A Blade 50191-B... -
Page 18: Troubleshooting
TROUBLESHOOTING At least twice each year, lower the canopy to check the downrod assembly, and then tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. You may occasionally apply a light coat of furniture polish to wood blades for added protection. -
Page 19: Limited Lifetime Warranty
Monday - Thursday, 8 am - 6 pm, EST and Friday, 8 am - 5 pm, EST. Please have a copy of the receipt as proof of purchase. The Honeywell Trademark is used under license from Honeywell International Hong Kong China Electric Appliance Manufacture Co., Ltd.
