CAUTION: Do not operate the server for long periods with the access panel open or removed. Operating
the server in this manner results in improper airflow and improper cooling that can lead to thermal
damage.
Procedure
1. Power down the server.
2. Extend the server from the rack.
Open or unlock the locking latch, slide the access panel to the rear of the chassis, and remove the access
panel.

Install the access panel

Procedure
1. Place the access panel on top of the server with the latch open.
Allow the panel to extend past the rear of the server approximately 1.25 cm (0.5 in).
2. Push down on the latch.
The access panel slides to a closed position.
Tighten the security screw on the latch, if needed.

Remove the hot-plug fan

Procedure
1. Observe the following alert:
IMPORTANT: After removing a high-performance (dual-rotor) fan, install or replace the fan within 60
seconds. Otherwise, the server will shut down gracefully.
2. Do one of the following:
Extend the server from the rack.
•
Remove the server from the rack.
•
3. Remove the access panel.
