  • Page 1 AMC2 4W APC-AMC2-4W | APC-AMC2-4WCF | APC-AMC2-4WUS Installation manual...
  • Page 3 Bosch Security Systems retains all rights not expressly granted. Nothing in this license constitutes a waiver of Bosch’s rights under the U.S. Copyright laws or any other federal or state law. If you have any questions concerning this license, please, write Bosch Access Systems GmbH Adenauerstr.

  • Page 4: Table Of Contents

    Internet7 We Are Interested in Your Opinion8 Safety Instructions9 Important Safety Notes9 FCC & ICES Information12 Safety Precautions13 Unpacking14 Introduction15 Description of the AMC2 4W 15 Equipment Configuration17 Performance Characteristics20 System Overview21 Technical Data22 Installing26 Mounting26 Demounting27 Opening the AMC2 4W Case28...
  • Page 5 AMC2 4W | Installation manual Table of Contents | en 5 Legend58 Index59 Bosch Sicherheitssysteme GmbH F.01U.024.965 | V 0.1 | 2006.03...
  • Page 6 6 en | Table of Contents AMC2 4W | Installation manual F.01U.024.965 | V 0.1 | 2006.03 Bosch Sicherheitssysteme GmbH...

  • Page 7: Please Read Carefully7

    AMC2 4W | Installation manual Please read carefully | en 7 Please read carefully Explanation of Used Symbols Throughout this document, helpful tips, important notes, cau- tions and warnings will be presented for the reader to keep in mind. These appear different from the rest of the text as fol-...

  • Page 8: We Are Interested In Your Opinion8

    8 en | Please read carefully AMC2 4W | Installation manual We Are Interested in Your Opinion We constantly try to improve the quality of our products and our manuals. Should you have any suggestions for improve- ment, please, send us your comments.

  • Page 9: Safety Instructions9

    AMC2 4W | Installation manual Safety Instructions | en 9 Safety Instructions Important Safety Notes Read, Follow, and Retain Instructions - All safety and operating instructions must be read and followed properly before putting the unit into operation. Retain instructions for future reference.
  • Page 10 10 en | Safety Instructions AMC2 4W | Installation manual specified in the operating instructions. Improper adjustment of other controls may result in damage, and require extensive work by a qualified technician to restore the unit to normal operation. •...
  • Page 11 AMC2 4W | Installation manual Safety Instructions | en 11 ANSI/ NFPA No.70, provides information regarding proper grounding of the mount and supporting structure, ground- ing of the coax to a discharge unit, size of grounding con- ductors, location of discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

  • Page 12: Fcc & Ices Information12

    12 en | Safety Instructions AMC2 4W | Installation manual FCC & ICES Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 13: Safety Precautions13

    Health and Safety Installation of the AMC2 4W must comply with any local fire, health and safety regulations. A secured door that may be part of an escape route from an area must be installed with: •...

  • Page 14: Unpacking14

    14 en | Safety Instructions AMC2 4W | Installation manual CAUTION! You must ground the AMC2 4W. Disconnect both AC and bat- tery power supply before working on the controller. Warning! Risk of damage! Protect the hardware from electrostatic discharge by observing ESD instructions before unpacking or touching connectors or electronics.

  • Page 15: Introduction15

    The LC Display provides all important status informa- tion. Using the AMC2 4W gives you the full functionality and the offline capability of a complete access control system on each room. This leads to an excellent reliability and a very high redundancy without paying extra money.
  • Page 16 16 en | Introduction AMC2 4W | Installation manual Fig. 3.2 The AMC2 4W in a four door safety lock The AMC2 4W can communicate upstream to the host computer via eight RS-485 multi-dropped, RS-232 or 10/100 Mbit/s Ether- net. It has eight analog input devices and eight relay outputs.

  • Page 17: Equipment Configuration17

    AMC2 4W | Installation manual Introduction | en 17 Equipment Configuration Fig. 3.3 Upper circuit board with display (top side) Internal tamper contact DIP switch for RS-485 address selection, protocol and RS- 232/RS-485 selection Lithium battery for buffering of static RAM and real time clock (RTC).
  • Page 18 18 en | Introduction AMC2 4W | Installation manual 11. Configurable RS-232 host interface (ribbon cable connec- tor) 12. Configurable 10/100 Mbit/s Ethernet interface Fig. 3.4 Overview - Interfaces 13. RS-485 extension module bus (Pluggable screw connector) 14. External tamper contact (Pluggable screw connector) 15.
  • Page 19 Introduction | en 19 Fig. 3.5 Jumper at the bottom side 19. Jumper: Selector for either potential free relay output or powered by AMC2 4W internal power supply (wet/dry con- tacts) 20. Jumper: Potential equalization between different mass systems and protective earth (shield) Bosch Sicherheitssysteme GmbH F.01U.024.965 | V 0.1 | 2006.03...

  • Page 20: Performance Characteristics20

    Self controlling transfer-receive-switching • Power supply for internal electronics: 10V - 30VDC - max. • The AMC2 4W is to be used with power supply AMC PBC- 60 (F.01U.026.573) with integrated UPS F.01U.024.965 | V 0.1 | 2006.03 Bosch Sicherheitssysteme GmbH...

  • Page 21: System Overview21

    RS-485 or RS-232 is also pos- sible. Fig. 3.6 System overview In RS-485 mode up to eight access controllers AMC2 4W can be combined on one party line. Via Wiegand interfaces up to four peripheral devices can be connected to each AMC2 4W.

  • Page 22: Technical Data22

    22 en | Technical Data AMC2 4W | Installation manual Technical Data Hardware – Integrated Microcontroller (32Bit, 30MHz) – SRAM (2MB) – Serial EEPROM – – Pluggable Compact Flash from 64 MB up to 1024 MB – Battery for SRAM and real time clock (RTC) –...
  • Page 23 AMC2 4W | Installation manual Technical Data | en 23 Power con- Internal: 5 VA sumption Peripheral devices: using the AMC PBC-60 • up to 55 VA at 12V DC • constant load: 25 VA • peak load: 30 VA...
  • Page 24 24 en | Technical Data AMC2 4W | Installation manual Conductor For short distances below 25m (75 feet) data for con- use AWG18 conductors. For higher dis- nection to tances install an additional power supply power supply close to the AMC2 4W.
  • Page 25 AMC2 4W | Installation manual Technical Data | en 25 Conductor Use AWG22 conductors. data RS-485 Please, calculate your voltage drop (see slave above) by checking conductor specifica- tions for characteristic resistance values. CAUTION! The voltage drop at the different cables add up! Their sum shall...

  • Page 26: Installing26

    AMC2 4W | Installation manual Installing Mounting The AMC2 4W can be attached on a standard 35 mm mounting rail via a snap-in mechanism. Attach the AMC-4W into the upper edge of the mounting rail, then push down the AMC2 4W and snap it onto the rail by pushing it towards the back.

  • Page 27: Demounting27

    To remove the AMC2 4W from a mounting rail, first, remove all pluggable screw connectors. Push down the AMC2 4W until it snaps out of the mounting rail. Pull the lower end of the AMC2 4W from the mounting rail.

  • Page 28: Opening The Amc2 4W Case28

    To open the AMC2 4W, first, remove all pluggable screw con- nectors at least the host connection. The AMC2 4W case consists of a top cover mounted with a two- point snap-in closure on a ground chassis. To open the AMC2 4W push down the two snap-ins with a srew driver.
  • Page 29 It is recommended that the unconnected end of the shield be insulated to prevent accidental connection. The AMC2 4W enables you to set up a central ground or shield- ing point, simply by setting a couple of jumpers. Set these jumpers only if ground or shield is not connected otherwise.
  • Page 30 Setting jumper JP2 connects the internal ground of the AMC2 4W to the shield of the RS-485 host interface. Set Jumper JP2 only at the first AMC2 4W of a party line. The host system must not connect cable shield and protective ground. If the AMC2 4W is set to RS-232 mode, Jumper JP2 must be set.

  • Page 31: Connecting Power Supply31

    AMC2 4W | Installation manual Installing | en 31 Connecting Power Supply Connect the power supply to the 7-pin pluggable screw connec- tor labeled with POWER on the upper case. NOTE! A complete connection diagram is shown in chapter Section 7.1 Connecting Diagrams of this documentation.
  • Page 32 32 en | Installing AMC2 4W | Installation manual WARNING! Risk of Damage! Power supply for external devices is 12V DC only! Applying higher voltages may cause hazards to people and damage to the equipment. When using a shared 12 VDC power supply for internal electron- ics and peripherals, pin 1 and pin 6 resp.

  • Page 33: Rs-485 Host Interface33

    AMC2 4W | Installation manual Installing | en 33 RS-485 Host Interface An RS-485 host system can consist of up to eight AMC2 4W con- trollers connected via 2- or 4-wire connection. Fig. 5.7 Configuration of a RS-485 host system Bosch Sicherheitssysteme GmbH F.01U.024.965 | V 0.1 | 2006.03...
  • Page 34 For longer bus lines connect the AMC2 4W to multiple AMC-MUX (-EXT) with the host. To use RS-485 mode at the AMC2 4W, connect the data cables to the pluggable screw connector of the RS-485 host interface. Then set the RS-485 address via DIP switch or software and activate the RS-485 two-wire or four-wire mode via jumper set- tings.

  • Page 35: Rs-485 Two Wire Connection35

    AMC2 4W | Installation manual Installing | en 35 Fig. 5.8 RS-485 host interface 5.6.1 RS-485 Two Wire Connection Fig. 5.9 Connection scheme of a RS-485 two wire connection Fig. 5.10 Settings for RS-485 two wire connections NOTE! A complete connection diagram of the RS-485 host interface is shown in chapter Section 7.1 Connecting Diagrams of this docu-...

  • Page 36: Rs-485 Four Wire Connection36

    36 en | Installing AMC2 4W | Installation manual 5.6.2 RS-485 Four Wire Connection Fig. 5.11 Connection scheme of an RS-485 four wire connection Fig. 5.12 Settings for RS-485 four wire connection NOTE! A complete connection diagram of the RS-485 host interface is shown in chapter Section 7.1 Connecting Diagrams of this docu-...

  • Page 37: Dil Switch Address Selector37

    DIL Switch Address Selector The first four DIL switches for address selection define the RS- 485 address of the AMC2 4W in a RS-485 bus system. Switch 5 selects on of the two different protocols, SDEB and BPA (according to DIN6619). Switch 6 sets the connection to the host system to either RS-232 or RS-485.
  • Page 38 38 en | Installing AMC2 4W | Installation manual DIP Switches Address none Table 5.1 Setting the RS-485 address with the DIP swich DIP Switches Mode SDEB RS-232 RS-485 Table 5.2 Protocol and connection settings F.01U.024.965 | V 0.1 | 2006.03...

  • Page 39: Rs-232 Host Interface39

    AMC2 4W | Installation manual Installing | en 39 RS-232 Host Interface The AMC2 4W offers an RS-232 serial interface to connect a host computer or serial modem. CAUTION! Cable length between two RS-232 COM serial interfaces must not exceed 15 meters (45 ft).
  • Page 40 40 en | Installing AMC2 4W | Installation manual Fig. 5.15 Connection scheme of the RS-232 interface NOTE! A complete connection diagram of the RS-232 host interface is shown in chapter Section 7.1 Connecting Diagrams of this docu- mentation. F.01U.024.965 | V 0.1 | 2006.03...

  • Page 41: Ethernet Interface41

    Use either a CAT5 crossover cable to connect the AMC2 4W directly to a computer’s network interface or a standard CAT5 patch cable to connect the AMC2 4W to a network hub or net- work switch. Fig. 5.16 Location of the Ethernet interface...

  • Page 42: Rs-485 Extension Module Bus42

    42 en | Installing AMC2 4W | Installation manual RS-485 Extension Module Bus The RS-485 Extension Module Bus expands the AMC2 4W with additional I/O modules (AMC 8I-8O or AMC 16I-16O). Up to three expansion modules can be connected to provide addi- tional in- and outputs, for example, for elevator control.

  • Page 43: Wiegand Interface For Card Readers43

    Installing | en 43 5.10 Wiegand Interface for Card Readers The AMC2 4W has four Wiegand interfaces to integrate up to four card readers with Wiegand compatible interfaces. Each interface is connected via a 10-pin pluggable screw connector (S2, S7, S14 and S19).

  • Page 44: Connecting Relay Outputs44

    AMC2 4W | Installation manual 5.11 Connecting Relay Outputs To operate locks or alarm systems the AMC2 4W has eight form C relay outputs. The outputs will be connected to the 3-pin pluggable screw connectors: S5, S6, S10, S11, S17, S18, S22, and S23.
  • Page 45 AMC2 4W | Installation manual Installing | en 45 Fig. 5.20 Wet mode and dry mode of the AMC2 4W relay outputs Maximum switching power of each relay output is 60 VA, maxi- mum switching voltage 30 V DC and maximum switching cur- rent 2 A.
  • Page 46 46 en | Installing AMC2 4W | Installation manual Each relay output has a separate jumper setting on the bottom side of the lower circuit board to activate wet (D2)or dry (D1) mode. Fig. 5.21 Location of relay output jumpers (bottom side) F.01U.024.965 | V 0.1 | 2006.03...

  • Page 47: Connecting Analog Input Devices47

    Installing | en 47 5.12 Connecting Analog Input Devices The AMC2 4W has eight analog inputs, for example, for poten- tial free lock mechanisms or to detect if a lock is closed or open. The inputs will be connected to the 2-pin pluggable screw connectors: S3, S4, S8, S9, S15, S16, S20, and S21.
  • Page 48 48 en | Installing AMC2 4W | Installation manual 1. Door open:R 2. Door closed:R 3. Broken wire:R 4. Short circuit:R The resistor values can vary and depend on the used lock system (wire resistance negligible). Default values are: = 2,2 k = 4,7 k Fig.

  • Page 49: Tamper Protection49

    Installing | en 49 5.13 Tamper Protection To protect the AMC2 4W against unauthorized access and pre- vent the AMC2 4W from tampering with sensitive data, the AMC2 4W offers an additional interface to connect external tamper contacts. This interface is a potential-free 2-pin plugga- ble screw connector marked with T.

  • Page 50: Operating50

    AMC2 4W | Installation manual Operating Status Display of the AMC2 4W The LC Display delivers information about the AMC2 4W status. Push the 'Dialog' button to switch between different modes. Fig. 6.1 Location of the ’Dialog’ button The display mode which has been set remains until the next operation of the ‘Dialog’...
  • Page 51 AMC2 4W | Installation manual Operating | en 51 Push Display (Example) Description V37.02 02.03.06 Software versions and date of the downloader (= default page) 99999876543210 A BOSCH serial number and bus address A = address 1 H = address 8 02.06 15:35:15...

  • Page 52: Configuring The Ethernet Interface52

    Insert the provided screwdriver into the hole as shown in the figure below. Push the reset button for at least three seconds. The AMC2 4W will be reset and reboots. You are back in the download program. Now it is possible to reconfigure the AMC2 4W from the beginning.
  • Page 53 AMC2 4W | Installation manual Operating | en 53 Fig. 6.2 Restarting the AMC2 4W with the provided screw driver Fig. 6.3 Resetting the AMC2 4W to delivery state Bosch Sicherheitssysteme GmbH F.01U.024.965 | V 0.1 | 2006.03...
  • Page 54 54 en | Appendix AMC2 4W | Installation manual Appendix Connecting Diagrams Fig. 7.1 Connectors on upper PCB Fig. 7.2 RS-485 host on upper PCB F.01U.024.965 | V 0.1 | 2006.03 Bosch Sicherheitssysteme GmbH...
  • Page 55 AMC2 4W | Installation manual Appendix | en 55 Fig. 7.3 Connecting diagram of the RS-232 serial interface Fig. 7.4 Ethernet Network socket (RJ45) Bosch Sicherheitssysteme GmbH F.01U.024.965 | V 0.1 | 2006.03...
  • Page 56 56 en | Appendix AMC2 4W | Installation manual Fig. 7.5 Connector blocks of the AMC2 4W F.01U.024.965 | V 0.1 | 2006.03 Bosch Sicherheitssysteme GmbH...
  • Page 57 AMC2 4W | Installation manual Appendix | en 57 Fig. 7.6 Power supply Fig. 7.7 Wiegand interface Fig. 7.8 Analog input Fig. 7.9 Relay output Bosch Sicherheitssysteme GmbH F.01U.024.965 | V 0.1 | 2006.03...
  • Page 58 58 en | Appendix AMC2 4W | Installation manual Fig. 7.10 Slave interface Fig. 7.11 External tamper contact Legend Twisted pair connection Transmitter Receiver F.01U.024.965 | V 0.1 | 2006.03 Bosch Sicherheitssysteme GmbH...
  • Page 59 AMC2 4W | Installation manual Index | en 59 Index Address Selector 37 Appendix 54 Analog Input Devices 47 Cabling 28 face 52 Conductor data 24 Connecting Diagrams 54 Configuring the Ethernet Inter- Connectors 23 Demounting the AMC-4 27 Dimensions 23...
  • Page 60 60 en | Index AMC2 4W | Installation manual Used Symbols 7 Wiegand Interface 43 F.01U.024.965 | V 0.1 | 2006.03 Bosch Sicherheitssysteme GmbH...
  • Page 61 AMC2 4W | Installation manual Index | en 61 Bosch Sicherheitssysteme GmbH F.01U.024.965 | V 0.1 | 2006.03...
  • Page 62 Bosch Sicherheitssysteme GmbH Robert-Koch-Straße 100 D-85521 Ottobrunn Germany Telefon (089) 6290-0 (089) 6290-1020 www.bosch-securitysystems.com © Bosch Sicherheitssysteme GmbH, 2006...
