Page 1 Installation and Operation Manual APEX1000 All-Purpose Edge Software Version 2.4.x...
Page 2 © 2010 Motorola, Inc. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from Motorola, Inc.
Page 3 This product contains a Class I laser and is intended for operation in a closed environment with fiber attached. CAUTION — Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 4 Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 5 Any changes or modifications not expressly approved by Motorola could void the user’s authority to operate this equipment under the rules and regulations of the FCC.
Page 6 Directive(s) of the Council of the European Union: EMC Directive 2004/108/EC Low Voltage Directive (LVD) 2006/95/EC Restriction of Hazardous Substances Waste Electrical and Electronic Equipment Directive 2002/95/EC (WEEE) Directive 2002/96/EC APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 7 Caused by Electronic Information Products”. The Toxic and Hazardous Substance disclosure table and EFUP Logo cover all electronic information products (EIP) supplied by the Home and Networks Mobility business of Motorola, Inc. APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 8 Caring for the Environment by Recycling When you see this symbol on a Motorola product, do not dispose of the product with residential or commercial waste. Recycling your Motorola Equipment Please do not dispose of this product with your residential or commercial waste.
Page 9: Table Of Contents
Installing or Removing GigE SFP Transceivers................33 Installing Transceivers......................33 Removing Transceivers......................33 SFP Transceiver Status ......................33 Connecting the Interface Cables..................... 35 APEX1000 Power Connections ..................... 36 Connecting to AC Power......................36 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 10 Downloading Configuration Files .................... 55 Configuration ..........................57 Initial Settings ..........................57 System Configuration......................57 Chassis Redundancy Configuration ..................58 DTA Configuration........................58 RADIUS Configuration......................58 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual viii 573408-001-a...
Page 11 RADIUS Configuration......................92 Motorola RADIUS Dictionary File.................... 94 EAS Configuration.......................... 95 PSIP Configuration......................... 97 QAM Configuration........................99 QAM RF Port Configuration ....................101 QAM Module Upgrade ........................ 104 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 12 Data Stream Identification..................... 153 Quick Enable/Disable........................155 SDV — Switched Digital Video Controls ................156 Session Controlled Mode ......................156 RPC Session Control ........................158 RPC Session Control Pop-up....................159 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 13 ECMG Statistics Details Window ..................207 EIS Statistics..........................209 SCG Details Window......................211 DEPI – MPT Mode ........................212 Overview ............................. 212 DEPI Modes .......................... 212 DEPI Control Connections..................... 213 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 14 Output PSIP .......................... 275 PSIP Status ........................... 276 Save APEX1000 Status ......................277 Troubleshooting ........................278 Contacting the TAC ........................278 APEX1000 LED Color Scheme ....................278 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 15 RFPM and Power Supply Modules....................302 Identifying an RFPM or Filler Module ................... 303 Removing an RFPM or Filler Module ..................303 Installing an RFPM or Filler Module ..................303 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual xiii 573408-001-a...
Page 16 Figure 6-10 — EAS Configuration....................95 Figure 6-11 — PSIP Configuration ....................97 Figure 6-12 — QAM Configuration ....................99 Figure 6-13 — QAM RF Port Configuration................. 102 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 17 Figure 10-13 — EIS Statistics ...................... 209 Figure 11-1 — DEPI Control Connections window ..............213 Figure 11-2 — DEPI Session Mapping window ................215 Figure 12-1 — APEX Alarms......................218 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 18 Figure 12-30 — Output PSI Table status window ............... 273 Figure 12-31 — Output PSIP window ..................275 Figure 12-32 — PSIP Status ......................276 Figure 12-33 — Save APEX1000 Status..................277 APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 19: Introduction
SimulCrypt encryption, and low power in an extremely cost-effective 1 RU platform. The unique attributes of the APEX1000 allow for the installation of up to three removable and hot-swappable QAM modules in the chassis. The APEX1000 also presents the following features: •...
Page 20: Related Documentation
• REM1000 User Guide Note: The SDM is the required device to perform any upgrades with the APEX. Document Conventions Before you begin using the APEX1000, familiarize yourself with the stylistic conventions used in this manual: Convention Description Bold type tier_match(1,524) Indicates text that you must type exactly as it appears or indicates a default value.
Page 21: Getting Help
Getting Help To get assistance with your Motorola product or solution, or to access learning materials, use one of the following channels: Technical Assistance Center (TAC) provides access to technicians 24 hours a day, 7 days a week for all products. Contact the TAC at 888-944-HELP (888-944-4357) or dial direct 847-725-4011.
Page 22: Calling For Repairs
ALL OTHER COUNTRIES +1 847 725 4011 Note: If you find a toll-free number that is not valid, please dial +1 847 725 4011. Introduction • Getting Help APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 23: Overview
The APEX1000 offers a feature set that is based on the existing SEM V8/V12 products. To allow for full use of all 48 QAM output streams, however, the APEX1000 allows each output to be configured separately. In addition, you can apply many configuration settings without rebooting the system (changes to the QAM Transmission Mode require a reboot before taking effect).
Page 24: Physical Overview
Does NOT require a one rack unit blank panel cooling space; cooling air is drawn in the front panel and exits out the rear fan Figure 2-1 — APEX1000 dimensions Overview • Physical Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 25: Apex1000 Front Panel
For easy access, a Console Port and an ASI Monitor Port are also located on the APEX1000’s front panel. To allow user access to a set of limited menus, such as boot mode selection and OAM&P Fast Ethernet IP address/mask entry, the Console Port provides a serial interface.
Page 26 Top row connector pins are: 5, 4, 3, 2, 1 • Bottom row connector pins are: 9, 8, 7, 6 RS-232 Test Console Port for further information on menu item selections. Overview • Physical Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 27 100 msec after detection of collision (during high collisions, this LED also appears as alternating green-yellow) ASI Monitor Port – This port is available for monitoring a selected output stream. Overview • Physical Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 28: Apex1000 Rear Panel
APEX1000 Rear Panel The rear panel of the APEX1000 provides access to up to three replaceable QAM modules with two RF connectors each. The replaceable power supply modules and ground stud are also located on the back of the unit.
Page 29 Fan Field Replacement Procedure additional details on replacing a fan assembly. *The APEX1000 is available with an optional redundant power supply that is of the same type (such as AC and AC or DC and DC). CAUTION For proper function of the internal RF Power Level detector, all RF Outputs must be terminated with 75 Ohms.
Page 30 AC PS module, one DC PS module, two AC PS modules, or two DC PS modules. (The APEX1000 does not support the inclusion of both one AC and one DC PS module at the same time.) •...
Page 31: 8Qrm/Rf Redundancy
8QRM/RF Redundancy Each APEX1000 unit contains up to three RFPM QAM modules, and each RFPM QAM module consists of two Octal QAM modules (8QRM) sub modules. There are, as a result, six 8QRM sub modules in a fully loaded APEX chassis. The APEX1000 includes support for 8QRM/RF port narrowcast redundancy, provided by the REM1000.
Page 32: 1:1 Chassis Redundancy
L2TPv3 support will be offered in a future APEX1000 release.) CAUTION The APEX1000 does not allow you to change the operating mode or PID remapping mode of QAM output that has any active service or stream mappings. To perform these modifications, you must first delete all service and stream mappings to that output.
Page 33: Switched Digital Video
Note: Shown with Motorola components, as well as the Time Warner Conductor required to support the TWC guide/SDV client (MDN/ODN) running in the set-top. Overview • Operating Modes APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 34 RTSP does not split the creation of shell sessions and binding of sessions between two separate controllers (as is the case in RPC). Overview • Operating Modes APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 35: Session-Oriented Vod
APEX Network (GigE) (GigE) (QAM) (NE) (STB) (GigE) R4, D7 R6, D6 Encryption Edge Resource Resource Manager Manager Pump (EnRM) (ERM) Session Manager Overview • Operating Modes APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 36 The ERM1000 uses D6 to discover the Edge QAM (the APEX1000) and its capabilities. • R6 routes individual VOD sessions through the APEX1000, from an SPTS input at the GigE interface to a program in an MPTS QAM output. The other interfaces shown above relate to other functions and components in the RTSP/MHA network, from the STB client, to the VOD streaming server, to the encryptor.
Page 37 RPC architecture. Therefore, as shown in the preceding graphic, the Network Encryptor (NE) is positioned to perform the encryption. The APEX1000 then takes already encrypted SPTSs at its input and routes them to the appropriate output per the Edge Device Interface Specification (EDIS).
Page 38: Mc Encryption And Access Control
Encryption FPGAs. Each FPGA can support the encryption of 24 full rate MPTSs (48 MPTSs in total). Using this architecture, the APEX1000 is able to support the encryption of up to 768 services across all 48 QAM outputs.
Page 39 While in all cases the APEX1000 internally creates the ECMs, the access requirements (Rights Meta Data) for a given stream are determined by the APEX1000 by the DAC (through its RDS interface), by the session controller setting up a VOD session, or through configured defaults on the APEX1000.
Page 40: Broadcast Encryption
You must convert all ASI outputs from IRDs or encoders to GigE before sending them to the APEX1000. As shown in the preceding graphic, you can perform this conversion using a SEM v8. Additionally, the Motorola AGB240 (ASI to GigE Bridge) can also be used to convert ASI into GigE.
Page 41: Common Tier Encryption (Cte)
The APEX1000 can remux services, but does not support trans-rating • The APEX1000 will (or will not) encrypt each individual stream based on the data for that service received from the DAC using the RDS. The APEX1000 will also insert the appropriate copy protection data (CCI, APS, CIT) •...
Page 42 APEX1000 will only support this exact scheme. Additional Notes: 1. To apply a basic level of encryption (mostly for privacy) to each stream, the APEX1000 is typically configured for CTE (common tier encryption). 2. Incoming streams may already be encrypted (perhaps using the OLES for pre-encryption), in which case the APEX1000 muxes the stream as is, without disrupting the encryption or ECMs.
Page 43 In a typical switched digital headend, the encryption and modulation functions are separated. The APEX1000 can perform both of these functions. While operating in RTSP mode, the APEX1000 can encrypt switched content using Common Tier Encryption. In this mode, all switched QAMs in a service group will have the same configured RMD and encryption settings.
Page 44 SDV architecture. Therefore, as demonstrated in the preceding graphic, the Network Encryptor is positioned to perform the encryption. The APEX1000 receives already encrypted SPTSs at its input, and routes them to the appropriate output according to the RPC control. This encryption procedure may also be performed at the edge level through the APEX1000 using CTE.
Page 45: Maximizing Throughput In Sdv Operation
Maximizing Throughput in SDV Operation RTSP/MHA Paired Port Assignment Prior to APEX1000 2.0, the APEX1000 could report a single pair of GigE ports to the ERM. Users could then enable all 48 QAMs for SDV mode, allowing the ERM to map streams from any enabled GigE input port to any enabled QAM output port.
Page 46 ERM. RPC Mode When configuring the APEX1000 for RPC mode, you must provide the input-to-output mapping through the EM or SDM configuration screens. As is the case with RTSP mode, you should avoid assigning more than 24 QAMs to a single GigE input pair.
Page 47: Installation
Installation Step-by-Step Instructions The following topics cover the basic steps required to install the APEX1000: • Mounting the APEX1000 • Connecting the Interface Cables • Applying Power to the Unit • Confirming APEX1000 Power-on Sequencing To make the procedure as quick and easy as possible, take a few minutes to review the...
Page 48: Other Required Items
Mounting the APEX1000 Mount the APEX1000 in a standard 19-inch rack. It is not necessary to provide an open space above and below the unit for air flow. If the equipment operates continuously in a closed cabinet, use forced air circulation to ensure maximum equipment life and optimum performance.
Page 49: Rack Mounting
The correct equipment rack mounting instructions for the APEX1000 are provided below: • Elevated Operating Ambient — If the units are installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (Tmax) specified by the manufacturer.
Page 50: Figure 3-1 - Apex1000 Rack Mounting
3. Insert the APEX1000 into the rack by sliding the side support rails through the rear mounting brackets. 4. Secure the front of the APEX1000 to the front rack angles with the four #10 (32 x .50-inch) long screws and plastic washers.
Page 51: Installing Or Removing Gige Sfp Transceivers
SFP transceiver installation and removal instructions. Installing Transceivers 1. Remove the dust plug from the selected APEX1000 front panel GigE port. Save the dust plug, should it become necessary to recap the port when not in use. 2. As shown in...
Page 52: Figure 3-2 - Typical Sfp Transceiver Installation/Removal
Figure 3-2 — Typical SFP transceiver installation/removal Installation • Installing or Removing GigE SFP Transceivers APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 53: Connecting The Interface Cables
Connecting the Interface Cables The Ethernet interface cable from ENET1 to the headend LAN is the only standard cabling. All other interface cabling is contingent upon the APEX1000 configuration (as defined by the specific system implementation). Inserting or Removing Cables Common F and BNC tools facilitate the insertion or removal of connectors from the APEX1000.
Page 54: Apex1000 Power Connections
100 through 240 V AC, at 50 through 60 Hz. Connecting to DC Power Warning! The APEX1000 with DC power must be installed in a restricted access area. Typical –48 V DC system installation specifications...
Page 55: Confirming Apex1000 Power-On Sequencing
Disconnecting less than the maximum will not de-energize the system. To reduce the risk of injury, disconnect all power feeders when removing power to the system. Confirming APEX1000 Power-on Sequencing When power is applied, the STATUS LED indicates APEX1000 sequencing as follows: LED Color Condition...
Page 56: Power Supply External Status Indicators
PS LED Location DC Output Power OK Green Fault Indicator Amber Middle DC Input Power OK Green (input <-40VDC) Bottom Installation • Power Supply External Status Indicators APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 57: Apex1000 Verification
APEX1000 Verification The following procedure is a quick and simple method to determine if the APEX1000 is operating properly. CAUTION Verification requires the use of the APEX1000 EM. If you have not yet downloaded the EM Java applet, see Initiating an EM Session for additional information.
Page 58: Setup And Operation
JRE. Establishing Network Connections At power up, the operating configuration of the APEX1000 is determined by data stored internally in flash memory, or by data that is downloaded from a bootstrap protocol (BOOTP) server; the particular method used to set up initial operation depends on the system configuration.
Page 59: Verifying The Network Connection
Verifying the Network Connection Ping the APEX1000 OAM&P interface to confirm that the IP address was assigned. At bootup, the OAM&P interface (ENET1) should be connected to the local network. The APEX1000 always attempts to auto-negotiate at bootup, and sets the duplex and data rate (10 Mbps or 100 Mbps) according to the results of the auto-negotiation process.
Page 60: Operating System
APEX1000 under the following conditions: • Data is read from the APEX1000 using SNMP get and getnext functions, and sent to the APEX1000 using SNMP set functions. • When configuration data is set on the APEX1000 using the Element Manager, it is read back by the EM so that the EM window stays synchronized with the APEX1000 database.
Page 61 2. To download the APEX1000 EM application, click Download APEX Element Manager. The file download pop-up displays (A typical Firefox screen is shown): Setup and Operation • Initiating an EM Session APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 62: Downloading The Jre
If your browser has named the EM files *zip, you will need to change this to *jar for it to open properly after download. Otherwise, WinZip (or an equivalent application) will be invoked due to the *zip extension. 4. To launch the APEX1000 EM after the application downloads, double click the file icon. downloaded apexem.jar...
Page 63: Active Warnings
The Active Warnings feature allows the operator to take immediate action to correct the fault or deactivate the alarm, as current conditions dictate: • If the APEX1000 does not have an active alarm at the time of login, only the EM main window displays, as shown in the preceding graphic. •...
Page 64 Note: You can only disable alarms with checkboxes through the APEX Alarms window. Setup and Operation • Logging In APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 65: Apex1000 Em Toolset
APEX1000 EM Toolset The APEX1000 EM is the primary interface to the APEX1000 for set-up and operation. Based on a Java application, it is a remote user interface that enables you to monitor an APEX1000 (remotely or locally). To allow access to other windows, the software toolset has seven drop-down menus: •...
Page 66: Navigating The Element Manager
Some pages accessible through the Element Manager contain additional product support windows: To display page-sensitive help topics, click Help (if available for that page). Setup and Operation • APEX1000 EM Toolset APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 67: System Settings
Manage your user name and passwords • Download Configuration files • View Element Manager version and build date • Exit the APEX-EM application System Settings • Managing Users APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 68: Root User Privileges
• Download configuration files • View Element Manager version and build date • Exit the system Figure 5-1 — Administration window System Settings • Root User Privileges APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 69: Adding Or Removing User Profiles
Add New User — Opens the Add New User window. • Remove User — Deletes the selected user name from the APEX1000 EM. (This option only becomes available when a new user has been added. User root cannot be removed.) •...
Page 70: Removing A User Profile
2. Check the radio button next to the desired user name. 3. Click Remove User. 4. Click OK when prompted. The user profile is removed. System Settings • Root User Privileges APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 71: Other User Privileges
Exit the system Note: User Management is the only function restricted to the Administrator. Users other than root have normal access to all other APEX1000 functions in the Element Manager. System Settings • Other User Privileges APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual...
Page 72: Setting A Password
The following menu options are available to all users: • Rebooting the System • Downloading Configuration Files • Displaying the Current EM Version • Ending a Session System Settings • Common System Tasks APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 73: Rebooting The System
3. Type (or click Browse to select) the Destination for the configuration file(s). 4. Click Get Files. The file(s) are placed in the destination folder. System Settings • Common System Tasks APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 74 Although you can edit these files, it is not recommended that you do so. Loading a corrupted configuration file onto an APEX1000 unit forces you to reconfigure the unit through the EM, as most (or all) configuration settings will be lost. In the event that you decide to edit these files, then use WordPad instead of Notepad.
Page 75: Configuration
Configuration Initial Settings For the APEX1000 to become fully functional, you must first configure specific settings such as System Time, Transport Streams, GigE ports, Encryption, PSIP Configuration, QAM outputs, and other essential parameters covered in this section. To display the configuration items drop-down list, click Configuration on the APEX-EM...
Page 76: Chassis Redundancy Configuration
Enabling PSIP Processing • EAS Messages Received Status • Message Insertion Settings • DST Settings QAM Configuration • QAM Transmission Mode • QAM RF Parameters Configuration • Initial Settings APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 77: Qam Rf Redundancy
Enable or Disable GigE Interface Redundancy Encryption Configuration • Encryption Algorithm • RDS IP Address • RDS TCP Port • RDS Poll Randomization • CTE Poll Interval Configuration • Initial Settings APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 78: Output Ts Configuration
Common Tier Output TS Configuration • PID Remapping • Operating Modes • ASI Monitor Port Output • PAT TS ID • Encryption Type Configuration • Initial Settings APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 79: System Configuration
System Configuration System Time Use this window to define the system time source and view the current APEX1000 up time. You can select between SNTP and Internal as the time source. SNTP can be either from a specific SNTP server, or the APEX1000 can ‘listen’ for any SNTP server.
Page 80 UTC/NTP with the earth’s rotation (GPS time). The International Earth Rotation Service (IERS) is responsible for notifying the public when a leap second will be inserted. A UTC offset of 0 sets the APEX1000 to use UTC time. The current number of leap seconds is 15.
Page 81: Fast Ethernet
Current Local Time – Displays the read-only current time and date of the PC that is running the APEX1000 EM. (This field is only viewable if Time Source is set to Internal and the Use Local PC Time box is enabled.) These settings are useful when no external time source is available (such as an SNTP server), allowing the APEX1000 to use a current time reference for logs.
Page 82: Figure 6-2 - Fast Ethernet Configuration
Figure 6-2 — Fast Ethernet Configuration CAUTION As shown in Figure 6-2, ENET1 and ENET2 must be on separate networks. Configuration • System Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 83 *Boot Method The Boot Method determines how the APEX1000 performs the bootup process on the next reboot. When setting the APEX1000 to No BOOTP, this ensures that the APEX1000 does not download a new configuration file or a new code image.
Page 84: Traps
Applicable values are 1 – 10, representing the maximum number of traps the APEX1000 will issue in one second (to a specific trap receiver). Configuration • System Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 85: Advanced
Use the Advanced Configuration screen to control the insertion mode, auto reboot, and the loss of PSI detection parameters, as well as other functions: Figure 6-4 — Advanced Configuration Configuration • System Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 86 The default is Stream Rate. Detect Loss of Input Range: On/Off PSI Enabled Reference Detection of Lost Input Services below for more information. Configuration • System Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 87: Loss Of Input Psi Timeout
Loss of PSI is used to determine when a service that was previously received is no longer on the input stream. For a service to be remultiplexed by the APEX1000, the input PAT must reference the applicable service number. In addition, the input PMT must be received.
Page 88: Detect Loss Of Input Psi Configuration
PATs associated with an output MPTS. • If disabled, the APEX1000 will not react to missing PSI on the input. In this eventuality, the current behavior will be maintained, wherein the APEX1000 will maintain the output PMT and SN references within the PAT, even though the input PSI is missing.
Page 89: Unicast And Multicast Loss Of Input Stream Processing
Because UDP Port Mapping sets up static VOD routes, the input streams are not always expected to be present. Therefore, no alarming is performed when input streams are missing. Configuration • System Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 90: 1:1 Chassis Redundancy Overview
Note: This feature does not un-mute QAM channels that were explicitly muted by the operator using the EM (when transitioning to the active state). Configuration • 1:1 Chassis Redundancy Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 91: Figure 6-5 - Redundancy With Heartbeat
QAM channels to come online without colliding with primary QAM channels. Configuration • 1:1 Chassis Redundancy Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 92: Primary And Secondary Apex Roles
Additionally, you can also determine if the link loss of the following interfaces will result in the APEX entering a fault state: Configuration • 1:1 Chassis Redundancy Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 93: Interface Fault Detection
APEXs. Loss of power on one APEX in a direct connect mode causes the link to be down on both APEXs. See also Alarms Window Field Definitions. Configuration • 1:1 Chassis Redundancy Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 94: Chassis Redundancy Configuration
Routing operation mode. (Manual routing is the main driver for 1:1 chassis redundancy.) CAUTION Leave the routes disabled until chassis redundancy is enabled. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 95: Figure 6-6 - 1:1 Chassis Redundancy Configuration
Configure Redundancy Parameters 1. Click Configuration > Chassis Redundancy Configuration. The Chassis Redundancy Configuration window displays: Figure 6-6 — 1:1 Chassis Redundancy Configuration Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 96 9. Enable the routes that were previously configured. Note: To Enable or Disable program mappings as a group, click Program Mappings > Quick Enable/Disable. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 97 Note: The availability fault is Major because the redundant APEX is not connected, therefore redundancy is unavailable. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 98: Configuring The Secondary Apex
— Enable this option. QAM Faults: APEX enters a fault state if a module, port, or channel fails. 8. Click Apply. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 99 1. The Primary APEX should be in Active status, and should be sourcing content. 2. The Secondary APEX should be in Standby status, and should have its RF ports muted. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 100: Redundancy Configuration
APEX does not become active until the suspend switch over parameter is disabled.) Note: The configuration is not synchronized when the standby APEX is suspended. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 101: Configuring Redundancy Triggers
2. Click Apply to implement the changes in the APEX1000. For more information on specific alarm triggers, see Alarms Window Field Definitions. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 102: Configuring Redundancy Failover
Note: This button is grayed out when chassis redundancy is disabled. Redundancy Availability The APEX1000 reports the status of the 1:1 redundancy system, whether or not redundancy is available. Note that the APEX can only failover when redundancy is available; additionally, the heartbeat interface link must be detected for the system to be available.
Page 103 Force Failover on the other APEX in the pair. Note: Make certain that the APEX from which a QAM Module is to be removed is the Standby APEX. Configuration • Chassis Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 104: Dta Support Overview
DTA video services are configured as manual routes, with a configured multicast joined to retrieve in-band messages for insertion. Note: The current APEX1000 firmware release does NOT include support for DTA content protection. This feature will be included in a future release.
Page 105: Dta Configuration (General)
CAT/EMMs for DTA are generated on the DAC (DAC 3.11-18), or the CASMR (DAC 4.0 and higher). Settings in this window must match those found in the DAC for DTA to function on the APEX. Configuration • DTA Support Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 106 3.3.1) before configuring the DTA on the APEX1000. • Customers using DAC 4.0 and later will require a CASMR system to generate DTA tables. Configuration • DTA Support Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 107: Dta Configuration (Rf Port)
0.0.0.0 indicates Unicast stream. Source IP IPv4 address of multicast source. Range: Multicast IPv4 The default is 0.0.0.0 0.0.0.0 indicates that SSM is not used. Configuration • DTA Support Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 108: Radius Authentication
Note: The current APEX firmware only supports Authentication, Authorization and Integration with a SecurID server. RADIUS Accounting will be supported in a future release of the APEX1000. Configuration • RADIUS Authentication APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 109: Redundancy Overview
(if so configured). Local authentication is the same as the current log in, with root and other users. Configuration • RADIUS Authentication APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 110: Radius Configuration
To begin setting up authentication parameters, click Configuration > RADIUS Configuration: Figure 6-9 — RADIUS Configuration Configuration • RADIUS Authentication APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 111 NAS IP Interface Selects which interface IP address is included in the NAS IP attribute in RADIUS messages. Range: ENET1/ENET2 The default is ENET1. Configuration • RADIUS Authentication APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 112: Motorola Radius Dictionary File
If both AVPs are present, the level configured for the APEX specific attribute takes precedence. Note: The Motorola dictionary file is bundled with all firmware releases that support RADIUS. For information on downloading the file at a later time, see...
Page 113: Eas Configuration
The EAS PID (0x1FFB) is not inserted if the output has been configured for pass-through mode, or if a user ancillary-mapped another PID to PID 0x1FFB. Configuration • EAS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 114 Indicates the total number of EAS messages received since bootup. Invalid EAS Messages Indicates the total number of invalid EAS messages received since bootup. Configuration • EAS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 115: Psip Configuration
APEX1000 version 2.4.x adds support to pass and fix the PSIP information provided by any content provider from an input multiplex through the cable network for receipt by hosts / digital TV receivers.
Page 116 3000 ms EIT-2 10000 ms EIT-3 10000 ms DST Settings Use this area for defining the DST values for In/Out Month, Day, and Hour. Configuration • PSIP Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 117: Qam Configuration
The current firmware version supports QAM Transmission Modes of Annex A, B, and C. Any changes to the QAM Transmission mode require a reboot. Configuration • QAM Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 118 The Output Transport Stream numbers (1 – 16, 17 – 32, 33 – 48) and Output QAM channel. Each field is colored to indicate the current QAM Channel alarm status. See APEX1000 LED Color Scheme for more information. Configuration • QAM Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 119: Qam Rf Port Configuration
Use the QAM RF Port Configuration window to configure EIA Channel, Center Frequency, and Interleaver. To access RF Port Configuration, click the associated QAM RF # Config button: Configuration • QAM Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 120: Figure 6-13 - Qam Rf Port Configuration
Use to select between the following tuning modes: • Frequency • Channel Note: Channel tuning mode is only selectable when QAM Transmission Mode is Annex B – ATSC DCII. Configuration • QAM Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 121 DVB or Annex C – Asia-Pacific. Information Rate (bps) The read-only information rate displays according to the selected symbol rate and Modulation mode, and cannot be changed directly. Configuration • QAM Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 122: Qam Module Upgrade
QAM Module Upgrade You can upgrade a QAM Module while it continues to operate normally. To field-upgrade the APEX1000’s 2x4 QAM Modules to become a 2x8 QAM Module unit, use an upgrade string/code entered through the SDM or the APEX-EM user interfaces.
Page 123: Ordering Information
Ordering Information When ordered by itself, the APEX1000 chassis includes two RFPM fan filler modules and one power supply fan filler module. Because unit operation requires at least one RFPM module and one power supply module, it is not necessary to provide three RFPM fan filler modules or two power supply fan filler modules.
Page 124: Figure 6-14 - Qam Module Upgrade
3. After following the link in the email to the Motorola website, you must supply the serial number of each QAM module to be upgraded. A conversion key will then be generated for each provided serial number and displayed on the website.
Page 125: Qam Rf Redundancy Configuration
Notes: • With RF redundancy enabled on the APEX1000, RF port 6 is configured as a redundant port, backing up RF ports 1 to 5. If a failure of an RF ports occurs, the APEX1000 re-routes the output transport streams to RF port 6.
Page 126: Rf Redundancy Configuration
None – No REM1000 is used. • Direct – The APEX ENET2 port connects directly to the REM1000 APEX1 or APEX2 port (this is the default setting on the APEX1000, and the recommended communication mode). • Common – The APEX communicates over the OAM&P network, using its ENET1 interface to communicate with the REM1000 ENET interface.
Page 127: Destination Ip Address
APEX with a set of RF inputs. You must configure the device ID of the APEX1000 according to the set of RF inputs to which it is connected on the REM1000, and make certain that the APEX ID corresponds to the set of connected inputs on the REM1000.
Page 128: Failover Sequence
Failover Sequence In the event of port failure on an APEX1000 connected to a REM1000, the following sequence of events takes place: 1. The APEX1000 detects a failed QAM channel, RF Port, or QAM Module, and issues a standard SNMP trap alarm.
Page 129: Figure 6-16 - Qam Rf Redundancy
Figure 6-16 — QAM RF Redundancy Configuration • QAM RF Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 130 Connected – Received ack message from the REM for current switch port message. • Connection Lost – The REM has not replied to the last three switch port messages. Configuration • QAM RF Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 131 UDP port 6060 before enabling common mode. REM1000 Identifies the set of RF inputs on the REM1000 associated with this APEX. APEX ID Configuration • QAM RF Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 132 Note: An error on the backup port or on the REM1000 overrides this setting. The APEX does not allow force to backup mode. Configuration • QAM RF Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 133 Indicates which port (1 – 5) has failed over to the backup port: Failure Range: None (0), 1, 2, 3, 4, 5 A zero indicates that the backup port is not active. Configuration • QAM RF Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 134 RF Port is in a QAM 2x4 Module. (This would occur if the failed 2x8 primary is replaced with a 2x4.) QAM Status Opens the QAM Status window. Button Configuration • QAM RF Redundancy Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 135: Gige Configuration
The Gigabit Ethernet Configuration window enables the functionality and provides the network particulars of GigE 1 through GigE 4. Figure 6-17 — GigE Configuration Note: The APEX1000 does not transmit outgoing MPEG transport streams over its GigE interfaces. Configuration • GigE Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x •...
Page 136 Indicates whether Auto Negotiation is Enabled or Disabled. Auto Negotiation Negotiation is always enabled within the network stack. (The GigE interfaces can only function at 1000/Full.) Configuration • GigE Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 137 GigE interface, or the user has initiated a force failover from the primary GigE interface. Help Button Available in selected windows. Click to view corresponding help topics. Configuration • GigE Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 138: Configuring Gige Ports
The loss of link is checked by the APEX every five seconds CAUTION GigE Interface Redundancy cannot be enabled when Chassis Redundancy or Transport Stream redundancy is enabled. Configuration • GigE Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 139: Encryption Configuration
DVB-CSA • DVB-CSA SimulCrypt To begin configuring settings, select Configuration > Encryption Configuration. The Encryption Configuration window displays in the default Algorithm tab: Configuration • Encryption Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 140 Rights Data Server (RDS) Settings Use this interface when performing broadcast encryption. With this process, the APEX1000 retrieves EMMs and service specific rights meta data directly from the DAC 6000’s RDS interface. 1. To begin configuring RDS settings, select Configuration > Encryption Configuration.
Page 141 Use only when moving an APEX from one DAC (RDS) system to another system. Caution: This procedure causes a loss of all output streams and configured routes! * Editable text field. Configuration • Encryption Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 142 Note: To use Full Encryption mode in CTE, you must configure the RDS tab with the IP address and port of the EMM server (DAC 6000 RDS interface). Configuration • Encryption Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 143 The default value is Disabled. Note: If the APS level is Not Defined, the CIT Setting has no effect. Status Opens the RDS Status window. Configuration • Encryption Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 144 MediaCipher (MC) Insertion Mode Settings ® Instead of using a specific frequency, the APEX1000 can be utilized in a MediaCipher Full-In-Band deployment, where EMM entitlement messages are sent in the same frequency as downstream services. To allow set-top boxes to identify these streams, a specific descriptor must be inserted in the CAT referring to the PID values (allocated by the operator to these entitlement messages).
Page 145: Output Ts Configuration
QAM channels. Note: You can delete existing service routes on uninstalled or disabled QAM channels, but the APEX1000 does not allow you to make any changes to these service routings until the output QAM is installed and enabled.
Page 146: Mapping Activation
Active state here could be brought about by removing an RF module or disabling the QAM channel. Mapping Activation The APEX1000 allows manual routing and UDP port mapping routings to be made to any output QAM that is installed and enabled (entitled). •...
Page 147: Figure 6-18 - Output Ts Configuration
Figure 6-18 — Output TS Configuration Configuration • Output TS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 148 The drop-down list offers a shortcut to the following Manual Routing tasks: • Program Mapping • Stream Pass Thru • Ancillary PID Mapping • UDP Port Mapping • DEPI Session Mapping Configuration • Output TS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 149: Configuring Qam Ports
Output TS Configuration window: CAUTION Configuring QAM Ports is a bulk operation that affects all of the Output Transport Streams in that particular group. Configuration • Configuring QAM Ports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 150: Setting The Operating Mode
1. Undefined 2. Session Control: RPC — The APEX1000 acts as an edge device that receives and processes commands from two external sources using the RPC protocol. RTSP Session Mode — The APEX1000 acts as an edge device that receives and processes commands and PID remapping using the RTSP protocol.
Page 151 PMT, ECM, and elementary PIDs. The APEX1000 uses a PID re-mapping scheme in which you can select from a number of PID re-mapping options on an output transport stream basis. The output PID values for PMTs and all components are then determined by the APEX1000.
Page 152 SimulCrypt is performed; connection with an EIS or utilization of Internal EIS is expected to define and schedule scrambling of services. Note: Only applicable in Manual Routing and UDP Port Mapping operating modes. Configuration • Configuring QAM Ports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 153: Manual Routing
Manually routed input streams cannot be the same as a redundant Manual Routing or redundant SDV input stream(s). Program Mapping To configure Active Mappings, select Manual Routing > Program Mapping > QAM Module > QAM number: Manual Routing • Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 154: Enabling Program Mappings
4. Click Apply. 5. Click Refresh to update the screen. Note: When a row is enabled, it moves to the Active Mappings panel. Manual Routing • Program Mapping APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 155 Identifies the input MPEG program number for the transport stream (0 – 65535). Input Program No. 0 is used as a wild card program. This informs the APEX1000 to map the first service listed in the input PAT message to the specified output.
Page 156: Source Id And Provider Id
The Service List window displays: 3. Scroll through the Service List to highlight the desired entries. 4. Click Insert. 5. Click Close to exit. Manual Routing • Program Mapping APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 157 The corresponding Manual Routing pop-up displays: 2. Click Yes to disable all mappings and reset to default values, or click No to cancel. Manual Routing • Program Mapping APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 158 Quick Status View Click Status on the Program Mapping window to display an auxiliary menu: From this menu, you can view the status of specific APEX1000 functions, as shown in the examples below: • Input PSI Table — Displays a list of program-specific information messages that are being extracted from the APEX1000 inputs.
Page 159: Udp Mapping
UDP port. To configure UDP Mappings, select Manual Routing > UDP Mapping: Figure 7-2 — UDP Port Mapping Manual Routing • UDP Mapping APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 160 *Changing this setting causes all programs already mapped to be deleted and re-added, resulting in a momentary glitch in the video streams. Manual Routing • UDP Mapping APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 161: Udp Map Multicast Configuration
4. Click Refresh to update the screen. Note: You can also disable all UDP Port Mappings by applying the Clear All /Disable All functions. Manual Routing • UDP Mapping APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 162: Stream Pass Thru Configuration
This window allows pass through of an entire input stream to a QAM Channel. Acting as a surrogate controller, the APEX1000 EM is used to configure the APEX1000 for service routings. When the APEX1000 EM is the APEX1000 controller, the APEX1000 can operate in Manual Routing, Undefined, or Session Control modes.
Page 163: Ancillary Pid Mapping
Configuring Ancillary PID Parameters To configure Ancillary PID processing, select Manual Routing > Ancillary PID Mapping: Manual Routing • Stream Pass Thru Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 164: Figure 7-5 - Ancillary Pid Mapping
Note: A mapping row that is not enabled displays in the Available Mappings panel. When you enable a row, it moves to the Active Mappings panel. Every entry in both lists is directly editable. Manual Routing • Stream Pass Thru Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 165 Output PID (hex) Output PID to use for the data. If PID remapping is disabled, the output PID value must match the input PID value. When PID Remapping is enabled, the APEX1000 will enforce a range of PIDs that can be remapped.
Page 166: Input Stream Redundancy
SDV services have redundancy configured by the ERM, and do not require any APEX user configuration. Figure 7-6 — Input Stream Redundancy Manual Routing • Input Stream Redundancy APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 167 Select an Enabled GigE Interface or N/A to disable a row. Input UDP Port Input UDP port from which to obtain data. Manual Routing • Input Stream Redundancy APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 168 RF port, and the primary RF port is not failed (in error). Note: This function only becomes available when you check Redund Enabled. Manual Routing • Input Stream Redundancy APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 169 Note: The Apply function is set on a row basis rather than for the entire window. Apply is set only for rows that have changed. Manual Routing • Input Stream Redundancy APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 170: Manual Routing Ts Redundancy
When a failover to a secondary occurs, there is no automatic fallback. To fallback to the primary, you must force the secondary to fallback to the primary. Manual Routing • Manual Routing TS Redundancy APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 171: Data Stream Identification
GigE streams may encounter network jitter, and the streams can cause overflows of the GigE buffers without proper identification and buffering. This will cause loss of data and packets. Manual Routing • Manual Routing TS Redundancy APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 172 The Gigabit Ethernet IGMP v3 Source IP Address. Warning! Only list streams without PCR packets in this table. Do NOT add video/audio input streams to this table. Manual Routing • Manual Routing TS Redundancy APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 173: Quick Enable/Disable
The Quick Enable/Disable window displays: 2. Click Yes to enable or disable all mappings. 3. Click No to exit without making any changes. Manual Routing • Quick Enable/Disable APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 174: Sdv - Switched Digital Video Controls
CAUTION After choosing a controller type in the Session Control Configuration window, you must configure the APEX1000 for that mode (RPC, RTSP, or MHA) only. Do not use any other menus. SDV — Switched Digital Video Controls • Session Controlled Mode APEX1000 All-Purpose Edge QAM Software Version 2.4.x •...
Page 175: Figure 8-1 - Session Control Configuration
Figure 8-1 — Session Control Configuration Session Control Configuration window field definitions Item Definition/Range SDV Controller Type Provides four selections to set the SDV controller type of the APEX1000: • None • • RTSP • Note: Any changes to the controller type require a system reboot before taking effect.
Page 176: Rpc Session Control
APEX1000 interfaces. The APEX1000 can be operating in either SDV or VOD/BC systems. You must configure the APEX1000 to define those GigE inputs that map to a specific QAM output channel. The APEX uses the RPC Session Control window to generate this configuration.
Page 177: Rpc Session Control Pop-Up
GigE1 and GigE2 or GigE3 and GigE4). 2. Click Apply. Note: While disabled, the APEX1000 only reports the sessions for the requesting manager. In addition, you cannot modify Primary and Secondary interfaces if there is an active session control mapping on the specified output stream.
Page 178: Rpc Status
RPC Status The RPC Status window displays the status of all RPC connections on the APEX1000. It shows a map of the (up to) 768 input multicast streams coming input on GigE and output to QAM RF: Figure 8-3 — RPC Status SDV —...
Page 179 Input Program Identifies the input MPEG program number for the transport stream (0 – 65535). This informs the APEX1000 to map the first service listed in the input PAT message to the specified output. Note: Input Program No. 0 is used as a wild card program.
Page 180: Rpc Qam Status
This is not the BW of current active SDV sessions, but the total BW reserved by the manager for SDV sessions. SDV — Switched Digital Video Controls • RPC Session Control APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 181: Rtsp Controller Configuration
RTSP Controller Configuration In RTSP and MHA mode, the APEX1000 operates in a SDV or VOD system which uses RTSP to set up sessions. The APEX needs to be configured with a Session Controller, GigE input groups, and QAM outputs. These settings are used to establish communication with the session controller and notify the controller about the APEX1000 interfaces.
Page 182 Range: 0 – 65535 The default value is 7100. Hold Time (s) This is the amount of time (in seconds) that the APEX1000 will wait for a keepalive message. If the timer expires, the connection to the manager is considered lost.
Page 183: Rtsp Gige Group Configuration
RTSP GigE Group Configuration Use this window to configure RTSP GigE inputs: Figure 8-6 — RTSP GigE Group Configuration SDV — Switched Digital Video Controls • RTSP Controller Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 184: Rtsp Qam Configuration
RTSP QAM Configuration Use this window to configure RTSP QAM RF outputs: Figure 8-7 — RTSP QAM Configuration SDV — Switched Digital Video Controls • RTSP Controller Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 185: Rtsp Status
The default value is 1000. RTSP Status This window shows the status of all RTSP connections on the APEX1000, as well as a map of the (up to) 768 input multicast streams coming in on GigE and going out to QAM Figure 8-8 —...
Page 186 Identifies the input MPEG program number for the transport stream (0 – 65535). Input Program No. 0 is used as a wild card program, and informs the APEX1000 to map the first service listed in the input PAT message to the specified output. Output Program The Output Program Number (1 –...
Page 187: Rtsp Qam Status
QAM Reserved Bandwidth in Mbps reserved by the manager. MPTS Mode QAM channel processing mode (pass-through or multiplexing). SDV — Switched Digital Video Controls • RTSP Controller Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 188: Rtsp Events
Identifier for the Source of the event (external controller or internal task). Description Event Text description of the event. Description SDV — Switched Digital Video Controls • RTSP Controller Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 189: Mha Encryption Configuration
APEX1000 must be configured with an encryption mode for dynamic VOD sessions. • The APEX1000 must also be configured with default CCI, APS, and CIT settings to use, in the event that the session VOD encryption parameters for a session setup (from the ERM) are incomplete.
Page 190: Sdv Ts Redundancy
In both RTSP and MHA modes, the ERM is notified of all loss of input streams and notified of all failovers to the secondary input stream. SDV — Switched Digital Video Controls • RTSP Controller Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 191: Configuring For Switched Digital Video
Configuring for Switched Digital Video APEX1000 SDV Configuration The figure below shows a typical SDV network configuration for the APEX1000, including devices which must be present for proper switched digital operation: Figure 9-1 — APEX1000 Network Configuration SDV Session & Resource control SVOM APEX 1000 Status &...
Page 192: Step By Step Instructions
An HFC network connected to the APEX1000 RF/QAM outputs Step by Step Instructions This section describes how to configure the APEX1000 for operation in a switched digital environment, and is intended to provide basic setup information for the APEX1000 for users familiar with Motorola products, such as the SEM and the NE1000.
Page 193 3. Configure the Default Gateway for the enabled port pair. 4. Click Apply to incorporate these changes in the APEX1000. Configuring for Switched Digital Video • Step by Step Instructions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 194 2. Confirm that the QAMs are not muted by clearing the Mute checkbox. 3. Configure the EIA channel range for the QAM. Configuring for Switched Digital Video • Step by Step Instructions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 195 All and selecting the appropriate operating mode. Configuring Switched Digital Mode On this screen, you can configure the APEX1000 for a specific session control mode, by selecting SDV > Session Control Config. You can also configure the Data Carousel PID in RPC Mode, and the Redundancy Type...
Page 196 2. Click Apply to incorporate these changes in the APEX1000. Note: You must reboot after selecting the controller type. Configuring for Switched Digital Video • Step by Step Instructions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 197 RPC Mode Specific Configuration When the APEX1000 is configured for RPC SDV mode, only the input-output pairing must be configured through the EM. (This process assumes the RPC session controller is already configured and operating correctly.) To configure session control mode specific settings, select SDV > RPC Session Control.
Page 198 RTSP/MHA Mode-Specific Configuration These parameters establish communication with the controller and inform the controller of the APEX1000 interfaces. To configure an RTSP or MHA session, you must first configure the APEX1000 with GigE input information and QAM output information. (The RTSP controller interface is configured last.)
Page 199 3. Click Apply to implement these changes in the APEX1000. The configuration changes are reported to the session controller. Configuring for Switched Digital Video • Step by Step Instructions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 200 Configuring QAM Outputs You must also use the RTSP QAM Configuration window to configure the APEX1000 QAM outputs: 1. Select SDV > RTSP QAM Config 2. Click the Edge Configuration button on the RTSP Controller Configuration window, and then select RTSP QAM Configuration: The RTSP QAM Configuration window displays: Configuring for Switched Digital Video •...
Page 201 APEX if the average bandwidth changes by more than this amount. Note: Motorola recommends keeping this parameter at the default value of 1000 kbps. 3. Click Apply to apply these changes to the APEX1000. The configuration changes are reported to the session controller. Configuring the RTSP Controller Use the RTSP Controller Configuration window to configure which parameters the APEX uses for communicating with the RTSP controller.
Page 202 Note: Motorola recommends setting the Hold Time to 30 s. 6. Click Apply to apply these changes to the APEX1000. (A VREP session will be established with the controller.) 7. Click Refresh to update the Communication Status, and confirm that the controller is both Discovered and Connected.
Page 203: Simulcrypt
SimulCrypt Overview To allow integration with third party CA providers, the APEX1000 supports DVB SimulCrypt. SimulCrypt is a Digital Video Broadcasting (DVB) standard that defines specific interfaces to support interoperation between two or more conditional access systems at a digital video head-end or satellite uplink, and purposed to protect a service (or range of services) sharing a common scrambling code.
Page 204: Simulcrypt Functions
V2, V3 Transfer of third party EMMs for insertion into multiplex. V3, V4 Transfer of scrambling, scheduling and access criteria between EIS and SCS. SimulCrypt • Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 205 SimulCrypt Redundancy Support For each Active ECMG channel configured in the APEX1000, it is possible to configure a Backup ECMG channel (the Backup ECMG channel needs to be linked to the same CAS).
Page 206: Simulcrypt Configuration
Use this window to configure general information governing the communication with different entities within the network related with SimulCrypt functionality. For access, select SimulCrypt > SimulCrypt Configuration: Figure 10-1 — SimulCrypt Configuration SimulCrypt • SimulCrypt Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 207: Scs Overview
This parameter is used to guarantee that channel connections from different APEX-SCS to the same ECMG entity use a unique identifier within the headend. Range: 0 – 20000 SimulCrypt • SimulCrypt Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 208 (by-default) value of 0, so that no ecm_id shifting is performed for ECM streams created by the secondary APEX device. Range: 0 – 20000 SimulCrypt • SimulCrypt Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 209: Emmg Configuration
EMMG entities to receive EMM data from different Conditional Access Systems for SimulCrypt. To access this feature, select SimulCrypt > EMMG Configuration: Figure 10-2 — EMMG Configuration SimulCrypt • EMMG Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 210 • EMM messages from for all the other EMMG entities will be played out in all output transport streams. SimulCrypt • EMMG Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 211: Scs-Ecmg Configuration
For access, select SimulCrypt > SCS-ECMG Configuration. The SCS-ECMG Configuration screen displays in the default Channels tab: Figure 10-3 — SCS-ECMG Configuration — Channels SimulCrypt • SCS-ECMG Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 212: Scs-Ecmg Configuration Channels
Use this window to configure the connectivity for each of the existing devices in the SimulCrypt network acting as ECMG entities: Figure 10-4 — SCS-ECMG Configuration — Hosts SimulCrypt • SCS-ECMG Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 213: Scs-Ecmg Configuration Supercas
This (read-only) value shows the conditional access system or vendor name officially assigned to the corresponding CAS Sys ID. Only vendors currently certified by the APEX1000 are identified. The complete list of CAS names is available in the ETSI-ETR162 standard document.
Page 214: Eis Configuration
EIS Configuration This window allows you to define if the scrambling provisioning is to be performed by an external EIS entity, or by means of direct configuration in APEX1000 element manager. To access this feature, select SimulCrypt > EIS Configuration.
Page 215: Scg Provisioning Configuration
1. Check the Enable box to select one or more rows in the Available Mappings panel. 2. Enter the remaining selections for that row. SimulCrypt • EIS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 216 A check mark in any of the columns indicates that the corresponding SuperCAS must be contacted to perform scrambling for the specified services in that output transport stream. SimulCrypt • EIS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 217: Access Criteria Configuration
Specifies the Access Criteria to be used when contacting an ECMG configured with the specified SuperCAS to request an ECM. Range: String of up to 256 hexadecimal values SimulCrypt • EIS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 218: External Eis Configuration
External EIS Configuration window field definitions Item Definition/Range EIS TCP Port Specifies the local TCP server port to be used to communicate with the event scheduler entity (EIS). SimulCrypt • EIS Configuration APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 219: Simulcrypt Events
Provides additional information to help identify the error condition (SimulCrypt error code). Description Provides a text description of the error or condition logged. SimulCrypt • SimulCrypt Events APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 220: Emmg Statistics
This window provides information on the status of EMM streams currently active in the SimulCrypt network. For access, select SimulCrypt > EMMG Statistics: Figure 10-11 — EMMG Statistics Note: All values in this window are read-only. SimulCrypt • EMMG Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 221: Emmg Channel Details Window
CAS Name Shows the conditional access system or vendor name officially assigned to the corresponding CAS identifier. Only vendors currently certified by the APEX1000 are identified. The complete list of CAS names is available in ETSI-ETR162 standard document. Active Streams Shows the number of streams active per EMMG channel.
Page 222: Ecmg Statistics
This window provides information on the status of ECM streams currently active in the SimulCrypt network. For access, select SimulCrypt > ECMG Statistics: Figure 10-12 — ECMG Statistics Note: All values in this window are read-only. SimulCrypt • ECMG Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 223 Displays (in milliseconds) the SimulCrypt Timing parameter reported by the ECMG entity. This value indicates the worst case time needed by an ECMG to compute an ECM. SimulCrypt • ECMG Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 224 ECMG channel status. Values are: • • indeterminate • warning • minor • major • critical Details Opens the ECMG Statistics Details window. SimulCrypt • ECMG Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 225: Ecmg Statistics Details Window
Identifies the ECM allocated by the headend to the ECM stream. Op State Shows the ECM stream operational status. Values are: • notApplicable • idle • settingUp • setup • provisioning • closing SimulCrypt • ECMG Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 226 Counter for the number of ECMs requested to the ECMG over this ECM stream. ECM Resp Counter for the number of valid ECMs received from the ECMG over this ECM stream. SimulCrypt • ECMG Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 227: Eis Statistics
This window provides information on the status of connectivity with EISentity in the SimulCrypt network. For access, select SimulCrypt > EIS Statistics: Figure 10-13 — EIS Statistics Note: All values in this window are read-only. SimulCrypt • EIS Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 228 Displays the recommended Crypto Period duration proposed by the EIS entity for the specific scrambling group. ECM Groups Number of ECM groups belonging to the specific scrambling group. SimulCrypt • EIS Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 229: Scg Details Window
ECM ID Shows the identifier allocated by the head-end to the an specific ECM stream within the scrambling group selected. SimulCrypt • EIS Statistics APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 230: Depi - Mpt Mode
DOCSIS SYNC messages Note: Version 2.4.x only supports MPT mode. PSP flow mode will be supported in a future version of the APEX1000. DEPI – MPT Mode • Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 231: Depi Control Connections
Use this window to define the parameters which control the delivery of DOCSIS frames from the M-CMTS core to the EQAM devices: Figure 11-1 — DEPI Control Connections window DEPI – MPT Mode • Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 232 You cannot modify the control connection configuration information if there is an active session setup with the corresponding M-CMTS core entity. DEPI – MPT Mode • Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 233: Depi Session Mapping
Use this window to define mapping parameters, such as the set of UDP ports to be used for session data transfer in the DEPI interface: Figure 11-2 — DEPI Session Mapping window DEPI – MPT Mode • Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 234 Status > Status. 3. You cannot modify the session-specific information (Remote DEPI ID, UDP port) if the corresponding session is active (enabled). DEPI – MPT Mode • Overview APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 235: Status
Status Reports To display the drop-down list of available reports, click Status on the APEX1000 EM menu bar. Please note that a Critical alarm prevents the APEX1000 from performing operational requirements, while Warning, Minor, and Major alarms allow uninterrupted operation, and allow corrections to take place at a later time.
Page 236: Alarms
Alarms The Alarms window represents a software panel of monitored conditions in the APEX1000. Although not applicable to all alarm conditions, the six status levels are listed in the preceding graphic. Figure 12-1 — APEX Alarms Note: All alarms are enabled by default. To disable any enabled alarm, un-click the check box and click Apply.
Page 237: Temperature And Fan
The Temperature and Fan Status window provides Celsius readings (in revolutions per minute) of the two temperature sensors and speeds of the three fans: Figure 12-2 — Temperature and Fan Status Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 238 Fan speed reading in revolutions per minute of the specified power supply. The numbering (1 – 2) corresponds to power supply modules from left to right when facing the back of the unit. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 239: Power Supply
Power Supply This window provides status readings of the available power supply units and fan modules: Figure 12-3 — Power Supply Status Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 240 Input Power Warning (yellow) • • Output Power Minor alarm (blue) • • Major alarm (magenta) Comm Error • • Fault Condition Critical alarm (red) Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 241: Hw And Sw Versions
HW and SW Versions This window provides read-only information regarding APEX1000 hardware and software: Figure 12-4 — HW/SW Versions Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 242 Identifies the MPC2MUX field-programmable gate array (FPGA) version. Glue CPLD Version Identifies the Glue CPLD Version. DPM Version Displays the current Data Protection Manager (DPM) Version. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 243: Hardware Events
A zero in this area indicates that: • The error does not use this parameter • The APEX1000 cannot determine the port or stream number for the error • The APEX1000 is not supporting this parameter for the error Description Provides a text description of the error.
Page 244: Qam Versions
Shows the RF Port Serial number. Board Model ID Shows the Board Model ID number. FW Revision Shows the FW Revision number. FPGA Revision Shows the FPGA Revision number. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 245: Qam Status
Figure 12-7 — QAM Status Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 246: Qrm Download Window
The download of a single QAM module (two QRMs) takes approximately five (5) minutes. During a download, the QAM channels are inactive and cannot be used. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 247: Figure 12-8 - Qrm Download Window
6. To close the QRM Download window and exit after the procedure is complete, click Close. (Do not click Close while the download is in progress.) Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 248: Invalid Initializations
Text string of the MIB variable name of the data item or table. Description Shows the table leaf to which the error pertains (when the data item is part of a table). Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 249: Rds Status
Rights Data Server in the RDS Error column. Note: If no address is contained in this entry, the error reported applies to all ACPs or to the entire APEX1000. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 250 Service List Acquisition Successful • RMD Acquisition Successful • CSN Acquisition Failed • EMM Acquisition Failed • Service List Acquisition Failed • RMD Acquisition Failed Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 251: Sfp Status
SFP Status The APEX1000 can retrieve SFP configuration from the SFP memory. When a Motorola- certified SFP is inserted into the APEX chassis, the APEX1000 can read the SFP memory to obtain SFP company name, Motorola part number, and SFP revision.
Page 252 The wavelength, vendor name, vendor part number, and vendor revision are then displayed on the EM screen. The other parameters become available on the APEX1000 MIB, and are recorded during a status capture. Note: Diagnostic parameters are updated once per second. Alarms and warnings set when measurements exceed vendor specified limits.
Page 253: Chassis Redundancy Status
Redundancy status information is gathered from heartbeat message exchanged between the APEXs. The graphic below illustrates a sample of the Chassis Redundancy Status screen: Figure 12-12 — Chassis Redundancy Status Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 254 APEX in redundancy pair • Configuration not synchronized • Primary or Secondary APEX in fault or suspend state • Synchronizing Synchronizing configuration between active and standby APEXs Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 255 APEX Alarms window. Failover • Availability Fault • Link Fault • Configuration Fault For further Redundancy Alarm Status details, reference Alarms Window Field Definitions. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 256: Depi Status
View All Sessions Opens the DEPI Session Stats window to display status information for all active sessions. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 257: Figure 12-14 - Depi Session Stats Window
Number of data packets discarded in the specific DEPI session. Data Pkts Discard Seq Num Number of Data packets discarded due to a sequence number discontinuity in the specific DEPI session. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 258: Dti Status
SYNC messages when required by specific DEPI session configuration. Note: DTI clients may reside in M-CMTS devices, Edge QAM (EQAM) devices or Upstream Receivers. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 259: Mapping Error Log
Reserved: 224.0.0.0 – 224.0.0.255 • Not used: 0.0.0.0 Source This is the IP address of the source device for multicast reception. Mapping Displays the mapping range in->out. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 260: Mapping Error Codes
Secondary is already in use as a Primary input stream Secondary is already in use on another Primary input Secondary is exact same stream as Primary Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 261 Input PID already in use (mapped to same output) Primary interface port number out of range Primary interface port not enabled Primary UDP port is invalid Primary MC invalid Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 262 Invalid starting program number requested Invalid TS Offset Invalid mode bits Invalid Host FE UDP Port FE UDP Port already assigned to another MC group/Source Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 263 DEPI Session(s) still assigned to Control ID Duplicate DEPI TSID DEPI UDP port out of range DEPI Keepalive Timeout out of range GigE Interface Redundancy is enabled Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 264: Input Ts Events
Range: 0 – 65535 Input Multicast The Multicast receive IP address: • Valid Range: 224.0.1.0 – 239.255.255.255 • Reserved: 224.0.0.0 – 224.0.0.255 • Not used: 0.0.0.0 Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 265: Input Stream Status
The rate is then calculated by converting the MPEG packet counts into Megabits per second (Mbps). Figure 12-18 — Input Stream Status Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 266 Allows user to select which group of 32 input streams (out of 784 available) to display in the Input Stream Status window. Refresh Click to update the information on the screen. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 267: Gige Mpts Alarms And Traps
(secondary) stream. The alarm clears when all redundant pairs fallback to the Primary input stream. A trap is issued for the first failover event. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 268 (data rate or stream rate). The APEX1000 will then set an alarm and issue a trap whenever any GigE input stream falls below the specified low bit rate.
Page 269: Gige Packet Statistics
MPEG data received by the GigE and routed to each output transport stream. Note: This number does not include PSI insertion, such as PATs, PMTs, ECMs, etc.. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 270 Total number of GigE MPEG packets routed from GigE input to an output Packets stream. Refresh Click to update the information on the screen. *Average is taken over the preceding five seconds. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 271: Gige Frame Statistics
MPEG DOCSIS received during the last status checking interval (five seconds). Total – shows the total number of singlecast frames received since last reset. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 272: Gige Buffer Statistics
Use to Reset All (or each individual GigE 1 – 4) totals. GigE Buffer Statistics The APEX1000 uses the GigE frame buffer to hold frames while its de-jittering algorithm performs time-based recovery. This algorithm attempts to correct the timing errors on the incoming MPEG streams, principally caused by the following factors: •...
Page 273: Figure 12-21 - Gige Frame Buffer Status
Displays the maximum GigE frame buffer level (as a percentage of Buffer Overflow Level) recorded for the hour. Max Full GPS Time Displays the GPS time when this table entry was last updated. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 274 GigE buffers. The APEX1000 is designed to reset a GigE frame buffer prior to overflowing. The maximum input data rate and nominal buffer settings are used to calculate the size of the GigE frame buffers. If an overflow occurs prior to a reset, then the APEX1000 has been incorrectly configured the (input data rate setting is incorrect).
Page 275: Input Psi Table
The following table contains a list of program-specific information messages that are extracted from the APEX1000 inputs. All messages extracted from APEX1000 inputs that are being used by the APEX1000 are displayed (PATs, PMTs, and PITs): Figure 12-22 — Input PSI Table Status •...
Page 276 Item Definition Type Indicates whether this message comes from an APEX1000 input or output, or if the source is unknown. Indicates the input interface (GigE 1 – 4 or Enet 1 – 2) port ID for which this message applies.
Page 277: Input Psip
Input PSIP The following table contains a list of messages that are extracted from the APEX1000 input PSIP: Figure 12-23 — Input PSIP window Input PSIP window field definitions Item Definition GigE Input Shows the number of GigE input for this PSIP message.
Page 278: Output Program Status
Output Program Status This window can help you determine the status of all mapped programs. The APEX1000 maps input programs to output streams in the same manner, regardless of the Operating mode. The Output Program Status window shows the programs that are being remapped to a particular output stream.
Page 279 PIT is updated). 6. If the output program is being encrypted (input program is not pre-encrypted), then the APEX1000 will mark the component PIDs with the appropriate scrambled control bit settings and encrypt the payload of the component PIDs. Additionally, ECM messages such as the PRK and WKE are inserted.
Page 280 Displays the current encryption status. PSIP Status Displays the PSIP Status window. APEX Service Error Alarms Provides an immediate alert to a new mapping that is in error. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 281: Program Status Summary
PCR PID is a value that is not supported. — — • PMT Error ES PIDs Unsupported One or more Elementary stream PIDs are — — invalid. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 282: Output Ts Events
To use this log, select a column header to sort and display the list based on the entries in that column. Figure 12-25 — Output TS Events Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 283: Host Packet Statistics
(for example, five seconds) for each interface output port by service number (1 – 48). A section of the Packet Insertion Statistics window is illustrated below: Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 284: Figure 12-26 - Packet Insertion Statistics
Shows the insertion rates of the MPEG interface output ports during the last monitoring period. Total Packets Inserted Displays the total number of packets inserted by the MPEG interface output ports. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 285: Figure 12-27 - Host Ip Packet Statistics
Figure 12-27 — Host IP Packet Statistics Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 286 Discarded Rate (Kbps) Discarded rates of the MPEG interface output ports during the last monitoring period. Total Number Packets Total number of packets discarded by the MPEG interface output ports. Discarded Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 287: Figure 12-28 - Host Ip Input Statistics
Displays the discarded data rate of the MPEG interface output ports during (Kbps) the last monitoring period. Total Number Displays the total number of packets discarded by the MPEG interface Discarded MPEG output ports. Packets Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 288: Output Transport Utilization
Note: To determine the output data rate, each output transport stream is monitored once per second. Figure 12-29 — Output Transport Utilization Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 289 Minimum utilization for a sample during this sampling interval (in bps). Minimum This is the minimum data rate over the last 15 minutes (sampling interval is a sliding 15 minute interval). Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 290 When the APEX1000 time source is internal (no GPS time source available), you can select PC time from the System Configuration window. This allows the APEX1000 to use the current PC time of the APEX1000 EM for logging purposes. Alarm Threshold (%)
Page 291: Output Psi Table
Output PSI Table The following table contains a list of messages that are inserted into the APEX1000 outputs. For the APEX1000 outputs, only PATs and PMTs are shown: Figure 12-30 — Output PSI Table status window Note: Clicking on a row in the left pane will highlight and expand the appropriate node in the right pane’s tree, as shown below:...
Page 292 The 1024 bytes of a message can be divided into parts, which are indexed with this field. Time Indicates the time the message was logged. Message Displays the raw data stream of the message. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 293: Output Psip
203 - EIT • 202 - RRT • 205 - STT GPS Time The GPS time when the PSIP message was added to the table. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 294: Psip Status
Current Output Service Number. Output TS Current Output Transport Stream of this service. Source ID Current PSIP Program Source Id. Service State Current program PSIP state. Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 295: Save Apex1000 Status
This feature saves all of the current status to the apexstatus.txt file, located in the same directory as the file. apex.jar Figure 12-33 — Save APEX1000 Status Status • Reports APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 296: Troubleshooting
Motorola Online: http://businessonline.motorola.com The TAC is on call 24 hours a day, 7 days a week. In addition, Motorola Online offers a searchable solutions database, technical documentation, and low-priority issue creation and tracking. For specific toll-free numbers when calling from outside the United States, please refer to your product manual or our Web page.
Page 297: Led/Error Indications
Fan Fault – one or more fans dropped Check fans; reference Fan Field below the allowed RPM level. Replacement Procedure for instructions on replacing a failed fan. Troubleshooting • LED/Error Indications APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 298 Reload memory from the BOOTP server. • BOOTP BOOTP reply not received. Verify that the MAC address is unsuccessful correct. • Verify Ethernet connectivity. Troubleshooting • LED/Error Indications APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 299: Specifications
280 W Electrical Specifications for DC Inputs Parameter Description Voltage, DC –40 through –60 VDC Nominal, DC –48 VDC Power (@ –48 VDC) Appendix A • Specifications APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 300: Operating Environment
The maximum MPEG throughput across a single GigE interface pair is 931 Mbps, assuming 24 QAMs active with a 38.81 Mbps data rate. • The maximum MPEG throughput across the APEX1000 is 1.863 Gbps, assuming 48 QAMs active with a 38.81 Mbps data rate. •...
Page 301: Gige Interface
CAT-5e or CAT-6 cable. SFP Specifications The APEX1000 GigE interface requires SFP transceivers. Each of the four GbE interfaces can accept any one of a variety of Small Form Factor Pluggable (SFP) modules, including 1000 Base SX (850 nm), 1000 Base LX (1310 nm), and 1000 Base ZX (1550 nm) fiber based modules, or 1000 Base T Electrical based modules.
Page 302 1 kHz to 10 kHz < –35 dBc 10 kHz to 50 kHz < –54 dBc 50 kHz to 3 MHz < –56 dBc Appendix A • Specifications APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 303: Cabling Specifications
300 feet Ethernet 10Base-T Interface Connector Pin Out Pin Number Signal Direction Description transmit data + TX– transmit data – receive data + Appendix A • Cabling Specifications APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 304: Rs-232 Interface Cabling
CommScope F59 HEC T/CU Headend Cable or equivalent 75 Ohm 100% shielded coax cable DTI Client RJ45 Interconnect Scheme RJ45 Pin Number Signal SIG+ SIG+ 3,4,5,6,7,8 Appendix A • Cabling Specifications APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 305: Dti Client Rj45 Interconnect Scheme
Electronics Note: Items with a Motorola part number are orderable directly from Motorola. Items that do not have a Motorola part number are supported, but must be ordered direct from the SFP manufacturer (supplier part number provided). Appendix A • Certified SFP Transceiver Vendors APEX1000 All-Purpose Edge QAM Software Version 2.4.x •...
Page 306: Alarms Window Field Definitions
Major indicates input power fault, output power fault communications fault, or no module installed • Critical indicates Over Temperature fault Appendix B • Alarms Window Field Definitions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 307 (PAT or PMT), or is unable to process input PAT or PMT and cannot output program as mapped Appendix B • Alarms Window Field Definitions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 308 Session Control Alarms RTSP Controller Failure to communicate with Alarm None Can be disabled Alarm RTSP controller • Major Init Alarms Appendix B • Alarms Window Field Definitions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 309 Channel is Disabled and Backup ECMG by user Channels are not setup 3. Overall alarm – 1 alarm for all ECMG channels Appendix B • Alarms Window Field Definitions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 310 Major when received SCG 4. Overall alarm – only one Provision is incorrect trap sent for the first error found Appendix B • Alarms Window Field Definitions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 311 APEX APEX Unit Alarm Highest alarm within the Alarms APEX • Major • Major error received Critical Appendix B • Alarms Window Field Definitions APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 312: Initialization Information
None (Self boot). If BOOTP is selected, it begins broadcasting BOOTP requests over its ENET1 Ethernet port. Self boot initialization occurs when the APEX1000 times out waiting for a reply and then initializes itself from the information stored in its non volatile memory.
Page 313: Configuration Modes
APEX1000. • If a downloaded FOF and the APEX1000 local copy are the same and a force download flag does not exist in that FOF, the APEX1000 does not download any additional files. It continues booting using the values stored in non volatile memory.
Page 314: Bootp Request And Reply Format
The file of files (FOF) name for the APEX1000 (apex.fof) • The path for the FOF • The network mask Note: Both BOOTP Request and Reply are transferred using UDP. Appendix C • Initialization Information APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 315: Apex1000 File Of Files
Apex1000.fof (File of files) Contains three field columns: source path, destination path, and force flag. Do not change the symbolic name of the APEX1000 in the second field, as it can cause an initialization failure. apex.cod Host application code for main APEX1000 processor.
Page 316 #---------------------------------------------------------- --------- /bootdir/apex/02_00.001/mux_des.rbf /muxfpga1/mux_des.img /bootdir/apex/02_00.001/mpc2mux.rbf /mpc2mux/mpc2mux.img /bootdir/apex/02_00.001/mpc2gx60.rbf /mpc2gx60/mpc2gx60.img /bootdir/apex/02_00.001/dtifpga.bin /dtifpga/dtifpga.img /bootdir/apex/02_00.001/gluefpga.rbf /gluefpga/gluefpga.img #/bootdir/apex/02_00.001/qrmimage.rbf /qrmimage/qrmimage.img #---------------------------------------------------------- --------- # GigE Files (Non-DOS File Systems) Appendix C • Initialization Information APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 317 Clarifications and Extensions for the Bootstrap Protocol, RFC 1542 Refer to these specifications for complete information on the BOOTP packet format and field descriptions. Appendix C • Initialization Information APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 318: Fan Field Replacement Procedure
To remove a fan: 1. Identify the failing fan whose blade is not turning on the rear panel of the APEX1000. Note: A failing fan blade does not turn, whereas a marginal fan may have a rasping sound that is definitely a pitch off, and also surges in volume from the steady hum of other fans.
Page 319: Replacement Fan Kit Assemblies
The diagram below details field fan removal and replacement steps: Replacement Fan Kit Assemblies The Motorola part number for an APEX1000 replacement fan kit assembly (one fan) is 492898-002. (The PS cooling fan is not field replaceable.) Motorola part numbers for APEX1000 replacement power supply assemblies are: •...
Page 320: Rfpm And Power Supply Modules
Appendix E RFPM and Power Supply Modules The APEX1000’s three RF Plug-in Modules (RFPM) are hot-swappable, and are plugged into the chassis from the rear of the chassis. The modules slide onto rails and mate with a high-speed docking connector on the main board, as shown below: Appendix E •...
Page 321: Identifying An Rfpm Or Filler Module
Installing an RFPM or Filler Module 1. Identify the slot where the RFPM or filler module is to be installed. Appendix E • RFPM and Power Supply Modules APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 322: Ac/Dc Power Redundancy
CAUTION Before removing and replacing a PS unit, certify that the APEX1000 is in full redundancy; operating in non-redundant power will require a complete system shutdown while removing and inserting a power supply module.
Page 323: Installing A Power Supply Filler Module
4. The fan is powered from the rear connectors; you should hear the fan running to indicate a successful installation. 5. Confirm a successful installation by accessing the Power Supply Status window: Appendix E • RFPM and Power Supply Modules APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 324: Rs-232 Test Console Port
The primary purpose of the menu is to configure the Internet Protocol (IP) address of the Ethernet 1 network interface. Properly setting the IP address is a prerequisite to using the APEX1000 EM. After the IP address has been properly assigned, the APEX1000 EM should be used for all subsequent configuration changes.
Page 325: Menu General Operations
Menu Selections The figure below is a summary illustration of menu selections 1 through 3: Appendix F • RS-232 Test Console Port APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 326 User Console Root Menu From the User Console Root Menu, you can access: • Show Enet1 Parameters — A quick access display for the APEX1000 MAC address and ENET1 parameters (IP, Subnet Mask, and Gateway addresses). • Enet1 IP Setup (Fixed Config) — Provides access to the fixed IP configuration Setup Menu.
Page 327 APEX1000 configuration files or application files have been purged. • Use Bootp to obtain config — Causes the APEX1000 to send a BOOTP request at boot. If a BOOTP reply is received, the APEX1000 will use the IP configuration assigned by the BOOTP server.
Page 328 Destructive Purge Menu (Root.4) You should only use this menu as a last resort, preferably under the direction of Motorola BCS technical support. Indiscriminant use of this menu may cause the APEX1000 to become non-operational.
Page 329: Typical Scenarios
PIDs will be remultiplexed. Reset APEX-EM User Name and Password Menu (Root.5) This menu option allows you to reset the APEX1000 EM username and password to the factory default values ( ). This menu is useful in the event a user root, password forgets the username and/or password previously defined for an APEX1000.
Page 330: Glossary
Entitlement Control Message Generator Element Manager Entitlement Management Message EMMG Entitlement Management Message Generator Edge Resource Manager FPGA Field Programmable Gate Array GigE Gigabit Ethernet Glossary • Abbreviations and Acronyms APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 331 Operation, Administration, Maintenance, And Provisioning (Ethernet port) OM 1000 Out-of-Band Modulator 1000 Program Association Table Program Clock Reference Packet Identifier Program Map Table Glossary • Abbreviations and Acronyms APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 332 Transmission Control Protocol/Internet Protocol Transport Stream User Datagram Protocol UDP/IP User Datagram Protocol/Internet Protocol Universal Resource Locator Unshielded Twisted Pair Video on Demand Working Key Glossary • Abbreviations and Acronyms APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 333 A data communications network within a given area, such as a control room, (LAN) office, specific workplace, building, or building cluster up to six miles wide (10 kilometers), but not using a common carrier. Glossary • Abbreviations and Acronyms APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 334 A transmission protocol that uses an IP address to identify the destination host Protocol (UDP) and a port number to identify the destination application. Glossary • Abbreviations and Acronyms APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual 573408-001-a...
Page 335 Motorola, Inc. 101 Tournament Drive Horsham, PA 19044 U.S.A. http://www.motorola.com 573408-001-a 04/2010...

Motorola APEX1000 Installation And Operation Manual

Quick Links

Related Manuals for Motorola APEX1000

Summary of Contents for Motorola APEX1000
