Grizzly G0688 Datasheet

Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
Product Dimensions:
Weight ............................................................................................................................................................................. 57 lbs.
Length/Width/Height .......................................................................................................................................18" x 11
Shipping Dimensions:
Type ........................................................................................................................................................................ Wood Crate
Content .......................................................................................................................................................................... Machine
Weight .............................................................................................................................................................................. 88 lbs.
Length/Width/Height .........................................................................................................................................18" x 13
Electrical:
Switch .................................................................................................................................................... ON/OFF Paddle Switch
Switch Voltage ................................................................................................................................................................... 220V
Cord Length ..........................................................................................................................................................................8 ft.
Cord Gauge .................................................................................................................................................................16 gauge
Recommended Circuit Size ..............................................................................................................................................8 amp
Included Plug ........................................................................................................................................................................Yes
Plug Type ...........................................................................................................................................................................L6-20
Motor:
Type .................................................................................................................................................................................. TEFC
Horsepower ........................................................................................................................................................................
Voltage ............................................................................................................................................................................... 220V
Phase ................................................................................................................................................................................ Three
Amps ...................................................................................................................................................................................... 2A
Speed .........................................................................................................................................................................3450 RPM
Cycle ................................................................................................................................................................................. 60 Hz
Number Of Speeds ...................................................................................................................................................................1
Power Transfer ........................................................................................................................................................Direct Drive
Bearings ......................................................................................................................... Shielded and Permanently Lubricated
Main Specifications:
Operation Information
Grinder Swing on Lathe ....................................................................................................................................... 13"–20"
Large Grinding Wheel Speed ...........................................................................................................................4500 RPM
Large Grinding Wheel Size ................................................................................................................ 5"D x
Small Grinding Wheel Speed ...........................................................................................................16,500, 23,000 RPM
Small Grinding Wheel Size ...................................................................................................................1"D x
Miter Angle .........................................................................................................................................................50°–150°
Model G0688

mACHine dATA

model G0688
Tool PosT Grinder
sHeeT
⁄ " x 12"
1
2
1 ⁄ " x 16"
2
⁄ HP
1
2
⁄ "W x 1 ⁄ "B
3 5
4 8
⁄ "W x ⁄ "B
5 1
8 4
Page 1 of 2
