Summary of Contents for HIKVISION DS-KD8003-IME2

  • Page 1 Video Intercom Two-Wire Bundle User Manual...
  • Page 2 WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,...
  • Page 3 Video Intercom Two-Wire Bundle User Manual CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY...
  • Page 4 Video Intercom Two-Wire Bundle User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or Danger could result in death or serious injury. Indicates a potentially hazardous situation which, if not Caution avoided, could result in equipment damage, data loss,...
  • Page 5 Video Intercom Two-Wire Bundle User Manual Safety Instruction Warning All the electronic operation should be strictly compliance with the electrical safety ● regulations, fire prevention regulations and other related regulations in your local region. Please use the power adapter, which is provided by normal company. The power ●...
  • Page 6 Video Intercom Two-Wire Bundle User Manual Please use the provided glove when open up the device cover, avoid direct contact ● with the device cover, because the acidic sweat of the fingers may erode the surface coating of the device cover. Please use a soft and dry cloth when clean inside and outside surfaces of the ●...
  • Page 7 Video Intercom Two-Wire Bundle User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 8 Video Intercom Two-Wire Bundle User Manual EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, RE Directive 2014/53/EU,the RoHS Directive 2011/ 65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the...
  • Page 9 Video Intercom Two-Wire Bundle User Manual l'appareil ne doit pas produire de brouillage, et l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada.

  • Page 10: Table Of Contents

    Video Intercom Two-Wire Bundle User Manual Contents 1 About this Maunal ..................1 2 Appearance ....................2 3 Terminal and Wiring Description ..............7 3.1 Terminal Description ..................7 3.2 Wiring Description .................... 9 4 Installation ....................11 4.1 Install Indoor Station ..................11 4.1.1 Configure Indoor Station Address ............
  • Page 11 Video Intercom Two-Wire Bundle User Manual 5.3 Activate via SADP .................... 56 5.4 Activate Device via Web .................. 57 6 Remote Configuration via Web ..............59 6.1 Login and Logout ..................... 59 6.1.1 Log in the Web ..................59 6.1.2 Logout ..................... 59 6.2 Quick Configuration ..................

  • Page 12: About This Maunal

    Video Intercom Two-Wire Bundle User Manual 1 About this Maunal Get the manual and related software from or the official website (http:// www.hikvision.com). Product Model Two-Wire Door Station DS-KD8003-IME2 Two-Wire Indoor Station DS-KH1201 Network Distributor DS-KAD7040 Analog Distributor DS-KAD1040...

  • Page 13: Appearance

    Video Intercom Two-Wire Bundle User Manual 2 Appearance Two-Wire Door Station Figure 2-1 Front and Side Panel Table 2-1 Appearance Description Description Microphone Low Illumination IR Supplement Light Built-in Camera Loudspeaker Call Button Nametag TAMPER...
  • Page 14 Video Intercom Two-Wire Bundle User Manual Figure 2-2 Bottom Panel Table 2-2 Appearance Description Description Network Interface Module-​ c onnecting Interface (output) Terminals Two-Wire Indoor Station Figure 2-3 Appearance of Indoor Station Table 2-3 Description Description Description Screen Live View/Switch Microphone Terminals Volume-...
  • Page 15 Video Intercom Two-Wire Bundle User Manual Description Description Volume+ Four-Wire Terminal Receive/Decline DIP Switch Unlock Door 2 Debugging Port Unlock Door 1 Jumper Note The Debugging Port is used for debugging only. Network Distributor Figure 2-4 Appearance of Distributor...
  • Page 16 Video Intercom Two-Wire Bundle User Manual Table 2-4 Description Description Description Cascade Input & Output Network Interface (Reserved) Cascade Channels Power Indicator Power Input Cascade Indicator Reset Button Network Interface (Supports for PoE Output) Note The appearance may vary according to different device models. Refers to the actual device.
  • Page 17 Video Intercom Two-Wire Bundle User Manual Table 2-5 Description Description Description Cascade Output Terminal Cascade Output Terminal Cascade Output Terminal Two-Wire Input Terminal Cascade Output Terminal Two-Wire Output Terminal...

  • Page 18: Terminal And Wiring Description

    Video Intercom Two-Wire Bundle User Manual 3 Terminal and Wiring Description 3.1 Terminal Description Two-Wire Main Unit Terminal Figure 3-1 Two-Wire Main Unit Terminal Table 3-1 Descriptions of Terminals and Interfaces Interface Description Door Lock Relay Output (NC) Door Lock Relay Output (NO) Common Interface Door Lock Relay Output (NC) Door Lock Relay Output (NO)
  • Page 19 Video Intercom Two-Wire Bundle User Manual Interface Description AIN3 For the access of Exit Button 1 AIN4 For the access of Exit Button 2 485- Module-​ c onnecting Interface 485+ 12 V OUT Two-Wire Interface Two-Wire Interface Two-Wire Indoor Station Figure 3-2 Terminal of Indoor Station Table 3-2 Descriptions of Terminal and Interfaces Interface...

  • Page 20: Wiring Description

    Video Intercom Two-Wire Bundle User Manual 3.2 Wiring Description Typical application of the system is shown as below. Figure 3-3 Wiring Note Up to 10 indoor stations can be connected hand-by-hand. ● Up to 150 indoor stations can be connected to one terminal of the distributor. ●...
  • Page 21 Video Intercom Two-Wire Bundle User Manual Note The distributor can only connect 1 door station. Network door station and two-wire door station can not be connected to the distributor at the same time.

  • Page 22: Installation

    Video Intercom Two-Wire Bundle User Manual 4 Installation 4.1 Install Indoor Station 4.1.1 Configure Indoor Station Address DIP switches are used to coding the room No. of indoor station. The No. should be unique. The No. of DIP switches from left to right is 1 ~ 10. Figure 4-1 DIP Switch...

  • Page 23: Wall Mounting

    Video Intercom Two-Wire Bundle User Manual Table 4-1 Description Icon Description Represent 1 in binary mode Represent 0 in binary mode For example, binary value of the following status is: 00 0000 1100. And its decimal value is 12. Figure 4-2 Example 4.1.2 Wall Mounting It supports wall mounting.
  • Page 24 Video Intercom Two-Wire Bundle User Manual Before You Start Make sure the device in the package is in good condition and all the assembly ● parts are included. The power supply the indoor station supports is 48 VDC. Please make sure your ●...

  • Page 25: Install Door Station

    Video Intercom Two-Wire Bundle User Manual Note If you install the device with a gang box (75 mm(width) × 75 mm(length) × 46 ● mm(depth)), the left and right holes will be applied. If you install the device with a gang box (55 mm(width) × 101 mm(length) × 48.5 ●...
  • Page 26 Video Intercom Two-Wire Bundle User Manual Steps 1. Remove the rubber cover on the rear panel of the sub module to expose the DIP switch. Figure 4-5 DIP Switch 2. Set the sub module address according to the DIP rules, and install the rubber cover back.

  • Page 27: One-Module Installation

    Video Intercom Two-Wire Bundle User Manual 4.2.2 One-Module Installation One-Module Surface Mounting Before You Start Figure 4-6 Mounting Frame Note The dimension of one module mounting frame (W × H × D) is: 117 mm × 107 mm ● × 32.7 mm. The dimensions above are for reference only.
  • Page 28 Video Intercom Two-Wire Bundle User Manual Figure 4-7 Drill Screw Holes 3. Remove the stricker and insert the expansion sleeves into the screw holes. 4. Fix the mounting frame onto the wall with 4 expansion bolts. Figure 4-8 Fix the Mounting Frame...
  • Page 29 Video Intercom Two-Wire Bundle User Manual 5. Connect the cables to the corresponding interfaces of the main unit and insert the main unit into the frame. Figure 4-9 Insert the Main Unit 6. Fix the cover onto the frame. Figure 4-10 Fix the Cover One-Module Flush Mounting...
  • Page 30 Video Intercom Two-Wire Bundle User Manual Before You Start Figure 4-11 Front and Side View of the Gang Box Figure 4-12 Gang Box...
  • Page 31 Video Intercom Two-Wire Bundle User Manual Note The dimension of one-module gang box is: 115 (W) × 134 (H) × 56 (D) mm. The dimension is for reference only. Steps 1. Drill an installation hole, and pull the cables out. Note The suggested dimension of installation hole is 118 (W) ×...
  • Page 32 Video Intercom Two-Wire Bundle User Manual Figure 4-14 Mark the Screw Holes 4. Drill 4 holes according to marks on the wall, and insert the expansion sleeves into the screw holes. Note The suggested size of the hole is 6 (diameter) × 45 (depth) mm. 5.
  • Page 33 Video Intercom Two-Wire Bundle User Manual Figure 4-16 Remove the Mounting Ears 7. Connect the cables to the corresponding interfaces of the main unit and insert the unit into the gang box. Figure 4-17 Insert the Main Unit 8. Fix the cover and the main unit with 2 socket head cap screws by using a hexagon wrench (supplied).

  • Page 34: Two-Module Installation

    Video Intercom Two-Wire Bundle User Manual Figure 4-18 Fix the Cover 4.2.3 Two-Module Installation Two-Module Surface Mounting Before You Start Figure 4-19 Mounting Frame...
  • Page 35 Video Intercom Two-Wire Bundle User Manual Note The dimension of two-module mounting frame (W × H × D) is: 219 mm × 107 mm ● × 32.7 mm. The dimensions above are for reference only. The actual size can be slightly ●...
  • Page 36 Video Intercom Two-Wire Bundle User Manual Figure 4-21 Fix the Mounting Frame 5. Thread the module-connecting line across the thread hole of the frame. Pass the main unit connecting lines across the thread hole to the upper grid. Figure 4-22 Placement of Lines 6.
  • Page 37 Video Intercom Two-Wire Bundle User Manual 3) Organize the cable with cable tie in the package. The suggested cable connection picture as shown below. Figure 4-23 Line Connection Effect Picture 7. Insert the modules into the frame after wiring. The main unit must be placed in the top grid.
  • Page 38 Video Intercom Two-Wire Bundle User Manual Figure 4-25 Fix the Cover Two-Module Flush Mounting Before You Start Figure 4-26 Gang Box...
  • Page 39 Video Intercom Two-Wire Bundle User Manual Note The dimension of two-module gang box is: 237 (W) × 134 (H) × 56 (D) mm. The dimension is for reference only. Steps 1. Drill the installation hole, and pull the cable out. Note The suggested dimension of installation hole is 220 (W) ×...
  • Page 40 Video Intercom Two-Wire Bundle User Manual Figure 4-28 Mark the Screw Holes 4. Drill 4 holes according to the marks on the wall, and insert the expansion sleeves into the screw holes. The suggested size of hole is 6 (diameter) × 45 (depth) mm. 5.
  • Page 41 Video Intercom Two-Wire Bundle User Manual Figure 4-30 Remove the Mounting Ears 7. Connect cables and insert the modules. 1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of the main unit, then insert the main unit into the upper grid. 2) Connect the other end of Cable 2 to the input interface of the sub module.

  • Page 42: Three-Module Installation

    Video Intercom Two-Wire Bundle User Manual Note Cable 1 refers to the cables pulled out from the wall that connected to the main unit. Cable 2 refers to the module-connecting line in the accessory package. 8. Fix the cover with 2 socket head cap screws by using a hexagon wrench (supplied). Figure 4-32 Fix the Cover 4.2.4 Three-Module Installation Three-Module Surface Installation...
  • Page 43 Video Intercom Two-Wire Bundle User Manual Note The dimension of two-module mounting frame (W × H × D) is: 320.8 mm × 107 ● mm × 32.7 mm. The dimensions above are for reference only. The actual size can be slightly ●...
  • Page 44 Video Intercom Two-Wire Bundle User Manual Figure 4-35 Fix the Mounting Frame Note The mounting frame should be placed exactly as shown below for this step. The tamper plate should be at the low right of the first grid. Figure 4-36 Mounting Frame 5.
  • Page 45 Video Intercom Two-Wire Bundle User Manual Figure 4-37 Placement of Lines 6. Connect the cables. 1) Connect the lines and module-connecting line 1 to the corresponding interfaces of the main unit, then place the main unit into the upper grid. 2) Connect the other end of the module-connecting line 1 to the input interface of the sub module.
  • Page 46 Video Intercom Two-Wire Bundle User Manual Figure 4-39 Insert the Modules into the Frame 8. Use the hexagon wrench in the package to fix the cover onto the frame. Figure 4-40 Fix the Cover Three-Module Flush Mounting...
  • Page 47 Video Intercom Two-Wire Bundle User Manual Before You Start Figure 4-41 Gang Box Note The dimension of one-module gang box is: 338.8(W)×134(H)×56(D) mm. ● The dimensions above are for reference only. The actual size can be slightly ● different from the theoretical dimension. Steps 1.
  • Page 48 Video Intercom Two-Wire Bundle User Manual Figure 4-42 Cave the Installation Hole 2. Select a cable entry and remove the plastic sheet. 3. Mark the gang box screw holes on the wall. 1) Route the cables through the gang box hole. 2) Insert the gang box into the installation hole.
  • Page 49 Video Intercom Two-Wire Bundle User Manual Figure 4-44 Fix the Gang Box 6. Fill the gap between the gang box and wall with concrete. Remove the mounting ears with tool after concrete is dry. Figure 4-45 Remove the Mounting Ears 7.

  • Page 50: More-Than-Three Module Installation

    Video Intercom Two-Wire Bundle User Manual Figure 4-46 Connect Cables and Insert Modules Note Cable 1 refers to the cables pulled out from the wall that connected to the main unit. Cable 2 and Cable 3 refer to the module-connecting line in the accessory package.
  • Page 51 Video Intercom Two-Wire Bundle User Manual Before You Start Figure 4-48 Mounting Frame Note It takes two three-module mounting frames. The dimension of three-module ● mounting frame (W × H × D) is: 320.8 mm × 107 mm × 32.7 mm. The dimensions above are for reference only.
  • Page 52 Video Intercom Two-Wire Bundle User Manual Figure 4-49 Drill Screw Holes 4. Remove the stickers and insert the expansion sleeves into the screw holes. 5. Thread the module-connecting line (400 mm) and grounding line across the thread hole of both frames. Figure 4-50 Place the Grounding Line and Module-Connecting Line...
  • Page 53 Video Intercom Two-Wire Bundle User Manual Note There are 6 module-connecting lines in the package: 190 mm × 4 and 400 mm × ● Take the 400 mm module-connecting line for this step. ● The green-yellow line in the package is for grounding. ●...
  • Page 54 Video Intercom Two-Wire Bundle User Manual 8. Connect the cables. 1) Connect the cables from the wall and module-connecting line 1 to the corresponding interfaces of the main unit, then place the main unit into the upper grid. 2) Connect the other end of the module-connecting line 1 to the input interface of the sub module.
  • Page 55 Video Intercom Two-Wire Bundle User Manual 9. Insert the modules into the frame after wiring. The main unit must be placed in the top grid on the left. Figure 4-54 Insert the Modules 10. Pull the grounding line out and fixed its two end to the screw on the cover. Figure 4-55 Connect the Grounding Line to the Cover 11.
  • Page 56 Video Intercom Two-Wire Bundle User Manual Figure 4-56 Fix the Cover More-Than-Three Module Flush Mounting...
  • Page 57 Video Intercom Two-Wire Bundle User Manual Before You Start Figure 4-57 Gang Box Note It takes two three-module gang boxes. The dimension of the gang box is: 338.8 (W) × 134 (H) × 56 (D) mm. The dimension is for reference only.
  • Page 58 Video Intercom Two-Wire Bundle User Manual Steps 1. Drill the installation hole, and pull the cable out.The suggested dimension of installation hole is 321.8 (W) × 315 (H) × 45.5 (D) mm. The suggested length of cables left outside is 270 mm. Figure 4-58 Cave the Installation Hole 2.
  • Page 59 Video Intercom Two-Wire Bundle User Manual 4. Remove the plastic sheets on the side of the gang boxes (shown as 1 and 2) below: Figure 4-60 Remove the Plastic Sheets 5. Mark the gang box screw holes on the wall. 1) Route the cables through the gang box hole.
  • Page 60 Video Intercom Two-Wire Bundle User Manual 6. Drill 8 holes according to the marks on the wall, and insert the expansion sleeves into the screw holes. The suggested size of hole is 6 (diameter) × 45 (depth) mm. 7. Fix the gang boxes with 8 expansion bolts. Figure 4-62 Fix the Gang Boxes 8.
  • Page 61 Video Intercom Two-Wire Bundle User Manual 1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of the Main Unit, then place the Main Unit into the upper grid of the left gang box. 2) Connect the other end of Cable 2 to the input interface of Sub Module 1. Connect one end of Cable 3 to the output interface of Sub Module 1 and insert it into the middle grid of the left gang box.
  • Page 62 Video Intercom Two-Wire Bundle User Manual Note Cable 2,3,5 and 6 are the module-connecting lines (190 mm) in the package. ● Cable 4 is the module-connecting line (400 mm) in the package. ● Main unit must be put in the top grid. ●...

  • Page 63: Install Network Distributor

    Video Intercom Two-Wire Bundle User Manual Figure 4-67 Fix the Cover 4.3 Install Network Distributor Before You Start Make sure the device in the package is in good condition. ● Make sure all the related equipment is power-off during the installation. ●...

  • Page 64: Install Analog Distributor

    Video Intercom Two-Wire Bundle User Manual Figure 4-68 Wall Mounting 4.4 Install Analog Distributor It supports wall mounting. Before You Start Make sure the device in the package is in good condition. ● Make sure all the related equipment is power-off during the installation. ●...
  • Page 65 Video Intercom Two-Wire Bundle User Manual Figure 4-69 Drill Screw Holes Note The suggested size of the hole is 7.5 (diameter) × 25 (Depth) mm. 2. Fix the device to the wall with 2 screws. Figure 4-70 Fix the Device...

  • Page 66: Activation

    Video Intercom Two-Wire Bundle User Manual 5 Activation 5.1 Connect to Network The network distributor supports two ways to connect to network. 5.1.1 Connect to Wired Network You can connect the device to the network via connecting network cables. Steps 1.

  • Page 67: Activate Via Sadp

    Get the SADP software from the supplied disk or the official website http:// ● www.hikvision.com/ , and install the SADP according to the prompts. The device and the PC that runs the SADP tool should belong to the same subnet.

  • Page 68: Activate Device Via Web

    Video Intercom Two-Wire Bundle User Manual Steps 1. Run the SADP software and search the online devices. 2. Find and select your device in online device list. 3. Input new password (admin password) and confirm the password. Caution STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 69 Video Intercom Two-Wire Bundle User Manual Default parameters of the door station are as follows: Default IP Address: 192.0.0.65. ● Default Port No.: 8000. ● Default User Name: admin ● Steps 1. Power on the device, and connect the device to the network. 2.

  • Page 70: Remote Configuration Via Web

    Video Intercom Two-Wire Bundle User Manual 6 Remote Configuration via Web 6.1 Login and Logout 6.1.1 Log in the Web After you activate the device and get the IP address, you can access the device via web browser. Steps 1. Open the web browser and input the IP address of the device in the address bar and then press the Enter key to enter the login page.

  • Page 71: Device Management

    Video Intercom Two-Wire Bundle User Manual 6.3 Device Management You can manage the linked device on the page. Click Device Management to enter the settings page. Add Device Click Add to add the indoor station or sub door station. Enter the ●...

  • Page 72: System Settings

    Video Intercom Two-Wire Bundle User Manual 6.4.1 System Settings Follow the instructions below to configure the system settings, include System Settings, Maintenance, Security, and User Management, etc. Click Configuration → System to enter the settings page. Basic Information Click System Settings → Basic Information to enter the settings page. On the page, you can edit Device Name and Device No., and select System Type according to your needs.
  • Page 73 Video Intercom Two-Wire Bundle User Manual Note The upgrading process will last 1 to 10 minutes, do not power off during the upgrading. The device reboots automatically after upgrading. Security Service Click Security → Security Service to enter the settings page. Enable SSH: When the device needs to be debugged in remote, you can slide Enable SSH.

  • Page 74: Network Settings

    Video Intercom Two-Wire Bundle User Manual security system, changing the password monthly or weekly can better protect your product. 6.4.2 Network Settings TCP/IP Settings TCP/IP settings must be properly configured before you operate the device over network. The device supports IPv4. Steps 1.

  • Page 75: Intercom Settings

    Video Intercom Two-Wire Bundle User Manual Figure 6-1 SIP Settings 2. Check Enable VOIP Gateway. 3. Configure the SIP parameters. 4. Click Save to enable the settings. HTTP Listening Click Configuration → Network → Advanced → HTTP Listening to enter the settings page.
  • Page 76 Video Intercom Two-Wire Bundle User Manual Steps 1. Click Configuration → Intercom → Device No. to enter the settings page. 2. The Device Type is Decoder Station by default. 3. Edit the Communication No., Building No. and Unit No. 4. Click Save to enable settings. Session Settings You can set session to establish the communication between main station with indoor station, outerdoor station, door station or video intercom server.

  • Page 77: Cables

    Video Intercom Two-Wire Bundle User Manual A. Cables Cables and Wiring When there are multiple cores in one parallel line, only one pair of closed ● cores are allowed to transmit signal. It is not allowed to use multiple pair of cores in one cable to transmit signal.
  • Page 78 CH1 of the video/audio distributor. Up to 15 video/audio distributor can be cascaded. If more distributors are ● needed, you should cascade network switch supporting 1000Mbps. The whole 2-wire system can have up to 600 devices. Power supply must be certified by Hikvision. ●...

  • Page 79: Communication Matrix And Device Command

    B. Communication Matrix and Device Command Communication Matrix Scan the following QR code to get the device communication matrix. Note that the matrix contains all communication ports of Hikvision access control and video intercom devices. Figure B-1 QR Code of Communication Matrix Device Command Scan the following QR code to get the device common serial port commands.
  • Page 80 UD25519B...
