- Page 1 INSTRUCTION MANUAL Cordless Multi Tool DTM40 DTM50 Read before use.
-
Page 2: Specifications
The following show the symbols used for the equip- Uncertainty (K) : 3 dB (A) ment. Be sure that you understand their meaning before The noise level under working may exceed 80 dB (A). use. Work mode: Cutting with plunge cut saw blade Read instruction manual. Model DTM40 Sound pressure level (L ) : 82 dB (A) Sound power level (L ) : 93 dB (A) Wear safety glasses. Uncertainty (K) : 3 dB (A) Model DTM50... -
Page 3: Ec Declaration Of Conformity
Save all warnings and instruc- Uncertainty (K) : 1.5 m/s tions for future reference. The term "power tool" in the warnings refers to your Work mode: Cutting with plunge cut saw blade mains-operated (corded) power tool or battery-operated Model DTM40 (cordless) power tool. Vibration emission (a ) : 9.5 m/s Uncertainty (K) : 1.5 m/s Work area safety Model DTM50 Keep work area clean and well lit. - Page 4 When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
- Page 5 Battery tool use and care Always use safety glasses or goggles. Ordinary eye or sun glasses are NOT safety Recharge only with the charger specified by glasses. the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire Avoid cutting nails. Inspect workpiece for any when used with another battery pack.
- Page 6 CAUTION: Only use genuine Makita batteries. rules for the subject product. MISUSE or Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting failure to follow the safety rules stated in causing fires, personal injury and damage. It will this instruction manual may cause serious also void the Makita warranty for the Makita tool and personal injury.
-
Page 7: Functional Description
Battery protection system (Lithium- FUNCTIONAL ion battery with star marking) DESCRIPTION WARNING: • Always be sure that the tool is switched off and battery cartridge is removed before adjusting or checking function on the tool. Failure to switch off and remove the battery cartridge may result in serious personal injury from accidental start-up. Installing or removing battery cartridge ► 1 . -
Page 8: Overload Protection
Adjusting the orbital stroke rate Indicator lamps Remaining capacity Lighted Blinking 75% to 100% 50% to 75% 25% to 50% 0% to 25% Charge the battery. The battery may have ► 1 . Dial malfunctioned. The orbital stroke rate is adjustable. To change the orbital stroke rate, turn the dial between 1 and 6. The higher the number is, the higher the orbital stroke NOTE: Depending on the conditions of use and the rate is. Preset the dial to the number suitable for your... -
Page 9: Indication Lamp
Indication lamp ► 1 . Application tool installation bolt 2. Hex wrench 3. Tighten ► 1 . Indication lamp Put an application tool (optional accessory) on the tool flange so that the protrusions of the tool flange fit in the • When the remaining battery capacity gets low, the holes in the application tool and secure the application indication lamp blinks. tool by tightening the bolt firmly with the hex wrench. • When the remaining battery capacity gets much When using sanding application tool, mount the appli- lower, the tool stops during operation and the cation tool on the sanding pad so that it matches the indication lamp lights up about 10 seconds. -
Page 10: Operation
Hex wrench storage NOTE: • Forcing or excessive pressure on the tool may reduce efficiency. • Before cutting operation, it is recommended to preset the orbital stroke rate 4 - 6. Sanding CAUTION: • Do not reuse a sanding paper used for sanding metal to sand wood. • Do not use a worn sanding paper or sanding paper without grit. -
Page 11: Maintenance
• Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, carbon brush inspection and replacement, any other maintenance or adjustment should be performed by Makita Authorized Service Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES CAUTION: • These accessories or attachments are recom- mended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for... - Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885278E220 www.makita.com 20181122...
