- Page 1 INSTRUCTION MANUAL Cordless Oil-Pulse Driver DTS131 DTS141 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model DTS131 DTS141 Capacities Machine screw 4 mm - 8 mm 4 mm - 8 mm Standard bolt 5 mm - 8 mm 5 mm - 8 mm No load speed Impact mode (Hard) 0 - 3,000 min 0 - 3,200 min... -
Page 3: Ec Declaration Of Conformity
Work area safety WARNING: Wear ear protection. Keep work area clean and well lit. Cluttered or WARNING: dark areas invite accidents. The noise emission during actual use of the power tool can differ from the declared Do not operate power tools in explosive atmo- value(s) depending on the ways in which the spheres, such as in the presence of flammable tool is used especially what kind of workpiece is... - Page 4 Do not overreach. Keep proper footing and Keep cutting tools sharp and clean. Properly balance at all times. This enables better control maintained cutting tools with sharp cutting edges of the power tool in unexpected situations. are less likely to bind and are easier to control. Dress properly. Do not wear loose clothing or Use the power tool, accessories and tool bits jewellery.
- Page 5 MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious CAUTION: personal injury. Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that Important safety instructions for have been altered, may result in the battery bursting causing fires, personal injury and damage. It will battery cartridge also void the Makita warranty for the Makita tool and charger.
-
Page 6: Functional Description
Indicating the remaining battery FUNCTIONAL capacity DESCRIPTION Only for battery cartridges with the indicator CAUTION: • Always be sure that the tool is switched off and the battery cartridge is removed before adjust- ing or checking function on the tool. Installing or removing battery cartridge ► 1 . Indicator lamps 2. Check button Press the check button on the battery cartridge to indi- cate the remaining battery capacity. The indicator lamps light up for a few seconds. - Page 7 Switch action CAUTION: • Before inserting the battery cartridge into the tool, always check to see that the switch trigger actuates properly and returns to the "OFF" position when released. ► 1 . Button To turn on the lamp status, press the button for few seconds. To turn off the lamp status, press the but- for few seconds again. With the lamp status ON, pull the switch trigger to turn on the lamp. To turn off, release it. The lamp goes out approx- imately 10 seconds after releasing the switch trigger.
- Page 8 1. Changed in four steps 2. Hard 3. Medium 4. Soft 5. T mode 6. Button Maximum blows Impact force grade Application Work displayed on panel DTS131 DTS141 Hard Tightening in underwork 2,500 2,700 Tightening when force material / Tightening long...
-
Page 9: Overload Protection
Tool / battery protection system NOTE: • When all lamps on the switch panel go out, the tool is turned off to save the battery power. The The tool is equipped with a tool/battery protection sys- impact force grade can be checked by pulling tem. This system automatically cuts off power to the motor to extend tool and battery life. the switch trigger to the extent that the tool does The tool will automatically stop during operation if the not operate. tool or battery are placed under one of the following • While pulling the switch trigger, the impact force conditions. In some conditions, the indicator lights up. grade cannot be changed. - Page 10 For tool with shallow bit hole Procedure 2 In addition to the procedure(1) above, insert the bit- piece into the sleeve with its pointed end facing in. A=12 mm Use only these type of bit. Follow the procedure (1). B=9 mm (Note) Bit-piece is not necessary.
-
Page 11: Operation
OPERATION High tensile bolt (kgf cm) (204) (153) (102) (51) Fastening time (S) Hold the tool firmly and place the point of the driver bit ► 1 . Vent in the screw head. Apply forward pressure to the tool to the extent that the bit will not slip off the screw and turn CAUTION: the tool on to start operation. • Never obstruct the air vents on the side of the NOTE: tool for cooling down oil unit and motor during •... -
Page 12: Maintenance
Discoloration, deformation or cracks these accessories, ask your local Makita Service Center. may result. • Screw bits To maintain product SAFETY and RELIABILITY, repairs, • Socket bits any other maintenance or adjustment should be per- • Hook formed by Makita Authorized Service Centers, always • Plastic carrying case using Makita replacement parts. • Makita genuine battery and charger • Bit-piece • Battery protector • Tool hanger NOTE: • Some items in the list may be included in the tool package as standard accessories. They may differ from country to country.
