the Model t10116 auxiliary table replaces the
spindle sanding table included with the Model
g0563/g0564 oscillating edge sander, and
improves dust collection when workpieces are
sanded on the spindle drum or end of the sand-
ing belt.
Inventory
(Figure 1)
A. Auxiliary table ............................................ 1
B. table insert 4 ⁄ " (preinstalled) ................... 1
1
4
C. table insert 3 ⁄ " ......................................... 1
1
4
D. table insert 2
⁄ " ......................................... 1
1
4
E. table insert 1
⁄ " ......................................... 1
3
4
B
d
Figure 1. Model t10116.
If you need help with your new auxiliary table, call
our Tech Support at: (570) 546-9663.
Assembly
1. loosen the lock handle on the idler roller
bracket and slide the existing spindle sanding
table out.
WARNING: NO pORTION OF ThIS MANUAL MAY BE REpRODUCED IN ANY ShApE
OR FORM WIThOUT ThE WRITTEN AppROvAL OF GRIzzLY INDUSTRIAL, INC.
A
C
e
Copyright © August, 2008 By grizzly industriAl, inC.
#Bl11017 printed in tAiWAn
MODEL T10116
AUXILIARY TABLE FOR
MODEL G0563/G0564
INSTRUCTIONS
2.
determine whether you will sand the work-
piece on the end of the main sanding belt or
on one of the spindle drums.
—if you plan to sand the workpiece on the
end of the belt, leave the preinstalled 4
table insert installed in the auxiliary table,
and proceed to Step 3.
—if you plan to sand the workpiece on one
of the spindle drums, remove the phillips
head screws (see Figure 2) and the 4
insert. Measure the diameter of the spindle
drum installed on the sander. insert the
correct sized insert into the auxiliary table,
secure with the phillips head screws, then
proceed to Step 3.
Note: The 1
⁄ ", 2
3
4
only fit the spindle drum—they will not fit over
the main sanding belt and idler roller.
spindle
insert
phillips
head screw
lock
handle
Figure 2. Model t10116 installed.
⁄ ", and 3 ⁄ " table inserts
1 1
4 4
shaft
⁄ "
1
4
⁄ "
1
4
