ENROLLING THE EXPANDER

VII.
The NetworX control panels have the ability to automatically find and store in memory the presence of all keypads,
zone expanders, wireless receivers and any other module connected to the data terminal. (Refer to Compatibility
chart on the back of this manual). This allows these modules to be supervised by the control panel. To enroll the
modules enter the Program Mode of the control panel (refer to the installation manual for the specific control panel).
When the Program Mode is exited, it will automatically enroll the devices. The enrolling process takes about 12
seconds, during which time the "Service" LED will illuminate. User codes will not be accepted during the enrolling
process. Once a module is enrolled, if it is not detected by the control, the "Service" LED will illuminate.

DEFAULT ZONE CONFIGURATIONS

VIII.
Zones can be programmed to be one of thirty different zone configurations (zone types). Configurations # 17
through 20 can be used for wireless or hardwired zones using European double EOL configuration. The default
zone configurations are listed below. These zone configurations can be customized by programming locations 110
to 169.
All Fire Zones are pre-programmed for UL systems.
Zone Types 21-30 are applicable to the NX-8E control panels ONLY.
The expander zones will not follow the Fast Loop Response.
DATA
1 DAY ZONE - Instant when system is armed trouble zone when system is disarmed.
2 24-HOUR AUDIBLE - Creates an instant yelping siren alarm regardless of the armed state of the
panel.
3 ENTRY/EXIT DELAY 1 - A trip will start entry delay 1. The lack of a trip during exit delay will enable
the Automatic Bypass or Instant mode if so programmed.
4 FOLLOWER WITH AUTO-BYPASS DISABLED - This zone will be instant when the system is
armed and no entry or exit delays are being timed. It is delayed during entry and exit delay times.
This zone will not bypass in Stay Mode, nor automatically bypass even if enabled in Segment 1 /
Location 23.
5 INTERIOR FOLLOWER WITH AUTO- BYPASS ENABLED - This zone will be instant when the
system is armed and no entry or exit delay is being timed. It is delayed during entry and exit delay
times. This zone will bypass in Stay Mode, and automatically bypass if enabled in Segment 1 of
Location 23.
6 INSTANT - This zone creates an instant alarm whenever it is tripped and the Armed LED is on.
7 24-HOUR SILENT - Creates an instant silent alarm regardless of the armed state of the control
panel. It will not display on the keypad.
8 FIRE - This zone will illuminate the Fire LED and sound the temporal siren each time the zone is
shorted. It will also rapidly flash the Fire LED indicating a trouble if the zone is open.
9 ENTRY/EXIT DELAY 2 - A trip will start entry delay 2. The lack of a trip during exit delay will enable
the Automatic Bypass or Instant mode if so programmed.
10 24-HOUR SILENT SUPERVISED - Creates an instant silent alarm regardless of the armed state of
the control panel. It will display on the keypad.
11 KEYSWITCH ZONE - This zone type will arm and disarm the partition or partitions of the control
panel that resides in each time the zone is shorted. Keyswitch arming will report as user #99.
12 INTERIOR FOLLOWER WITH "CROSS ZONE" ENABLED - This zone will be Instant when the
system is armed and no entry or exit delay is being timed. It is delayed during entry and exit delay
times. If a "Cross Zone" is not being timed it will start a "Cross Zone" timer. If a "Cross Zone" is being
timed it will create an Instant alarm. This zone will bypass in Stay Mode and automatically bypass
when enabled in Segment 1 of Location 23.
13 INSTANT ENTRY GUARD - This zone creates an instant alarm whenever it is tripped and the Stay
LED is off. It will start an entry delay time 2 if it is tripped and the system is armed and the Stay LED
is on.
NX-216E Zone Expander
DESCRIPTION OF DEFAULT CONFIGURATION
7
