TABLE OF CONTENTS

I.
GENERAL DESCRIPTION ............................................................................................................................. 4
II.
ORDERING INFORMATION......................................................................................................................... 4
III.
BOARD INSTALLATION ............................................................................................................................... 4
IV.
WIRING ............................................................................................................................................................. 5
V.
TERMINAL DESCRIPTION........................................................................................................................... 5
VI.
DIP SWITCH SETTINGS (6 POSITION) ...................................................................................................... 6
VII.
ENROLLING THE EXPANDER .................................................................................................................... 7
VIII.
DEFAULT ZONE CONFIGURATIONS ........................................................................................................ 7
IX.
ZONE CONFIGURATION AND PARTITION ............................................................................................. 9
X.
PROGRAMMING WORKSHEETS.............................................................................................................. 10
XI.
SPECIFICATIONS ......................................................................................................................................... 16
UNDERWRITERS LABORATORIES INFORMATION
The NX-216E is UL approved and listed in accordance with the following UL Standards (US & Canada):
UL365
UL609
UL985
UL1023
UL1610
NX-216E Zone Expander
Police Station Connected Burglar Alarm Units & Systems
Local Burglar Alarm Units & Systems
Household Fire Warning Systems
Household Burglar Alarm Systems
Central Station Burglar Alarm Units
3
