Cisco Aironet 4-dBi Omnidirectional Antenna
(AIR-ANT5140V-R)
This document outlines the specifications, describes the AIR-ANT(AIR-ANT5140V-R) 4-dBi
omnidirectional antenna, and provides instructions for mounting it.
The antenna is designed specifically for use with pre-802.11n and 802.11n 3-antenna access points. The
antenna operates in the 5-GHz frequency range and is designed for use only in an indoor office
environment. The antenna assembly consists of three radiating elements, each fed with its own coaxial
cable.
The following information is provided in this document.
Technical Specifications, page 2
•
System Requirements, page 4
•
Safety Instructions, page 4
•
Installation Notes, page 4
•
•
Obtaining Documentation, Obtaining Support, and Security Guidelines, page 12
Americas Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
© 2007 Cisco Systems, Inc. All rights reserved.
Advertisement
Table of Contents
Related Manuals for Cisco Aironet AIR-ANT5140V-R
Summary of Contents for Cisco Aironet AIR-ANT5140V-R
- Page 1 Safety Instructions, page 4 • Installation Notes, page 4 • • Obtaining Documentation, Obtaining Support, and Security Guidelines, page 12 Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA © 2007 Cisco Systems, Inc. All rights reserved.
-
Page 2: Technical Specifications
< 1 in (< 2.5 cm) Cable length and type 36 in. (91.4 cm) Plenum rated, UV stable Operating temperature 32 F – 131 F (0 C – 55 C) Antenna A Elevation and Azimuth Pattern Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01... - Page 3 Technical Specifications Antenna C Elevation and Azimuth Pattern Antenna B Elevation and Azimuth Pattern Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01...
-
Page 4: System Requirements
System Requirements System Requirements This antenna is designed for indoor use with pre-802.11n and 802.11n Cisco Aironet access points. Safety Instructions Follow these safety instructions when installing your antenna. Plan your installation procedure carefully and completely before you begin. •... -
Page 5: Choosing A Mounting Location
Mounting Hardware Kit Contents The antenna ships with a hardware mounting kit containing the following items: Two recessed ceiling T-rail spacers • • Two channel ceiling rail adapters Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01... -
Page 6: Tools And Equipment Required
The antenna is shipped ready to install on a standard dropped ceiling T-rail. No adapters or spacers are necessary. Figure 1 shows the antenna installed on a standard dropped ceiling T-rail. Figure 1 Antenna Installed on a Standard Dropped Ceiling T-Rail Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01... - Page 7 Note These marks indicate the center points of the spacers and must be 10 3/16 in. (24.8 cm) apart. Step 3 In the mounting kit, locate two recessed dropped ceiling spacers. Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01...
- Page 8 These adapters attach to the channel ceiling T-rail and must be disassembled before you can attach them. Figure 3 shows the antenna installed on a channel ceiling T-rail using the supplied channel T-rail spacers. Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01...
- Page 9 These marks indicate the center points of the adapters and must be 10 3/16 in. (24.8 cm) apart. Note In the mounting kit, locate two recessed channel ceiling adapters. Step 3 Step 4 Disassemble each adapter by pushing on its tabs using your thumb and forefinger. Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01...
- Page 10 Erico 512A or equivalent T-bar box hanger. Figure 4 shows a typical dropped ceiling bridge assembly and Figure 5 shows the antenna installed on a dropped ceiling bridge assembly. Figure 4 Typical Dropped Ceiling Bridge Assembly Cisco Aironet 4-dBi Omnidirectional Antenna (AIR-ANT5140V-R) 78-17605-01...
-
Page 11: Suggested Cable
Replace the ceiling tiles. Step 15 Suggested Cable Cisco recommends a high-quality, low-loss cable for use with the antenna. Note Coaxial cable loses efficiency as the frequency increases, resulting in signal loss. The cable should be kept as short as possible because cable length also determines the amount of signal loss (the longer the run, the greater the loss). -
Page 12: Obtaining Documentation, Obtaining Support, And Security Guidelines
