Grizzly G0863 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Grizzly Growler creates a cyclone of incom-
ing air that separates heavy wood chips and large
dust particles, increasing the performance of your
single-stage dust collector, and resulting in less
suction loss from dirty or clogged filters.
Inventory
Description
A. Collection Drum .......................................... 1
B. Cyclone Funnel w/Band Clamp .................. 1
C. Intake Barrel ............................................... 1
D. Collection Drum Lid ................................... 1
E. Vacuum Hose 1
1
F. Inlet Adapter 6" x 4" x 2 .............................. 1
G. Vacuum Ring .............................................. 1
H. Universal Reducer ...................................... 1
I.
Intake Adapter 7" x 6" ................................ 1
J.
Phillips Head Screws M4-.7 x 8 (Latches) .. 8
K. Flange Bolts
⁄ " -20 x
1
4
L. Casters, 2" Swivel Ball .............................. 4
M. Lock Nuts M4-.7 (Latches) ......................... 8
N. Flange Nuts
⁄ " -20 (Funnel) ....................... 6
1
4
O. Collection Drum Latches ............................ 2
P. Acorn Nuts ⁄ " -20 (Handle) ........................ 2
1
4
Q. Flange Screws #10-24 x
—Intake Adapter ........................................ 1
—Inlet Adapter ........................................... 1
R. Phillips Hd. Screws
S. Open-End Wrench 10/12mm ...................... 1
T.
Handle ........................................................ 1
U. Hose Clamps 1
⁄
1
V.
Plastic Bag 30" X 41" (not shown) .............. 1
Specifications
Recommended Horsepower Range ..... 1.5–3 HP
Airflow Range ............................. 750–2300 CFM
Outlet Size .................................................... 7 in.
Inlet Size ....................................................... 6 in.
Max. Material Collection Capacity ............20 Gal.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ " x 67" ............................ 1
2
⁄ " (Funnel) .............. 6
1
2
⁄ "
3
8
⁄ " -20 x ⁄ " (Handle) ... 2
1 5
4 8
" ...................................... 2
2
COPYRIGHT © JANUARY, 2019 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 10/18) #MN20050 PRINTED IN TAIWAN
MODEL G0863
GRIZZLY GROWLER
CYCLONE SEPARATOR
A
Qty
F
G
Figure 1. Inventory—components.
