  • Page 1 PS254DB Original instructions...
  • Page 2 mportant! It is essential that you read the instructions in this manual before assembling, operating and maintaining the product. Subject to technical modifications.
  • Page 3 Ø 254 mm Ø 30 mm 48 HW 2.2 mm 7000 max. “D” Handle Switch trigger Switch lock off Lower blade guard Throat plates Sliding fence “No hands zone” label “No hands zone” boundary line Table lock button 10. Mitre detent bypass button 11.
  • Page 4 Fig. 1 Fig. 3 1 - Mounting holes 2 - Mounting surface 1 - Depth control knob 3 - Depth stop 3 - Base 2 - Lock nut 4 - Head lock pin Fig. 4 1 - “D” handle 2 - Head lock pin Fig.
  • Page 5 Fig. 7 Fig. 6 1 - Adjustable throat plate Fig. 8 To loosen Ø 254 mm 48 HW 2.2 mm Ø 30 mm 7000 max. To tighten 1 - Work clamp shaft 2 - Work clamp 3 - Work clamp hole Fig.
  • Page 6 Fig. 11 Fig. 10 Underside of mitre lock lever 1 - Mitre lock shoe 2 - Mitre lock screw 1 - Mitre lock nut 3 - Saw base 2 - Mitre lock screw 4 - Mitre lock nut 3 - Mitre lock lever Fig.
  • Page 7 Fig. 15 Fig. 13 1 - Handle 1 - Mitre scale 2 - Detent disengaged 2 - Scale indicator 3 - Detent engaged 4 - Bevel detent lever 5 - Bevel lock knob Fig. 16 6 - To tighten 7 - To loosen Fig.

  • Page 8: Cross Cut

    Fig. 19 Fig. 17 1 - Screws 2 - Bevel lock dust cover 3 - Bevel lock knob 4 - Bevel detent lever Fig. 18 Back of bevel lock bracket 1 - LED switch 2 - Shadow of blade teeth projected onto workpiece Fig.

  • Page 9: Mitre Cut

    Fig. 24 Fig. 21 EXTENDED MITRE CUT MITRE CUT Fig. 25 BEVEL DETENT LEVER 1 - Work clamp Fig. 22 1 - Handle 5 - Bevel lock knob 2 - Detent disengaged 6 - To tighten 1 - Sliding fence 3 - Detent engaged 7 - To loosen 2 - Rotating extension table...

  • Page 10: Slide Cut

    Fig. 30 Fig. 27 45º x 45º COMPOUND MITRE CUT 1 - Compound mitre cut Fig. 28 SLIDE CUT Fig. 31 1 - Slide saw arm forward 2 - Push down 3 - Push back Fig. 29 1 - Long workpiece 2 - Workpiece supports Fig.
  • Page 11 Fig. 33 Fig. 36 52° 45° Ceiling Ceiling 38° 45° Wall Wall Top edge against fence: 1 - Depth control knob 2 - Lock nut 3 - Depth stop Fig. 34 1 - Sliding fence 2 - Mitre table Fig. 37 1 - Work clamp 2 - C clamp 3 - Workpiece...
  • Page 12 Fig. 40 Fig. 38 1 - Hole “A” Fig. 41 2 - Crown stop 3 - Hole “B” 4 - Crown stop lock knob Fig. 39 RIGHT Fig. 42 1 - Slide lock knob 2 - Crown and baseboard setting lever 3 - Crown stop WRONG 4 - Baseboard lock groove...

  • Page 13: Technical Data

    TECHNICAL DATA SLIDING COMPOUND MITRE SAW PS254DB Rated input 220V - 240V ~ 50 Hz Rated current 7.5 A Rated power 1800 W Weight 24.6 kg Maximum cutting depth 89 mm No-load speed 4800 min Saw blade diameter x hole diameter...

  • Page 14: Work Area Safety

    GENERAL POWER TOOL SAFETY WARNINGS Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A WARNING! Read all safety warnings, instructions, illustrations careless action can cause severe injury within a fraction of a second. and specifications provided with this power tool.

  • Page 15: Additional Safety Warnings

    handed” i.e. holding the workpiece to the right of the saw blade with deformation and vibration. your left hand or vice versa is very dangerous. Do not use the product without the guards in position. Keep guards in Do not reach behind the fence with either hand closer than 100 good working order and properly maintained.

  • Page 16: Specified Conditions Of Use

    may fall from the cutting area. minimize voltage fluctuations. Contact your electric power supplier for further clarification. Disconnect the product from the mains supply or remove battery pack before carrying out any maintenance or cleaning the product. SPECIFIED CONDITIONS OF USE Only connect to the mains supply when the product is switched off.
  • Page 17 When used, the depth guide limits the downward travel of the blade WARNING! The saw arm is spring loaded. Hold the handle down when cutting dadoes and other non-through cuts. to prevent saw arm from snapping up when cutting the tie-wrap. Failure to do so could result in possible serious injury.

  • Page 18: Installing The Work Clamp

    NOTE: The blade bolt has left hand threads. Turn blade bolt needed. clockwise to loosen. ADJUSTING THE MITRE LOCK Remove the outer blade washer. See figure 9 - 10. NOTE: The inner blade washer is integrated into the spindle and cannot be removed.

  • Page 19: Operation

    Pull the saw arm all the way down and lock in transport position. TO ADJUST THE BEVEL See figures 17 - 18. Loosen the bevel lock knob and disengage the bevel detent lever. Set the saw at the 0º bevel angle, engage the bevel detent lever, Remove the bevel lock dust cover.
  • Page 20 any cutting angle while the saw is running and the blade is rotating. the workpiece from the mitre table. Any slip can result in contact with the blade causing serious personal TO MAKE EXTENDED MITRE CUTS injury. See figure 22 - 24. WARNING! Do not try to cut narrow pieces using the sliding feature.

  • Page 21: To Slide Cut

    Loosen the bevel lock knob. NOTE: When performing 45° bevel compound cut, the maximum mitre angle is 45°. When performing 70° mitre cut, only 0° bevel NOTE: Firmly grasp the “D” handle while loosening the bevel lock angle is allowed. knob to prevent the saw head from shifting unexpectedly.

  • Page 22: Making An Auxiliary Fence

    Turn the LED switch on to project the blade shadow onto the CLAMPING WIDE WORKPIECES workpiece. See figure 32. Loosen the slide lock knob by turning the knob counterclockwise. When cutting wide workpieces, such as a nominal 50 mm. x 50 mm, Grasp the workpiece firmly with one hand and secure it against boards should be clamped securely.
  • Page 23 When cutting crown molding by this method the bevel angle should (Left) Left side of outside corner be set at 33.9°. The mitre angle should be set at 31.6° either right or 1. Bottom edge of molding against left, depending on the desired cut for the application. See the chart fence below for correct angle settings and correct positioning of crown 2.

  • Page 24: Cutting Base Molding

    AEG service centre. Place and secure the base molding flat against the fence using Use only AEG accessories and spare parts. Should components need the work clamp and hold the base molding securely. to be replaced which have not been described, please contact one of Before turning on the saw, perform a dry run of the cutting our AEG service agents (see our list of guarantee/service addresses).
  • Page 25 Do not expose to rain or use in damp locations. Keep hands away from the cutting area and sharp blade. CAUTION! Do not stare at the operating lamp. Blade rotation direction Blade teeth 48 HW Width of cut 2.2 mm Arbor hole and blade size For cutting wood only Adjust the position of sliding fence...
  • Page 28 Techtronic Industries GmbH Max-Eyth-Straße 10 D-71364 Winnenden Germany...
