11 - 34
9. With the base unit attached to the wall, hook the two bottom
tabs in the tab slots on the Multiline Terminal base.
Base Unit
Wall
Tab
Figure 11-43 Attaching the Bottom Tabs of the Multiline
10. Push up on the Terminal and lock the top base unit tabs in the
top slots on the terminal.
of the Multiline Terminal to the Base Plate
Multiline Terminal is attached.
Tab Slots
Tabs
Wall
Figure 11-44
Installing Electra Elite Optional Terminal Equipment
Tab Slots
Terminal to the Base Plate
Figure 11-44 Attaching the Top Tabs
Wall Mount Unit
Attaching the Top Tabs of the Multiline
Terminal to the Base Plate
Electra Elite IPK II
Multiline
Terminal
Line Cord
shows how the
Multiline
Terminal
Line Cord
