Makita DCL280F Instruction Manual

Cordless cleaner
Hide thumbs Also See for DCL280F:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
Cordless Cleaner
DCL280F
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita DCL280F

Summary of Contents for Makita DCL280F

  • Page 1 INSTRUCTION MANUAL Cordless Cleaner DCL280F Read before use.

  • Page 2: Specifications

    Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. SPECIFICATIONS Model: DCL280F Capacity 750 mL Continuous use (with battery BL1830B) Approx. 20 min Overall length...
  • Page 3 Use only as described in this manual. Use only — Flammable materials such as gasoline, manufacturer's recommended attachments. thinner, benzine, kerosene or paint Do not use with damaged battery. If appliance — Explosive materials like nitroglycerin is not working as it should, has been dropped, —...

  • Page 4: Functional Description

    Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. Tips for maintaining maximum battery life...

  • Page 5: Battery Protection System

    Indicator lamps Remaining CAUTION: Always install the battery cartridge capacity fully until the red indicator cannot be seen. If not, it may accidentally fall out of the tool, causing injury to Lighted Blinking you or someone around you. Charge the CAUTION: Do not install the battery cartridge battery. forcibly. If the cartridge does not slide in easily, it is The battery not being inserted correctly.
  • Page 6 Prefilter or high performance filter Lighting up the lamp and HEPA filter CAUTION: Do not look in the light or see the source of light directly. To turn on the lamp, pull the switch trigger. During the tool actuating, the lamp turns on. Release the switch to turn off the lamp.
  • Page 7 In order to drop dust sticking on the filter in the capsule, Twist high performance filter in direction of arrow to tap the capsule 4 or 5 times with your hand. unfasten securing lip from cleaner unit and then pull off the filter. ► 1 . Capsule 2. Suction inlet ► 1 . Securing lip Point suction inlet downwards, turn capsule in direction of arrow in diagram, and disconnect capsule slowly and NOTE: When using the prefilter, also follow the pro- straight.
  • Page 8 Installing or removing stay / HEPA NOTICE: Always be sure to check that high perfor- mance filter is loaded correctly prior to using cleaner. filter If they are not loaded correctly, dust will get into the motor housing, and cause motor failure. Optional accessory If the problem as described later occurs, high per- formance filter is not loaded correctly. Reload them For the stay and sponge filter correctly to rectify problem.

  • Page 9: Operation

    NOTE: When installing the extension wand, be sure to align the release button with the hook on the extension wand. If they are not aligned, the wand will not be locked and may come off from the cleaner. NOTE: When installing the extension wand with- out lock function (optional accessory), twist and insert it to the suction inlet of the cleaner in direc- tion of the arrow.
  • Page 10 Corner nozzle Fit on the corner nozzle for cleaning corners and crev- ices of a car or furniture. Cleaning (Suction) Nozzle ► 1 . Corner nozzle 2. Cleaner body Attach the nozzle to clean off tables, desks, furniture, etc. The nozzle slips on easily. Corner nozzle + Extension wand (Straight pipe) In tight quarters where the cleaner itself cannot...

  • Page 11: Maintenance

    To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. After use NOTICE: Putting the cleaner against the wall...

  • Page 12: Hepa Filter

    HEPA filter Optional accessory Do not rub or scratch the HEPA filter NOTICE: with hard objects such as a brush and a paddle. Clogged HEPA filter cause poor suction performance. Clean out the filter from time to time. Occasionally wash the HEPA filter in water, rinse and dry thoroughly in the shade before use. Never wash the filter in a washing machine. Sponge filter ► 1 . Sponge filter 2. Bottom edge of pillar When the sponge filter becomes dirty, clean it as follows.

  • Page 13: Troubleshooting

    Do not attempt to repair the cleaner by yourself. OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 16 Jan-Baptist Vinkstraat 2, Makita Europe N.V. 3070 Kortenberg, Belgium 3-11-8, Sumiyoshi-cho, Makita Corporation Anjo, Aichi 446-8502 Japan 885705-227 www.makita.com 20190128...
