MONOGRAM - ZIP360NHA, ZIPP360NHASS, ZIPS360NHASS
Electrical Shock Hazard
WARNING
Death or serious injury can result from failure to
follow these instructions.
•
• Disconnect power before servicing this product.
• Reconnect all grounding devices after service.
• Replace all parts and panels before operating.
CAUTION
To avoid personal injury when servicing the
condensing unit, stand on a ladder which will give
enough support to allow removal of the top panel
and safely allow access to service the unit.
ELECTRICAL SPECIFICATIONS
Max Defrost Control
w/No Door Openings
Evap Defrost Thermodisc
Electrical Rating: 115V AC 60 Hz
Maximum Current Leakage
Maximum Ground Path Resistance
NO LOAD PERFORMANCE
CONTROL POSITION 37-0°F and
AMBIENT TEMPERATURE OF
Fresh Food, °F
Frozen Food, °F
Percent Running Time
REFRIGERATION DIAGNOSIS
To access the low pressure side of the system,
install a WJ56X61 valve only on the process tube
extending from the compressor case.
To Cabinet
Wiring
Orange
Red
Communication
Signal White
Inverter
Ground

Technical Data

96 hrs @ 40 min
140-110°F
7.0 amp
0.75 mA
0.14 ohms
65°F 90°F
36-38 36-38
(-1) - (1) (-1) - (1)
36-44 61-69
Black
Green/Yellow
Black
Red
White
Compressor
REFRIGERATION SYSTEM
Compressor
Minimum Compressor Capacity
Vacuum
Minimum Equalized Pressure
@ 70°F
@ 90°F
R134a Refrig. Chg
Suction Line Suction Line
Muffler
Process
Process
Tube
Tube
Inverter* Inverter*
Compressor Compressor
Condenser Loop Condenser
Loop
*Approximate location of * Approximate
inverter
location of inverter
– 9 –
833 BTU/hr
22 inches
62/68 PSIG
87/91 PSIG
9.25 oz
Condenser
Condenser
Dryer
Dryer
Discharge
Discharge
Capillary
Capillary
Suction Tube
Suction Tube
Evaporator
Evaporator
