5 FINAL OPERATIONS

After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the racks.
Following adjustment to a gas other than the preset one, replace the gas setting label fixed to the
appliance with the one corresponding to the new gas. The label is inserted inside the pack together
with the nozzles.
5.1 Regulation of the hob burner minimum for natural gas
Light the burner and turn it to the minimum position
gas tap knob and turn the adjustment screw to the top left of the tap
rod until the correct minimum flame is achieved.
Refit the knob and verify that the burner flame is stable (when
turning the knob rapidly from the maximum to the minimum position
the flame must not go out). Repeat the operation on all the gas taps.
For valved models, keep the knob pressed in at the minimum level for a few seconds to keep the
flame lit and to activate the safety device.
5.2 Adjusting the hob burner minimum for LPG gas
In order to adjust the minimum setting with LPG gas, the screw at the side of the tap rod must be
tightened clockwise all the way. This adjustment is not necessary for the models equipped with a gas
cylinder compartment.
When the adjustment is completed, restore the sealing of the by-passes with paint or another
material.
5.3 Adjustment of the oven burner minimum
The oven thermostat is equipped with a screw for regulating the minimum, which can be seen by
removing the thermostat knob.
When changing the type of supplied gas, the minimum must be
adjusted as follows:
•
Light the oven burner and keep it at the maximum for 10/15
minutes with the door closed and without the shelf; after this
period, move the knob to the minimum temperature, slide off the
knob and insert a straight edge screwdriver to make the
adjustment.
•
If using LPG gas the adjustment screw must be tightened
clockwise to the very end.
•
If using city gas or natural gas, adjust the screw so that when
the thermostat knob is turned from the maximum to the
minimum position, the flame remains steady and constant.
When the adjustment is completed, restore the seal on the
screws using paint or equivalent materials. When closing the
oven door, make sure the burner remains lit at the minimum.
14
Instructions for the installer
