Configuring QoS
Configuring QoS
Command
4. class {class-map-name | class-default}
5. police aggregate aggregate-policer-name
6. exit
7. exit
8. interface interface-id
9. service-policy input policy-map-name
10. end
11. show policer aggregate
[aggregate-policer-name]
12. copy running-config startup-config
After you have created an aggregate policer, you attach it to an ingress port. See
page 609.
To remove the specified aggregate policer from a policy map, use the no police aggregate aggregate-policer-name
policy map configuration mode. To delete an aggregate policer and its parameters, use the no policer aggregate
aggregate-policer-name global configuration command.
This example shows how to create an aggregate policer and attach it to multiple classes within a policy map. The policy
map is attached to an ingress port.
Switch(config)# policer aggregate example 10900000 80000 conform-action transmit exceed-action drop
Switch(config)# class-map testclass1
Switch(config-cmap)# match access-group 1
Switch(config-cmap)# exit
Switch(config)# class-map testclass2
Switch(config-cmap)# match access-group 2
Switch(config-cmap)# exit
Switch(config)# policy-map testexample
Switch(config-pmap)# class testclass
Switch(config-pmap-c)# police aggregate example
Switch(config-pmap-c)# exit
Switch(config-pmap)# class testclass2
Switch(config-pmap-c)# police aggregate example
Switch(config-pmap-c)# exit
Switch(config-pmap)# exit
Switch(config)# interface fastethernet0/1
Switch(config-if)# service-policy input testexample
Switch(config-if)# exit
This example shows how to create a 2-rate, 3-color aggregate policer and attach it to multiple classes within a policy
map. The policy map is attached to an ingress port.
Switch(config)# policer aggregate example cir 10900000 pir 80000000 conform-action transmit
exceed-action drop violate-action drop
Switch(config)# class-map testclass1
Switch(config-cmap)# match access-group 1
Purpose
Enter a class-map name or class-default to match all unclassified
packets, and enter policy-map class configuration mode.
If you enter a class-map name, you must have already created the
class map by using the class-map global configuration command.
Apply an aggregate policer to multiple classes in the same policy
map. For aggregate-policer-name, enter the name specified in
Step 2.
Return to policy-map configuration mode.
Return to global configuration mode.
Enter interface configuration mode for the interface to which you
want to attach the policy.
Attach the policy map (created in Step 3) to the ingress interface.
Return to privileged EXEC mode.
Verify your entries.
(Optional) Save your entries in the configuration file.
621
Attaching a Traffic Policy to an Interface,
