ViewSonic NMP-302w Quick Start Manual

1

Box Contents

2
Mounting and Installation
Attach the wireless antenna as shown in left, screw antenna clockwise onto the post.
[VESA Mount] Put the VESA mount plate on the bottom of the player, with the screw holes
aligned. Make sure the countersunk holes are facing up, so when the screw goes in, the
screw head is level with the surface.
[Attach to HDMI port] Simply plug the player into the
HDMI port of the monitor as shown in left.
[Attach on the back of the monitor] Separate the
Velcro pads and stick one of them to the bottom of player.
Stick the other Velcro pad onto the back of monitor, and
then attach the player to it. Use HDMI extension cord to
connect player and the monitor.
NMP-302w
Network Media Player

Quick Start Guide
