ViewSonic Moderro NMP012 User Manual

Network media player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Moderro NMP012
User Guide

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic Moderro NMP012

Summary of Contents for ViewSonic Moderro NMP012

  • Page 1 Moderro NMP012 User Guide...
  • Page 2 Thank you for choosing ViewSonic As a world leading provider of visual solutions, ViewSonic is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic product you have chosen will serve you well.

  • Page 3: Table Of Contents

    Contents 1. Introduction 1.1 Scope ..................1 1.2 Terminology ................1 1.3 Overview of Moderro VideoWall Solution ........1 1.4 Workflow ..................3 2. Setting Up the Video Wall 2.1 Connecting the Hardware ............4 2.2 Downloading, Installing and Launching the VideoWall Application on Windows ............
  • Page 4 Configuring Video Wall 4.1 Identify All Devices in Video Wall ..........20 4.2 Reboot All Devices in Video Wall ..........20 4.3 Delete Video Wall ..............21 4.4 Upgrade All Devices in the Wall at Once ......... 21 Video Wall Composition 5.1 Change the Measurement Units ..........
  • Page 5 10.1 Moving Video Wall to Cloud Portal .......... 45 10.2 Monitoring from Cloud ............. 45 10.3 Controlling from Cloud ............. 45 11 Device and Video Wall Status 12 Preferences 13 Upgrading VideoWall Manager 14. Other Information Customer Support ................50...

  • Page 6: Introduction

    1. Introduction This chapter explains the scope of the user guide and provides an overview of the Moderro VideoWall solution. 1.1 Scope The document describes how to install, configure and operate Moderro VideoWall Manager 2.0.24 with the Moderro Xpack Media Player and covers the basics of VideoWall Management Service on the cloud.
  • Page 7 Highly-Efficient Cloud Based Service Xpack Media Players and video walls can be monitored and managed with our cloud-based service from a computer, anywhere, at any time. You can see the content being played on each video wall by checking the screenshots sent from each player.

  • Page 8: Workflow

    1.4 Workflow Here is the workflow that describes the most common steps you would take to play video on your video wall. Video File - If the video stream is not compatible, the VideoWall Manager will split and separately re-encode streams, and then transfer the cropped portions of the video to each device.

  • Page 9: Setting Up The Video Wall

    2. Setting Up the Video Wall This chapter explains how to set up the equipment and start the video wall application. 2.1 Connecting the Hardware Refer to the Quick User Guide for the Moderro Xpack Media Player for easy hardware installation instructions. 2.2 Downloading, Installing and Launching the VideoWall Application on Windows Refer to the Quick User Guide for the Moderro Xpack Media Player for easy...

  • Page 10: Log In And Download The Videowall Application From The Cloud

    4. Click Sign Up. 5. A verification email will be sent to your email address. 6. Click the link in the email to activate your account. 2.2.2 Log in and Download the VideoWall Application from the Cloud You must first login to download the VideoWall Manager. 1.

  • Page 11: Install And Launch The Videowall Application

    2.2.3 Install and launch the VideoWall Application 1. Double click on the saved *.exe file to start the installation process. 2. When Open File – Security Warning appears, click the Run button to run the software. 3. When the warning Do you want to allow this app from an unknown publisher to make changes to your device pops up, click Yes.

  • Page 12: Creating Video Wall And Adding Devices

    2.3 Creating Video Wall and Adding Devices 1. Click New VideoWall button on the bottom of the Walls and Devices pane. 2. Enter the name of the wall. 3. Click Add. 4. Add Devices to Wall window appears. If there are no unmanaged devices in the application: 1.

  • Page 13: Discovering And Adding Device

    2.4 Discovering and Adding Device Devices can be discovered and added to the application first, and then add them to the videowall later. 1. Click Discover Devices button on the top of the Walls and Devices pane to discover all devices in the same network. The grayed-out devices are the devices managed by the cloud and can’t be added.

  • Page 14: Adding Device Manually

    2.5 Adding Device Manually 1. Click Discover Devices button to discover all devices in the same network. 2. Click Add Device Manually. 3. Enter IP address and give a name to the device. 4. Click Add. 5. Added device appears under Walls and Devices. 6.

  • Page 15: Configuring Device

    3. Configuring Device This chapter explains how to configure the Xpack Media Player settings. The area surrounded by a red box is called the Walls and Devices pane. 3.1 Identify Device 1. Select the device from the Walls and Devices pane. 2.

  • Page 16: Rename Device

    3.2 Rename Device 1. To rename the device, select the device from the Walls and Devices pane. 2. Click Rename button in the General tab. 3. Enter a new device name and click OK. Note: The name of the device should not exceed 30 characters and only allows alphanumeric characters and spaces.

  • Page 17: Unregister Device

    3.4 Unregister Device When the device in the video wall is unregistered, any active playback on the device will be stopped. When a device that’s managed by the Cloud is unregistered, any active playback on the device will be stopped and the device’s cloud-enable property becomes false.

  • Page 18: Manage Network And Time

    3.7 Manage Network and Time Since the device doesn’t have a real-time clock that keeps track of the current time, it needs to get current time from an external source. The Network Time Protocol (NTP) is used to synchronize the time of a device to NTP server time.

  • Page 19: Ntp (Network Time Protocol)

    3.7.1 NTP (Network Time Protocol) Enable NTP: When NTP is enabled, the device will get time from the NTP server. Every 5 minutes, the device synchronizes with the server. When a change in the configuration is made, it requires a reboot to take effect. 1.

  • Page 20: Ptp (Precision Time Protocol)

    3.7.2 PTP (Precision Time Protocol) After a configuration change, reboot the player to take effect. 1. Select the device from the Walls and Devices pane. 2. Click the Network tab. 3. Click on the PTP drop down list and select the mode. PTP Master: Device will act as PTP master.

  • Page 21: Av Output

    3.8 AV Output 3.8.1 Brightness, Contrast, Saturation The brightness, contrast, and saturation of the video output are configurable. By default, brightness is 0%, contrast and saturation is 100%. 1. Select the device from the Walls and Devices pane. 2. Click the Output tab. 3.

  • Page 22: Manage Display

    3.9 Manage Display...

  • Page 23: Hdmi Connection

    3.9.4 RS-232 When the display connects to the device by RS-232 communication, the display can be controlled with RS-232 commands from the device. Only ViewSonic CDX 4652 is supported at this time. A USB to Serial adapter is required to use this feature. Plug the USB connector into...

  • Page 24: Upgrade Device Individually

    3.10 Upgrade Device Individually Follow the procedure below to upgrade a device individually. 1. Select the device from the Walls and Devices pane. 2. Click the Upgrade tab. 3. Click Select Firmware. It will list all available firmware. 4. Select one from the list and click OK. A confirmation dialog appears. 5.

  • Page 25: Configuring Video Wall

    4 Configuring Video Wall This chapter explains how to configure the video wall. 4.1 Identify All Devices in Video Wall 1. Select the wall from the Walls and Devices pane. 2. Click Identify from the Wall Control pane to learn the following information about the devices which will be displayed on each screen.

  • Page 26: Delete Video Wall

    4.3 Delete Video Wall When a video wall is deleted, wall composition will be lost and any active playback will be stopped. Devices in the video wall will remain listed in the Walls and Devices pane as unassigned devices. When a video wall that’s being managed by the Cloud is deleted, the video wall will be removed from both Cloud and VideoWall Manager.

  • Page 27: Video Wall Composition

    5 Video Wall Composition This chapter explains how to create a video wall composition. 5.1 Change the Measurement Units By default, the VideoWall Manager uses inches as its unit of measurement used in composition and display profiles. You can change the measurement units to centimeters.

  • Page 28: Grid Layout Mode

    5.3 Grid Layout Mode The grid Layout Mode allows users to configure the video wall in a traditional grid or matrix pattern using identical displays with uniform spacing. This mode allows users to adjust the video wall size (number and size of displays), device assignment, bezels of display, spacing between displays and video wall rotation.
  • Page 29 Use the Show Device Positions button to display the position names (e.g. A0, A1, B0, etc) on the physical displays. There are 2 ways to configure display settings, custom settings or defined display profiles. Click the drop-down list of Display Profile option and then select custom or defined profile.
  • Page 30 Bezels –Specifies the distance between the visible portion and the outer edge of the display. Horizontal and vertical spacing - Specifies the space between screens. Rotation – The video wall will be rotated to the given angle.

  • Page 31: Artistic Layout Mode

    5.4 Artistic Layout Mode Artistic layout mode allows users to configure the video wall in free layout and create more visually appealing arrangements of the displays. Artistic mode allows you to: • Use a mix of different displays. Users can mix and match displays of different brand, sizes and aspect ratio.
  • Page 32 Canvas size and position get dynamically adjusted when the device is moved or the size/angle of display is changed, if the Auto-resize Canvas option is enabled. The canvas size/position/angle can also be manually adjusted by disabling the Auto- resize Canvas option and changing the size/position/angle parameters. Use the Show Device Positions button to display the device names on the physical displays.
  • Page 33 Options in the Composition Work Area Zoom – Specifies zoom level. Auto-resize Canvas – When checked, canvas size and position automatically get optimized when the display position, size, or angle is changed. Enable Docking – When checked, the display object will snap to the nearest intersection in the grid (if the grid is visible) or snap to another display object.

  • Page 34: Selecting And Configuring Content

    6 Selecting and Configuring Content This chapter explains how to locate and add video and still image files as the source contents. 6.1 Video File This section describes how to add a video file, such as mp4, mkv, and ts, to the content. Audio only files, such as mp2, mp3, and aac can also be added. 1.

  • Page 35: Slideshow

    6.2 Slideshow This section describes how to create a video slideshow from still images, such as jpeg, png, and bmp. Follow these steps to create a video slideshow. 1. Select the wall from the Walls and Devices pane. 2. Click the Content tab. 3.

  • Page 36: Slideshow Parameters

    6.2.1 Slideshow Parameters Slideshow Name - Short name of the slideshow to display in content lists. Framerate – The number of frames for each second of video generated. The tool will generate video at the framerate selected. 29.97fps & 59.94fps are recommended if you are using common 60Hz displays.
  • Page 37 Picture train settings Orientation - Choose to build either a vertical or a horizontal stripe of pictures. Speed – The stripe of pictures will be shifted by this length each frame. Use positive values to scroll right-to-left/up-to-down and negative for the opposite direction. Slide spacing –...

  • Page 38: Youtube And Vimeo

    6.3 YouTube and Vimeo This section explains how to add YouTube and Vimeo videos as the source content. Note: Add YouTube and Add Vimeo buttons become active only when you are connected to the Cloud. In VideoWall Manager 2.0.24, there are some limitations in downloading YouTube and Vimeo videos: 1.

  • Page 39: Configuring And Building Compatible Video

    7 C onfiguring and Building Compatible Video This chapter explains how to configure and build compatible videos. Before building videos from video files and still images, make sure the video wall composition is configured and the source contents are added.
  • Page 40 Follow the steps below to build videos. 1. Select the wall from the Walls and Devices pane. 2. Click the Build tab. 3. Configure Settings. Details of the settings are described in the section 7.1. 4. Click the Build button to start building video. Estimated encoding time is shown. If the contents are modified from the previous build, the button to start build is renamed to Rebuild.

  • Page 41: Transcoder Settings

    7.1 Transcoder Settings Transcoding is the process of converting one digital format to another. 7.1.1 Video Scaling The video scaling option allows you to determine how videos will be scaled to fit in a video wall. This option has no effect if the video and the video wall have the same aspect ratio.
  • Page 42 Rules that determine video stream compatibility are: • None of the output streams (and canvas) requires rotation. • Video codec is h264 (AVC). • Video width is not greater than 1920px AND video height is not greater than 1080px. • H264 profile level is not greater than 4.2. •...

  • Page 43: Transcoding Mode

    7.1.3 Transcoding Mode Sets the transcoding mode. Increasing the picture quality level leads to a more precise analysis of the original picture, and makes the encoding engine’s internal settings finer. Custom Settings: Give users more control over compatibility settings. Video Encoder Mode: Sets the transcoding mode. As the precision of picture analysis and quality of picture increases, the output speed decreases.

  • Page 44: Save Built Content To Local Storage

    7.2 Save Built Content to Local Storage VideoWall Manager allows you to save the generated video to your computer to use it in the future. 1. When the video is built successfully, Click Save. A window appears. 2. Specify the location to save the contents, enter folder name and click Save. 3.

  • Page 45: Publishing Generated Video To Device

    8 Publishing Generated Video to Device Once the videos are built successfully, transfer them to the devices to play them locally. 1. Select the wall from the Walls and Devices pane. 2. Click the Publishing tab. 3. Set Build to Publish. Specify the location of videos that will be transferred to the devices.
  • Page 46 5. Click Start. A confirmation dialog appears. 6. Click OK to start transferring videos. Videos will be transferred to the devices and stored under the asset name specified in the step 4. Any devices that are playing the asset will be stopped. 7.

  • Page 47: Playing Back Video

    9 Playing Back Video 9.1 Play Published Content Videos will play continuously until you stop the playback or delete the wall/device. If the device is rebooted while playing the video, it will automatically start playing the video by calculating the start time and current time. 1.

  • Page 48: Delete Asset From All Devices In The Wall

    9.2 Delete Asset from All Devices in the Wall 1. Select the wall from the Walls and Devices pane. 2. Click the Playback tab. 3. Click on the Asset drop down list. 4. Select the asset you want to delete. 5.

  • Page 49: Wall View And Proof Of Play

    9.4 Wall View and Proof of Play The wall view starts to show snapshots of the video that’s currently playing on the video wall when the capture feature is enabled. Note: This feature becomes unavailable when you connect to the Cloud. To enable the capture, follow these steps: 1.

  • Page 50: Monitoring And Controlling From The Cloud Portal

    10 Monitoring and Controlling from the Cloud Portal Moderro VideoWall Management Service on the Cloud has not been completely implemented, however basic features such as status monitoring and rebooting devices are available. If you haven’t created an account on Moderro VideoWall Management Service on Cloud, refer to section 2.2.1 and create an account.

  • Page 51: Device And Video Wall Status

    11 Device and Video Wall Status Status Device/Wall Description Network connection between the device and Green dot Device VideoWall Manager is good. No network connection between the device Red dot Device and VideoWall Manager. Wall The wall is managed by cloud without issue. White cloud Device The device is managed by cloud without issue.

  • Page 52: Preferences

    12 Preferences The Settings pane manages the VideoWall Manager preferences settings. General Check for updates on startup – If checked, every time the application is launched, it will access the server and check for any updates. If unchecked, the application will not access the server for updates.
  • Page 53 Logs: Creates a new log file every time the application starts. Log to file – If checked, log will be filed to the location specified by Save logs to. If unchecked, no log will be filed. Save logs to – Specifies the location to save logs. Delete old logs on start –...

  • Page 54: Upgrading Videowall Manager

    13 Upgrading VideoWall Manager This chapter explains how to upgrade VideoWall Manager. The application will check the server every time it’s launched and notify user when a new update is available. Check for updates on startup – Uncheck the box to disable application from automatically looking for updates on startup.
