NMP760
Chromebox
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specific languages using the Regional selection
box in the upper right corner of our website. "Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual"
Model No. VS18614
Advertisement
Table of Contents
Related Manuals for ViewSonic NMP760
Summary of Contents for ViewSonic NMP760
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
- Page 2 Thank you for choosing ViewSonic As a world leading provider of visual solutions, ViewSonic is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic product you have chosen will serve you well.
-
Page 3: Ce Conformity For European Countries
Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Declaration Of Rohs2 Compliance
If the batteries, accumulators and button cells included with this equipment, display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead. -
Page 5: Energy Star ® Compliance
ENERGY STAR compliance ® As an ENERGY STAR Partner, has followed the EPA’s enhanced product qualification and certification process to ensure that the products marked with the ENERGY STAR logo are ENERGY STAR qualified per the applicable ENERGY STAR guidelines for energy efficiency. The following logo appears on all ENERGY STAR-qualified computers: The ENERGY STAR program for computers was created by the EPA to promote energy efficiency and reduce air pollution through more energy-efficient equipment in... -
Page 6: Table Of Contents
Contents Compliance Information FCC Statement ..................i CE Conformity for European Countries ..........i Declaration of RoHS2 Compliance ............ii ENERGY STAR compliance .............iii ® Copyright Information For Your Records ................1 1. PRODUCT OVERVIEW Package contents ................2 Front view ................... 3 Rear View ................... - Page 7 4. Operting the Chromebox Navigating the desktop ..............11 Managing apps ................. 11 Wireless connections ............... 12 Connecting to a wireless access point ..........12 Connecting to Bluetooth devices ............12 Managing notifications ..............13 Switching to Night Light mode ............13 Adjusting volume ................
-
Page 8: Copyright Information
Purchase Date: _______________________________________ Product disposal at end of product life ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more. USA & Canada: http://www.viewsonic.com/company/green/recycle-program/ Europe: http://www.viewsoniceurope.com/eu/support/call-desk/... -
Page 9: Product Overview
1. PRODUCT OVERVIEW Package contents Please take a moment to check if all the necessary items are included in the package. If anything is missing or damaged, please contact your dealer immediately. NMP760 Power adapter Power cord (by Region) Wall Mount... -
Page 10: Front View
Front view Description Description Audio jack (3.5mm) Power button with LED (2) USB type-A 3.0 ports* Kensington lock port MicroSD™ card reader Reset hole Note: *Supports battery charging. Rear View 1 2 3 5 6 7 8 Description Description LAN port DC-in jack (2) USB 2.0 ports USB type-C port... -
Page 11: Status Indicators
Status indicators Indicator Color Status Description Power button Chromebox is switched on. White Chromebox is switched off. Flashing Activity on the link. Orange No activity on the link. LAN port Active link connection. Green No link connection. -
Page 12: Getting Started
2. Getting Started Connecting the AC power To connect your Chromebox to the power outlet, do the following: Connect one end of the power cord to the AC adapter and the other end to the power outlet. Connect the AC adapter to the DC-in jack of your Chromebox. Connecting a display device To establish the connection, you need to use an HDMI cable (not supplied). -
Page 13: Connecting A Mouse And Keyboard
Connecting a mouse and keyboard Your Chromebox supports both wired and wireless mouse and keyboard. Connecting a mouse and keyboard Connect the USB mouse and USB keyboard to the USB2.0 ports of your Chromebox. Connecting a wireless mouse and keyboard Connect the USB receiver that is supplied with your wireless mouse and keyboard to the USB port of your Chromebox. -
Page 14: Performing Additional Connections
3. Performing additional connections Connecting audio components Connect the audio component into the audio jack of your Chromebox. Connecting to local area network (LAN) Connect one end of the RJ-45 cable to the LAN port of your Chromebox. Connect the other end of the RJ-45 cable to a network connection device or a network wall connector. -
Page 15: Inserting A Memory Card
Inserting a memory card Note: Your Chromebox supports MicroSD™ cards. With the gold contacts facing down, insert the memory card into the card reader. Push the memory card all the way until you hear a locking sound. Connecting USB devices Note: Your Chromebox supports USB2.0, USB3.0, and USB type-C. -
Page 16: Mounting The Chromebox
Mounting the Chromebox Mount the Chromebox to the back of your display device. Note: Make sure your display device supports VESA mounting. Refer to the following illustration for size measurements: 100 mm 75 mm Secure the mounting plate (optional accessory) to the VESA mounting holes behind your display device with the four screws. -
Page 17: Powering On Your Chromebox
Align and install your Chromebox to the screw holes in the mounting plate. Powering on your Chromebox To power on your Chromebox, press the Power button on the front panel. The Power button LED lights solid white. After you power on the Chromebox for the first time, you are asked to configure some device’s basic settings, such as set the language, configure accessibility options, connect to the network, and finally sign in to your Chromebox. -
Page 18: Operting The Chromebox
4. Operting the Chromebox Navigating the desktop After the initial setup is configured, you will see the desktop. Click on any of the following items: • Launcher: Manage installed apps and perform search. • App launcher: Access most frequently used apps quickly. •... -
Page 19: Wireless Connections
Wireless connections Connecting to a wireless access point Click anywhere on the Status tray to open the tray. Click on to automatically enable Wi-Fi function and start scanning for nearby wireless access points. After scanning, a list of available Wi-Fi networks is displayed on the screen. -
Page 20: Managing Notifications
Managing notifications Click anywhere on the Status tray to open the tray. Click to switch to Do not disturb mode. Click again to disable the mode. Click next to Notifications to select apps that are allowed to send notifications. Switching to Night Light mode Click anywhere on the Status tray to open the tray. -
Page 21: Configuring Chromebox Settings
Configuring Chromebox settings Click Status tray > or Launcher > > to open Settings page. Configure any of the following: • Network > Ethernet: LAN connection parameters. Note: Make sure your Chromebox is connected to the LAN. Refer to page 15. •... - Page 22 • Personalisation > Wallpaper: Select your preferred desktop wallpaper. • Search and Assistant > Preferred search engine: Set the default search engine that is used in the address bar. • Search and Assistant > Google Assistant: Enable or disable Google Assistant and configure its settings.
-
Page 23: Troubleshooting
5. Troubleshooting If you experience a problem with your Chromebox, refer to the following troubleshooting guide. If a problem persists, contact the service center. The power is switched on, but Chromebox does not start: • Make sure that the AC adapter is properly plugged into the DC-in jack of the Chromebox and to the power outlet. -
Page 24: Specifications
6. Specifications Item Description Processor CPU Intel Celeron 5205U Dual Core 1.8GHz BGA 2MB L3 HD 610 Operating system Google Memory 8G DDR4, 2 slots Memory type 2133 DDR4 SODIMM (DDR4-2133) Storage eMMC Storage capacity Storage type 2242 type Gigabit Networking 10 / 100 / 1000M GbE LAN 802.11ac, BT Combo (2x2) -
Page 25: Other Information
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 ( 繁體中文 ) www.viewsonic.com/hk/ Hong Kong (English) www.viewsonic.com/hk-en/... - Page 26 If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
- Page 27 Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 10 Pointe Dr. Suite 200. Brea, CA. 92821, UY.S.A Col 20 de Noviembre Tel: 800-688-6688 Tijuana, Mexico E-Mail: http://www.viewsonic.com...
