User Manual
Quick Start Guide
Network Media Player NMP-530
Packaged Contents
Check that you have all the following items in the package.
Remote Control and Two
Batteries
RJ-45
Ethernet Cable
System Requirements
System requirements include a display, a network
environment, and a PC with network capability
Software Requirements
Software applications need to be purchased
separately in order to create material for playback,
such as graphics, video, and Flash files, etc.
Back view
VIDEO
USB
Reset
HDMI*
S-VIDEO/YPbPr
CVBS
*If your monitor has a DVI input, use an HDMI-to-DVI cable.
NMP-530
S-Video/YPbPr Adapter
AUDIO
POWER-5V DC
Ethernet 10/100
RS232
AUDIO LEFT
AUDIO RIGHT
Quick Start Guide
Quick Start Guide
RS-232 Cable
PC Requirements (for basic server)
• Operating System: Any Windows
capable of running a web server
®
• Processor: Intel
Pentium
compatible microprocessor)
• Memory: 512 MB RAM or more
• Network Interface: 100Base-T
ViewSonic CD
AC Power Adapter
®
or Linux OS
®
4, 1 GHz or higher (or
Front view
Blue LED: Power
Green LED: Activity
Advertisement
Related Manuals for ViewSonic NMP-530 - Digital Multimedia Receiver
Summary of Contents for ViewSonic NMP-530 - Digital Multimedia Receiver
- Page 1 Quick Start Guide Network Media Player NMP-530 Packaged Contents Check that you have all the following items in the package. Quick Start Guide ViewSonic CD Remote Control and Two Quick Start Guide NMP-530 Batteries RJ-45 RS-232 Cable S-Video/YPbPr Adapter AC Power Adapter...
-
Page 2: Connect T O A Display
S etup For the initial setup, you need the following: • A Router with DHCP services • A TV or Display with Composite or S-Video input for initial setup. During the setup, you can change the NMP-530 output to the final display being used. •... - Page 3 ONNECT OUTER Connect the supplied RJ-45 ethernet cable from the NMP-530 to a router with DHCP services. Refer to your router’s user guide or contact your network administrator for assistance. Ethernet Cable Router...
-
Page 4: Turn Power On
OWER Connect the supplied AC Adapter DC Plug into the NMP-530. Turn the TV or the Display power on making sure that the Input is on the proper setting. Plug the AC Adapter to a wall outlet. AC power AC Power Adapter (wall outlet) (supplied) -
Page 5: Start Url
IP A DDRESS Wait a few seconds and the IP Address of the NMP-530 appears on the screen. Make a note of the IP information as this will be used to login to the NMP-530. OGIN Open an Internet Browser, i.e., Internet Explorer on a PC in the same network. In the URL address field, type the IP address of the NMP-530 noted in the previous step >... -
Page 6: Set Video Output Of Nmp-530
NMP-530 IDEO UTPUT OF By default, the video output is set to S-Video. But, you can choose any one of the following connections if you prefer, depending on the type of display input you want to use. HDMI Connect an HDMI cable from the back of the NMP-530 to the HDMI interface on the back of the display. -
Page 7: Put Batteries In Remote Control
Be sure to match the positive end of the battery with the positive end in the compartment. Put the cover back on the remote control. For more information, see the NMP-530 User Guide. If you still need help, contact ViewSonic Customer Support as listed in the user guide or on our website.
