Configuring a Cisco Unified Communications
Manager SIP Trunk with a Cisco
TelePresence Content Server
This document includes instructions for configuring a Cisco Unified Communications Manager version
9.1.2 and 10.5 Session Initiation Protocol (SIP) trunk with Cisco TelePresence Content Server (Content
Server) Release 6.2.
Before integrating Cisco Content Server 6.2 with CUCM through a SIP trunk, confirm that the Cisco
Content Server is ready for the integration completing the applicable tasks in the Content Server
installation guide. See the
http://www.cisco.com/c/en/us/td/docs/telepresence/tcs/6_0/installation/guide/tcs-vm-install.html
CUCM Integration with Content Server 6.2
After installing the CUCM software is installed, complete these procedures in the following order:
•
•
Cisco Content Server Standalone
To create a SIP Trunk between CUCM and Content Server.
1.
2.
3.
Complete these steps in the order given:
Create the SIP Trunk Security Profile
Step 1
Login to the Cisco Unified Communication Manager Administration Interface.
Step 2
Choose Security > SIP Trunk Security Profile.
Step 3
On the Find and List SIP Trunk Security Profiles page, click Add New.
CUCM Integration with Cisco Content Server Standalone
Cisco TCS 6.2 with a Content Server cluster configured
Create the SIP Trunk Security Profile
To Create the SIP Profile
Create the SIP Trunk
Cisco TelePresence Content Server Release 6.2.1 Administration and User Guide
3
C H A P T E R
3-15

Advertisement

loading

Related Manuals for Cisco TelePresence

Summary of Contents for Cisco TelePresence

  • Page 1 9.1.2 and 10.5 Session Initiation Protocol (SIP) trunk with Cisco TelePresence Content Server (Content Server) Release 6.2. Before integrating Cisco Content Server 6.2 with CUCM through a SIP trunk, confirm that the Cisco Content Server is ready for the integration completing the applicable tasks in the Content Server installation guide.
  • Page 2 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Step 4 On the SIP Trunk Security Profile Configuration page, under SIP Trunk Security Profile Information, enter the following: Field...
  • Page 3 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 To Create the SIP Profile Step 1 In Cisco Unified CM Administration, expand Device> Device Settings and select SIP Profile.
  • Page 4 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Step 5 Click Save. Create the SIP Trunk Step 1 In Cisco Unified CM Administration, expand Device and click Trunk.
  • Page 5 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Step 7 Under SIP Information, enter the following. Cisco TelePresence Content Server Release 6.2.1 Administration and User Guide 3-19...
  • Page 6 Recording Alias URI Suffix on TCS should match with suffix based SIP route pattern that configured on CUCM. Eg: If SIP route pattern configured on CUCM is ‘@tcs-cisco.com’ then the recording alias URI configured on TCS must be ‘xxx@tcs-cisco.com’. Using Number Based Routing.
  • Page 7 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Note Because no default SIP route patterns exist in CUCM, the administrator must configure them. Domain name examples: cisco.com, my-pc.cisco.com, *.com, rtp-ccm[1-5].cisco.com Valid characters for domain names: [, -, ., 0-9, A-Z, a-z, *, and ].
  • Page 8 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description Use Calling Party's Check the check box if you want the full, external phone number to be used External Phone Mask for calling line identification (CLID) on outgoing calls.
  • Page 9 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description Connected Line ID Cisco Unified Communications Manager uses connected line ID Presentation presentation (COLP/COLR) as a supplementary service to allow or restrict the called party phone number on a call-by-call basis.

  • Page 10: Configuring Route Patterns Using Route Group/ Route List

    Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Configuring Route Patterns Using Route Group/ Route List A route pattern is a string of digits (an address) and a set of associated digit manipulations that can be assigned to a route list or a gateway.
  • Page 11 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description Device Name contains Enter the character(s) that are found in the device name that you are seeking and click the Find button. Device names that match the character(s) that you entered display in the Available Devices box.
  • Page 12 Step 4 From the drop-down list box, choose a Cisco Unified Communications Manager group. Note The Route List registers with the first Cisco Unified Communications Manager in the group which is its primary Cisco Unified Communications Manager. Note If you choose a Cisco Unified Communications Manager group that has only one Cisco Unified...
  • Page 13 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 To add a route group to this list, click Add Route Group and perform Step 4 through Step 8 of the “Adding Route Groups to a Route List”...
  • Page 14 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Step 4 Click Save. Field Description Pattern Definition Route Pattern Enter the route pattern, including numbers and wildcards (do not use spaces);...
  • Page 15 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description MLPP Precedence Choose an MLPP precedence setting for this route pattern from the drop-down list box: • Flash Override—Second highest precedence setting for MLPP calls.
  • Page 16 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description Allow Overlap Sending With overlap sending enabled, when Cisco Unified Communications Manager passes a call to the PSTN, it relies on overlap sending in the PSTN to determine how many digits to collect and where to route the call.
  • Page 17 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description Use Calling Party's Check the check box if you want the full, external phone number to be used External Phone Number for calling line identification (CLID) on outgoing calls.
  • Page 18 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description Connected Line ID Cisco Unified Communications Manager uses connected line ID Presentation presentation (COLP/COLR) as a supplementary service to allow or restrict the called party phone number on a call-by-call basis.

  • Page 19: Cisco Content Server Cluster Configuration

    Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Description Carrier Identification Enter the appropriate carrier identification code (0, 3, or 4 digits) in the Code Carrier Identification Code field. Carrier identification codes allow customers to reach the services of interexchange carriers.
  • Page 20 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Step 5 Click Add to Route Group. Step 6 Under Current Route Group Members, confirm that the SIP trunk that connects to the subscriber TCS 6.2 appears first in the list.

  • Page 21: Region Configuration On Cucm

    Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Field Setting Route Pattern Enter the route pattern for TCS trunk. Gateway/Route List Select the name of the route list that you created in the...
  • Page 22 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 To Create the Integration Step 1 In Content Server Administration, expand the Management tab, go to Configuration> Site Setting >SIP Setting.
  • Page 23 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Cisco TelePresence Content Server Release 6.2.1 Administration and User Guide 3-37...
  • Page 24 Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence CUCM Integration with Content Server 6.2 Cisco TelePresence Content Server Release 6.2.1 Administration and User Guide 3-38...
