For tool with the knob
CAUTION:
Be sure to re-install the knob after
inserting new carbon brush.
Release the lock lever and remove the knob by turning
it counterclockwise.
Fig.25
► 1. Knob
NOTE: The compression spring will come out of
the knob, so be careful not to lose the compression
spring.
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
OPTIONAL
ACCESSORIES
Router bits
Straight bit
1
Fig.26
D
6
1/4"
12
1/2"
12
1/2"
8
6
1/4"
6
1/4"
"U"Grooving bit
Fig.27
D
6
10 ENGLISH
A L1
20 50
12 60
10 60
8 60
8 50
6 50
R
A L1 L2
6 50 18
Unit:mm
L2
15
30
25
25
18
18
Unit:mm
R
3
