IPSec Security Method
After finishing all the settings here, please click OK to save the configuration.
4 . 1 2 . 6 L A N t o
4 . 1 2 . 6 L A N t o
Here you can manage LAN-to-LAN connections by maintaining a table of connection profiles.
You may set parameters including specified connection direction (dial-in or dial-out),
connection peer ID, connection type (VPN connection - including PPTP, IPSec Tunnel, and
L2TP by itself or over IPSec) and corresponding security methods, etc.
The router supports up to 2 VPN tunnels simultaneously. The following figure shows the
summary table.
Available settings are explained as follows:
Item
Set to Factory Default
Vigor2132 Series User's Guide
Identity.
This group of fields is a must for IPSec Tunnels and L2TP
with IPSec Policy when you specify the remote node.
Check the Medium, DES, 3DES or AES box as the security
method.
Medium-Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option
is invoked. You can uncheck it to disable it.
High-Encapsulating Security Payload (ESP) means
payload (data) will be encrypted and authenticated. You
may select encryption algorithm from Data Encryption
Standard (DES), Triple DES (3DES), and AES.
Local ID (Optional)- Specify a local ID to be used for
Dial-in setting in the LAN-to-LAN Profile setup. This item
is optional and can be used only in IKE aggressive mode.
L A N
L A N
Description
Click to clear all indexes.
310
