4 4 . . 9 9 . . 6 6 . . 2 2 P P P P T T P P D D i i a a l l - - o o u u
Display the name of LAN to LAN profile with PPTP dial-out/SSL dial-out tunnel.
Each item will be explained as follows:
Item
Add
Edit
Delete
Refresh
Profile Number Limit
Profile
Enable
Dial-Out Through
Server IP/Host
PPTP User Name/
SSL User Name
Local IP / Subnet Mask
Remote IP / Subnet
Mask
t t / / S S S S L L D D i i a a l l - - o o u u t t T T u u n n n n e e
Description
Add a new profile.
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
profile.
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Renew current web page.
Display the total number (200) of the object profiles to be
created.
Display the name of LAN to LAN profile with PPTP/SSL
dial-out policy.
Display the status of the profile. False means disabled; True
means enabled.
Display the WAN interface selected for the profile.
Display the IP address or the host name of PPTP/SSL server.
Display the user name for authentication in PPTP/SSL
connection.
Display the LAN IP address with subnet mask of this profile.
Display the WAN IP address with subnet mask of this
profile.
354
l l
Vigor3900 Series User's Guide
