Available parameters are listed as follows:
Item
Profile
MAC Address
Apply
Vendor
Cancel
4. Enter all of the settings and click Apply.
5. A new MAC/Vendor Object profile has been created.
Description
Type a name for such profile.
Click Add to have the fields of MAC Address and Mask.
Type the address with the correct format (will be shown
automatically when the mouse cursor is on it). Choose a
suitable mask selection.
Click it to save the configuration.
Edit – Click it to open a table of vendor list. Check the
one(s) you want. The names for selected vendors will be
shown later.
Click it to exit the dialog without saving anything.
230 Vigor3900 Series User's Guide
